Silver 2U rack storage array with twelve drive bays populated

HPE

HPE MSA 2060 Gen6 P79248-B25 2U rack server 28.8TB 12x2.4TB SAS 2x10/25GbE iSCSI 4-port

SKU CH-KC96-6BZ7Q MPN P79248-B25

Delivers 28.8 TB of SAS storage in a 2U rack server with twelve 2.4 TB drives and dual 10/25 GbE iSCSI controllers

  • WorkloadStorage Server
  • TypeSmall Form Factor
  • Rack Height2U
  • Hard Drive (Installed)28.8TB (12 x 2.4TB)
  • Storage Controller2 x 10/25 GbE iSCSI 4-port Controller
  • HDD InterfaceSAS

HDD 28.8TB (12 x 2.4TB)

Option 2 x 10/25 GbE iSCSI 4-port controllers

  • 8TB raw capacity from twelve 2.4TB SAS drives
  • Dual 10/25GbE iSCSI 4-port controllers for host connectivity
  • 2U rack form factor with 24 SFF drive bays
  • Two 580W redundant power supplies included
  • Expandable to 1.78PB raw capacity with additional enclosures

HPE MSA 2060 Gen6 28.8TB SAS storage array

The HPE MSA 2060 Gen6 is a 2U rack-mount SAN storage system with twelve 2.4TB SAS hard drives installed for 28.8TB raw capacity. It targets small and remote offices that need affordable shared storage with room to grow.

Dual 580W redundant power supplies

Two 580W redundant power supplies feed the base array and any attached enclosures. The platform accepts up to 24 SFF drives per enclosure and supports both enterprise SAS HDDs and SSDs in the same chassis.

2x 10/25GbE iSCSI 4-port controllers

The array ships with two 10/25GbE iSCSI 4-port controllers and four 10Gb iSCSI SFP+ transceivers included. Expansion enclosures attach via 12Gb SAS, allowing up to nine additional units for larger deployments.

Points forts

  • 8TB raw capacity from twelve 2.4TB SAS drives
  • Dual 10/25GbE iSCSI 4-port controllers for host connectivity
  • 2U rack form factor with 24 SFF drive bays
  • Two 580W redundant power supplies included
  • Expandable to 1.78PB raw capacity with additional enclosures

Caractéristiques

BrandHPE
SeriesMSA 2060 Gen6
ModelP79248-B25
WorkloadStorage Server
TypeSmall Form Factor
Rack Height2U
Hard Drive (Installed)28.8TB (12 x 2.4TB)
Storage Controller2 x 10/25 GbE iSCSI 4-port Controller
HDD InterfaceSAS
Max HDD CapacityMaximum array raw capacity of 1.78 PB (all SFF) and 2.71 PB (SFF & LFF)
Expansion Bays24 drive bay 2060 SFF drive enclosure or 12 drive bay 2060 LFF drive enclosure (add up to 9 with any combination)
Compatible/Certified OSWindows Server 2022
Windows Server 2019
Windows Server 2016
VMWare vSphere 6.7
Red Hat Linux 8
SuSE SLES 15
Power CharacteristicsTwo 580W redundant power supplies
Dimensions3.5" x 17.5" x 20.0"
Weight11 lbs.
Package ContentsHPE MSA 10 Gb Short Range iSCSI SFP+ 4-pack Transceivers
Poids d’expédition13.61 kg
Dimensions du colis762 × 635 × 254 mm

Autres versions de ce modèle

3 de plus dans cette gamme

Même famille, mémoire, ventirad ou fréquence différents — comparez avant de vous décider.

Questions sur cet article

How do I install the HPE MSA 2060 Gen6 into a standard rack, and which step is often missed?

Mount the 2U chassis using the included rails, connect the two 580W redundant power supplies to separate circuits, then link the 2 x 10/25 GbE iSCSI 4-port controllers to your network; the step often missed is registering the array in HPE InfoSight for automatic firmware baseline alignment.

What maintenance or replacement will the installed 12 x 2.4TB SAS drives need later?

The 28.8TB of factory-installed SAS drives are field-replaceable hot-swap units; monitor SMART alerts via the management UI and replace any drive that reports predictive failure — no scheduled media refresh is required.

What limit appears first under sustained write workloads on this array?

The dual 10/25 GbE iSCSI controller ports and the 12 Gb/s SAS backend set the sustained throughput ceiling; once aggregate write IOPS approach the rated 395000 IOPS, latency rises before the drive media saturates.
