HPE
HPE P83314-005 ProLiant DL380 Gen11 Xeon 6530 32-Core 64GB DDR5 2x960GB SATA SSD rack server
A 1U rack server with a 32-core Intel Xeon Gold processor, 64 GB DDR5 memory, dual 960 GB SATA SSDs and redundant 1000 W power supplies
- WorkloadGeneral Purpose Server
- TypeRack
- Rack Height1U
- Hot-swap Fans6 x High Performance Fan
- CPU TypeIntel Xeon Gold
- CPU Speed6530 (2.10 GHz)
- 32-core Xeon 6530 at 2.1 GHz drives heavy workloads
- 64 GB DDR5 Smart Memory at 5600 MT/s feeds data fast
- Two 960 GB SATA read-intensive SSDs supply quick storage access
- Dual 1000 W Titanium hot-plug supplies keep power redundant
- Up to 8 PCIe Gen5 plus 2 OCP 3.0 slots expand I/O flexibility
1U rack server with 32-core Xeon
The HPE ProLiant DL380 Gen11 is a 1U rack server built around a single Intel Xeon Gold 6530 processor running at 2.10 GHz with 32 cores and 160 MB L3 cache. It ships with 64 GB of HPE DDR5 Smart Memory in a two-module configuration at 5600 MT/s. The platform targets general-purpose workloads that need dense compute in a standard rack footprint.
Thermals, noise and dual 1000W titanium supplies
Six high-performance hot-swap fans provide airflow through the 1U chassis while the two 1000W Flex Slot Titanium power supplies operate in a redundant configuration. Titanium-rated efficiency reduces waste heat and lowers overall power draw during typical operation. Hot-swap capability allows a failed supply or fan to be replaced without shutting the system down.
MR416i-o controller and 25GbE OCP adapter
The onboard HPE MR416i-o Gen11 storage controller brings x16 PCIe lanes and 8 GB of cache to manage the two installed 960GB SATA read-intensive SSDs. An Intel E810-XXVDA2 dual-port SFP28 OCP 3.0 adapter delivers 10/25Gb Ethernet connectivity for high-speed fabric integration. Up to eight PCIe Gen5 slots and a second OCP 3.0 bay remain available for additional I/O expansion.
Points forts
- 32-core Xeon 6530 at 2.1 GHz drives heavy workloads
- 64 GB DDR5 Smart Memory at 5600 MT/s feeds data fast
- Two 960 GB SATA read-intensive SSDs supply quick storage access
- Dual 1000 W Titanium hot-plug supplies keep power redundant
- Up to 8 PCIe Gen5 plus 2 OCP 3.0 slots expand I/O flexibility
Caractéristiques
| Brand | HPE |
|---|---|
| Series | ProLiant DL380 G11 |
| Model | P83314-005 |
| Workload | General Purpose Server |
| Type | Rack |
| Rack Height | 1U |
| Hot-swap Fans | 6 x High Performance Fan |
| CPU Type | Intel Xeon Gold |
| CPU Speed | 6530 (2.10 GHz) |
| Number of CPU Cores | 32-Core Processor |
| Cache Memory | 160 MB L3 Cache |
| # of Processors Installed | 1 |
| Installed Memory Size | 64 GB (2x32 GB, 5600 MT/s) |
| Memory Type | HPE DDR5 Smart Memory |
| Storage Controller | HPE MR416i-o Gen11 x16 Lanes 8GB Cache OCP SPDM Storage Controller |
| SSD (Installed) | 2 x HPE 960GB SATA 6G Read Intensive SFF |
| Ethernet Controller | Intel E810-XXVDA2 Ethernet 10/25Gb 2-port SFP28 OCP3 Adapter for HPE |
| Expansion Slots | Up to 8 PCIe Gen5, and 2 OCP 3.0 |
| Power Characteristics | 2 x HPE 1000W Flex Slot Titanium Hot Plug Power Supply Kit |
| Dimensions | 10.75" x 23.62" x 39.29" |
| Weight | 91.095 lbs. |
| Poids d’expédition | 18.14 kg |
| Dimensions du colis | 508 × 508 × 152 mm |
Questions sur cet article
How do I install the HPE MR416i-o storage controller and what step is often missed?
The MR416i-o plugs into an OCP 3.0 slot; the step often missed is seating the controller fully until the latch clicks and then enabling the SPDM option in the BIOS before creating any arrays.
What maintenance will the 960GB SATA SSDs need later?
The read-intensive SSDs have no user-serviceable parts; monitor the Smart Carrier health LED and replace a drive only when the controller reports a predictive failure or the wear indicator reaches its limit.
What limit appears first under sustained load with the 1000W Titanium power supplies?
With dual 1000W supplies the thermal ceiling of the 1U chassis is reached before the power budget, so sustained heavy workloads are limited by the six high-performance fans keeping the Xeon 6530 and memory within spec.
