HPE
HPE DL580 Gen9 5SFF 4x Xeon E7-8890v4 2.2GHz 128GB DDR4 rack server
A four-socket rack server with four Xeon E7-8890v4 processors at 2.2 GHz, 128 GB DDR4 memory, five 2.5-inch drive bays and a Smart Array P830 controller
- TypeRack
- CPU TypeIntel Xeon
- CPU Speed2.2GHz
- # of Processors Installed4
- MAX Processors4
- Installed Memory Size128GB
- Four Xeon E7-8890v4 processors at 2.2GHz provide 24 cores each
- 128GB DDR4 ECC registered memory supports large workloads
- 5SFF chassis accepts up to five 2.5" drives
- HPE Smart Array P830 with 4GB RAID cache protects data
- Dual 10GbE and dual 1GbE Intel ports plus iLO remote management
HPE DL580 Gen9 four-processor rack server
This HPE DL580 Gen9 rack server ships with four Intel Xeon E7-8890v4 processors running at 2.2GHz. The system provides 128GB of DDR4 ECC registered memory and supports a maximum of 6TB. Five 2.5-inch small-form-factor drive bays are available for SATA or SAS storage. An integrated HPE iLO Advanced module handles remote management.
Storage limits of the SATA and SAS interface
The onboard Smart Array P830 controller manages up to five 2.5-inch bays using SATA or SAS drives. SATA devices operate at 6Gb/s while SAS devices reach 12Gb/s, so mixed arrays run at the lower speed. The controller includes 4GB of RAID cache to absorb write bursts. Maximum raw capacity depends on the largest drives you install in the five bays.
Installation notes and common issues
The chassis measures 36 by 24 by 10 inches and weighs 40 units, so plan rack space and lifting assistance before unpacking. Two 1200W Flex Slot power supplies are pre-installed; verify that your PDU cables match the IEC connectors. Memory must be DDR4 ECC registered — other DDR generations will not fit or post. Rail kits are optional and must be ordered separately if your rack requires them.
Points forts
- Four Xeon E7-8890v4 processors at 2.2GHz provide 24 cores each
- 128GB DDR4 ECC registered memory supports large workloads
- 5SFF chassis accepts up to five 2.5" drives
- HPE Smart Array P830 with 4GB RAID cache protects data
- Dual 10GbE and dual 1GbE Intel ports plus iLO remote management
Caractéristiques
| Brand | HP |
|---|---|
| Series | ProLiant |
| Model | Rack Mount |
| Type | Rack |
| CPU Type | Intel Xeon |
| CPU Speed | 2.2GHz |
| # of Processors Installed | 4 |
| MAX Processors | 4 |
| Installed Memory Size | 128GB |
| Memory Type | DDR4 |
| Max Memory Capacity | 6TB |
| Hard Drive (Installed) | 3,84 |
| Storage Controller | HPE Smart Array P830 SAS Controller |
| HDD Interface | SATA |
| GPU Type | Integrated Graphics |
| Remote Management | HPE iLO Advanced |
| Dimensions | 36 x 24 x 10 in |
| Weight | 40 |
Questions sur cet article
Should I choose the 5SFF chassis with the four E7-8890v4 CPUs and 128 GB DDR4, or a different drive-bay count?
The 5SFF chassis provides five 2.5-inch bays; this unit ships with four E7-8890v4 processors at 2.2 GHz and 128 GB DDR4 ECC registered memory.
What does the 2.2 GHz clock speed mean for actual throughput with four 24-core Xeons installed?
Four Xeon E7-8890v4 CPUs each run at 2.2 GHz with 24 cores, giving dense multi-threaded performance for virtualization and database workloads.
How does the SAS controller and SATA interface limit drive speed in this 5SFF box?
The HPE Smart Array P830 SAS controller with 4 GB cache manages SATA drives; peak throughput is capped by the SATA link and the controller's 4 GB cache buffer.
