White mid-tower case with tempered glass side panel and mesh front panel

NZXT

NZXT CM-H72FW-01 H7 Flow White PC Case

SKU CH-EWGV-4PYM2 MPN CM-H72FW-01

Mid-tower ATX case with vertical PSU layout supporting three bottom fans for direct GPU airflow, high-performance mesh panels, three pre-installed 120 mm front fans.

  • Motherboard CompatibilityE-ATX (Up to 27.7mm), ATX, Micro-ATX, Mini-ITX
  • ColorWhite
  • Case MaterialSGCC Steel, Ultra-clear Tempered Glass
  • TypeATX Mid Tower
  • Side Panel1 x Side Tempered Glass Panel
  • Dust FiltersHigh Performance Mesh

Options H7 Flow White (2024)

Les versions barrées existent, mais ne sont pas disponibles ici.

  • Supports E-ATX boards up to 27.7 mm wide
  • Three 120 mm front fans included for instant airflow
  • Fits 410 mm graphics cards and 185 mm CPU coolers
  • Vertical PSU layout allows three 120 mm bottom fans
  • Front USB 3.2 Gen 2 Type-C plus two Type-A ports

Mid-tower airflow case for GPU-focused builds

The NZXT H7 Flow (2024) is a white ATX mid-tower built around a vertical PSU layout that makes room for three bottom 120 mm fans to push air directly toward the graphics card. It accepts E-ATX boards up to 27.7 mm thick, plus ATX, Micro-ATX and Mini-ITX. Three F120Q 120 mm fans come pre-installed at the front, and the side panel is a single piece of ultra-clear tempered glass.

Drive capacity and cooling headroom

Two fixed and two removable 3.5-inch bays plus four 2.5-inch mounts give room for multiple storage drives. The front fits radiators up to 420 mm, the top up to 360 mm and the rear up to 140 mm. A graphics card up to 410 mm long clears the interior, while CPU cooler height stops at 185 mm. The power-supply cavity takes units up to 200 mm deep.

Front-panel I/O and mesh airflow limits

The top panel carries two USB 3.2 Gen 1 Type-A ports, one USB 3.2 Gen 2 Type-C port and a headset audio jack. High-performance mesh wraps the front, top and bottom to maximise intake and exhaust while filtering dust. Seven expansion slots support full-length add-in cards. Overall dimensions are 19.49 x 8.46 x 17.91 inches.

Points forts

  • Supports E-ATX boards up to 27.7 mm wide
  • Three 120 mm front fans included for instant airflow
  • Fits 410 mm graphics cards and 185 mm CPU coolers
  • Vertical PSU layout allows three 120 mm bottom fans
  • Front USB 3.2 Gen 2 Type-C plus two Type-A ports

Caractéristiques

Motherboard CompatibilityE-ATX (Up to 27.7mm), ATX, Micro-ATX, Mini-ITX
ColorWhite
Case MaterialSGCC Steel, Ultra-clear Tempered Glass
TypeATX Mid Tower
Side Panel1 x Side Tempered Glass Panel
Dust FiltersHigh Performance Mesh
Front Ports2 x USB 3.2 Gen 1 Type-A, 1 x USB 3.2 Gen 2 Type-C, 1 x Audio,
BrandNZXT
ModelCM-H72FW-01
Part NumberCM-H72FW-01
Internal 3.5" Drive Bays2 + 2
Internal 2.5" Drive Bays4
Expansion Slots7
Fan OptionsFront: 3 x 120 mm / 3 x 140 mm (3 x F120Q included)
Top: 3 x 120 mm / 2 x 140 mm
Bottom: 3 x 120 mm
Rear: 1 x 120 mm / 1 x 140 mm
Fan Specs
Model: F120Q Airflow Fan (Case Version)
Speed: 1,350 ± 150 RPM
Airflow: 60.2 CFM
Static Pressure: 1.05 mm-H2O
Noise: 24.1 dBA
Fan Connector: 3-pin
Pre-installed FansFront - 3 x 120mm
Radiator OptionsFront: Up to 420 mm
Top: Up to 360 mm
Rear: Up to 140 mm
Max GPU Length410 mm
Max CPU Cooler Height185 mm
Max PSU Length200 mm
Dimensions19.49" x 8.46" x 17.91"
FeaturesThe H7 Flow maintains a classic mid-tower look while enabling direct GPU cooling with bottom fan support. Ultra-fine perforation on the panels maximizes airflow. Includes 3 x 120mm fans.
Accommodates up to 420mm radiators in the front, 360mm radiators up top, plus a 10-fan capacity to meet the cooling needs of any build.
Crafted from durable steel and tempered glass panels. Rigorously tested to ensure long-lasting performance and appearance over the years.
Experience simplified building with an intuitive cable management system and tool-less panel access. Supports both ATX and EATX m
Poids d’expédition14.38 kg
Dimensions du colis635 × 569 × 325 mm

Autres versions de ce modèle

3 de plus dans cette gamme

Même famille, mémoire, ventirad ou fréquence différents — comparez avant de vous décider.

Questions sur cet article

Will my E-ATX motherboard fit if it is wider than 27.7 mm?

The case supports E-ATX boards up to 27.7 mm wide; anything wider will not fit.

Can I install a 360 mm radiator in the top and a 420 mm radiator in the front at the same time?

Yes, the top supports up to 360 mm and the front up to 420 mm simultaneously.

Do I need to buy extra fans for the bottom mounts to cool my graphics card?

Three 120 mm fans are included at the front; bottom mounts are optional and fans are not included for them.
