Intel
Intel 535 Series 2.5" 360GB SATA internal SSD SSDSC2BW360H601
A 2.5-inch SATA internal SSD with 360GB of MLC storage delivering up to 540 MBps sequential read and 490 MBps write speeds for responsive consumer computing
- Device TypeInternal Solid State Drive (SSD)
- Used ForConsumer
- Form Factor2.5"
- Capacity360GB
- Memory ComponentsMLC
- InterfaceSATA III
Options 360GB
- 360GB
- 180GB
- Fast boot and app launches with up to 540 MB/s sequential read
- Responsive multitasking backed by up to 490 MB/s sequential write
- Snappy random access from 45,000 read and 33,000 write IOPS
- Low power draw at 55 mW idle and 165 mW active extends battery life
- High endurance with 1.2 million hours MTBF and 16 nm MLC NAND
Intel 535 Series 360GB SATA SSD
This 2.5 inch internal solid state drive uses 16nm MLC NAND and a SATA III interface to deliver up to 540 MBps sequential read and up to 490 MBps sequential write speeds. Random 4KB performance reaches 45,000 IOPS read and 33,000 IOPS write. It targets consumers who want faster boot times and application launches without moving parts.
Upgrade from mechanical hard drive
Replacing a traditional hard drive with this SSD removes mechanical latency and yields read latency of 80 µs and write latency of 85 µs. The jump is worth it when a system feels sluggish during multitasking or when battery life matters, because active power draw is 165mW and idle power is 55mW. MTBF is rated at 1,200,000 hours for long-term reliability.
SATA III interface limits
The SATA III interface caps sequential throughput near 540 MBps read and 490 MBps write, so faster NAND cannot exceed this ceiling. Random IOPS top out at 45,000 read and 33,000 write within the same bottleneck. Operating temperature range is 0°C to 70°C, which defines the thermal envelope for sustained workloads.
Points forts
- Fast boot and app launches with up to 540 MB/s sequential read
- Responsive multitasking backed by up to 490 MB/s sequential write
- Snappy random access from 45,000 read and 33,000 write IOPS
- Low power draw at 55 mW idle and 165 mW active extends battery life
- High endurance with 1.2 million hours MTBF and 16 nm MLC NAND
Caractéristiques
| Brand | Intel |
|---|---|
| Series | 535 Series |
| Model | SSDSC2BW360H601 |
| Device Type | Internal Solid State Drive (SSD) |
| Used For | Consumer |
| Form Factor | 2.5" |
| Capacity | 360GB |
| Memory Components | MLC |
| Interface | SATA III |
| Max Sequential Read | Up to 540 MBps |
| Max Sequential Write | Up to 490 MBps |
| 4KB Random Read | Up to 45,000 IOPS |
| 4KB Random Write | Up to 33,000 IOPS |
| Read Latency | 80 µs |
| Write Latency | 85 µs |
| MTBF | 1,200,000 hours |
| Features | High performance for demanding applications High quality and reliability Low power consumption Space-conscious form factors 16nm NAND technology Wide range of capacities |
| Power Consumption (Idle) | 55mW |
| Power Consumption (Active) | 165mW |
| Operating Temperature | 0°C ~ +70°C |
| Storage Temperature | -55°C ~ +95°C |
| Max Shock Resistance | 1500 G/0.5 ms |
| Max Vibration Resistance | Operating: 2.17 GRMS (5-700Hz) Non-Operating: 3.13 GRMS (5-800Hz) |
| Height | 7.00mm |
| Weight | 78.00g |
| Poids d’expédition | 0.10 kg |
| Dimensions du colis | 150 × 107 × 20 mm |
Autres versions de ce modèle
1 de plus dans cette gamme
Même famille, mémoire, ventirad ou fréquence différents — comparez avant de vous décider.
Questions sur cet article
Will the 2.5 inch form factor fit my laptop drive bay?
The drive uses the standard 2.5 inch form factor and a SATA interface so it fits any laptop or desktop bay that accepts a 2.5 inch SATA drive.
What is the correct way to connect the SATA data and power cables during installation?
Attach the SATA data cable to the motherboard SATA port and the SATA power connector from the power supply; the drive has no jumpers or extra configuration steps.
How long is the drive rated to last under typical use?
The manufacturer rates the drive at 1,200,000 hours MTBF and the MLC NAND is designed for sustained consumer workloads within the 0 to 70 °C operating range.
