Mean Well HLG-240H-24 24V 10A 240W LED Switching Power Supply

240 W LED Driver for Indoor and Outdoor Lighting

The Mean Well HLG-240H-24 is a 24 V, 10 A switching power supply designed for LED lighting and street lighting applications. It accepts a universal AC input up to 305 VAC and delivers 240 W through a single output. The IP67 and IP65 rated enclosure suits both indoor and outdoor installations. It meets Type HL requirements for Class I, Division 2 hazardous locations.

Upgrade from Lower-Efficiency or Unsealed Supplies

Replacing an unsealed or lower-efficiency driver with this unit adds active PFC and up to 94% efficiency, reducing waste heat and improving power factor. The jump is worth it when installations demand IP67 or IP65 ingress protection, 4 kV surge immunity per IEC 61000-4-5, or adjustable output current for precise LED drive. Builders needing only basic indoor coverage without dimming or surge rating may not require this specification.

Convection-Cooled Stability Under Continuous Load

Cooling relies on free air convection, so sustained output depends on ambient airflow rather than forced fans. The built-in protections — short circuit, over current, over voltage and over temperature — maintain safe operation during prolonged use. High efficiency up to 94% minimises internal heat rise, supporting reliable performance in sealed outdoor enclosures where active cooling is impractical.
