Compact black mini PC barebone with RGB lighting accents, 221 by 142 by 42 mm

Intel

Intel NUC11 Phantom Canyon i7-1165G7 RTX 2060 barebone mini PC

SKU CH-N9QA-6XQF6

Barebone mini PC with Core i7-1165G7, RTX 2060 6 GB GDDR6, dual DDR4-3200 slots up to 64 GB, dual M.2, 2.5 Gb Ethernet, Wi-Fi 6E and Bluetooth 5.2

  • ColorBlack
  • CPU TypeIntel 11th generation Core
  • CPU SocketCore i7 1165G7
  • FSB2.8 GHz
  • Memory installedNo Memory
  • Memory slot2 x 288Pin DIMM
  • 11th Gen Core i7-1165G7 up to 4.7 GHz for responsive performance
  • Discrete NVIDIA GeForce RTX 2060 with 6 GB GDDR6 for gaming graphics
  • Dual DDR4-3200 SODIMM slots up to 64 GB for memory flexibility
  • Two M.2 slots supporting NVMe or SATA SSDs for storage choice
  • 5 Gb Ethernet, Wi-Fi 6E AX411 and Bluetooth 5.2 for fast connectivity

Compact gaming barebone

The Intel NUC11 Phantom Canyon is a barebone mini PC built around an 11th generation Core i7-1165G7 processor and a discrete NVIDIA GeForce RTX 2060 graphics card with 6 GB GDDR6. It ships without memory or storage, letting builders choose up to 64 GB of dual-channel DDR4 3200 and two M.2 drives. The 230 W power adapter and 221 x 142 x 42 mm chassis complete the kit.

Step up from integrated graphics

This system replaces a pure integrated-graphics mini PC when 3D workloads or modern titles need dedicated GPU performance. The jump is worth it if you want RTX 2060-class frame rates in a 42 mm thin enclosure that still offers 2.5 Gb Ethernet, Wi-Fi 6E AX411 and Bluetooth 5.2. Builders who only need office productivity or media playback can stay with integrated Iris Xe graphics.

DIY builders wanting a tiny RTX box

It suits enthusiasts who will supply their own DDR4 modules and NVMe or SATA SSDs to create a compact gaming or content-creation rig. It is not for buyers who want a complete out-of-the-box system with Windows pre-installed, nor for those who need more than two memory slots or a larger GPU power envelope.

Points forts

  • 11th Gen Core i7-1165G7 up to 4.7 GHz for responsive performance
  • Discrete NVIDIA GeForce RTX 2060 with 6 GB GDDR6 for gaming graphics
  • Dual DDR4-3200 SODIMM slots up to 64 GB for memory flexibility
  • Two M.2 slots supporting NVMe or SATA SSDs for storage choice
  • 5 Gb Ethernet, Wi-Fi 6E AX411 and Bluetooth 5.2 for fast connectivity

Caractéristiques

BrandIntel
SeriesNUC (Next Unit of Computing)
Modelphantom canyon
ColorBlack
CPU TypeIntel 11th generation Core
CPU SocketCore i7 1165G7
FSB2.8 GHz
Memory installedNo Memory
Memory slot2 x 288Pin DIMM
Memory Type SupportedDDR4 3200
Max Memory Supported64GB
Dual Channel Memory SupportedYes
PCI Express 3.0 x161 x PCI Express 3.0 x16
OtherSDXC slot supports UHS-II 1×M.2 22×80/110 interface, support PCIE 3.0 NVME 1×M.2 22×80 interface, support PCIE 3.0 NVME or SATA 3 solid state drive
Storage InstalledNo Hard Drive
M.2 Slot2 x M.2
Discrete Graphic CardNVIDIA GeForce RTX 2060
Integrated GraphicsIntel Iris X Core Graphics
Onboard AudioAudio chip supports 7.1 surround sound (via HDMI or MiniDP)
Channel7.1 Channel
LANIntel i225-LM RJ45
Max LAN Speed2.5Gbps
Wireless LANIntel AX201, WiFi6
BluetoothYes
IrDAYes
Front USB2
Front Audio Ports1 jacks
Front S/PDIF InYes
Front S/PDIF OutYes
Card ReaderYes
Other Front PortsThunderbolt 3
HDMI1
DisplayPort1 x Mini DisplayPort
Thunderbolt 3Yes
Rear USB4
RJ451
Power Supply19V, 230w
Dimensionssize 221*142*42mm
Weight1.6 Kg

Questions sur cet article

What DDR4 SO-DIMM length and pin count do the two 288-pin slots accept?

The board has two 288-pin DDR4 3200 SO-DIMM slots supporting up to 64 GB in dual-channel mode.

Which screw length should I use when securing an M.2 2280 NVMe drive in the 22×80 slot?

The M.2 2280 slot uses a standard 3 mm standoff; insert the drive at an angle, press down, and fasten the single retaining screw.

When should the 230 W 19 V power adapter be replaced if the system becomes unstable under load?

Replace the 230 W 19 V adapter if the mini PC throttles or shuts down during sustained GPU and CPU workloads.
