Thin rectangular E3.S enterprise SSD with silver metal casing and gold edge connector

Solidigm

Solidigm D5-P5336 15.36TB E3.S 7.5mm PCIe 4.0 enterprise SSD SBFPFABV153TOP1

SKU CH-2EEW-XQZZ0 MPN SBFPFABV153TOP1

E3.S 7.5mm enterprise SSD with 15.36TB QLC 3D NAND, PCIe 4.0, 7000 MBps read and 3000 MBps write

  • Form FactorE3.S 7.5mm
  • Capacity15.36TB
  • Memory Components192 L QLC 3D NAND
  • InterfacePCI-Express 4.0
  • Max Sequential ReadUp to 7000 MBps
  • Max Sequential WriteUp to 3000 MBps

Option 15.36TB E3.S Opal

Voir les 21 autres configurations

Les versions barrées existent, mais ne sont pas disponibles ici.

  • Massive 15.36 TB capacity fits huge datasets in one E3.S slot
  • PCIe 4.0 x4 interface delivers up to 7000 MB/s sequential read speed
  • 192-layer QLC 3D NAND enables high density with 0.51 DWPD endurance
  • Opal security protects data at rest without host overhead
  • 2 000 000-hour MTBF and 1000 G shock rating ensure enterprise reliability

Enterprise capacity drive

The Solidigm D5-P5336 delivers 15.36TB in an E3.S 7.5mm form factor using PCI-Express 4.0 and 192 L QLC 3D NAND. It targets data-centre workloads that need high density read performance with 0.51 DWPD endurance.

Thermals and power profile

Idle power sits at 5W while active consumption reaches 21W within a 0°C to 70°C operating window. The drive tolerates 1,000 G shock at 0.5 msec and 2.17 GRMS operating vibration.

Build integration

The E3.S 7.5mm module fits standard hot-plug bays and weighs approximately 90g. Opal security support is included for hardware-based encryption without additional software overhead.

Points forts

  • Massive 15.36 TB capacity fits huge datasets in one E3.S slot
  • PCIe 4.0 x4 interface delivers up to 7000 MB/s sequential read speed
  • 192-layer QLC 3D NAND enables high density with 0.51 DWPD endurance
  • Opal security protects data at rest without host overhead
  • 2 000 000-hour MTBF and 1000 G shock rating ensure enterprise reliability

Caractéristiques

BrandSolidigm
ModelD5-P5336
Part NumberSBFPFABV153TOP1
Form FactorE3.S 7.5mm
Capacity15.36TB
Memory Components192 L QLC 3D NAND
InterfacePCI-Express 4.0
Max Sequential ReadUp to 7000 MBps
Max Sequential WriteUp to 3000 MBps
4KB Random Read1005000 IOPS (4K, QD256)
4KB Random Write29900 IOPS (16K, QD256)
Endurance0.51 DWPD (16K RW) / 14.11 PBW
MTBF2,000,000 hours
SecurityOpal
Power Consumption (Idle)5W
Power Consumption (Active)21W
Operating Temperature0°C ~ +70°C
Max Shock Resistance1,000 G (Max) at 0.5 msec
Max Vibration ResistanceOperating: 2.17 GRMS (5 - 700 Hz) Max
Non-Operating: 3.13 GRMS (5 - 800 Hz) Max
Weight90g +/- 10g
Poids d’expédition0.17 kg
Dimensions du colis140 × 110 × 17 mm

Autres versions de ce modèle

5 de plus dans cette gamme

Même famille, mémoire, ventirad ou fréquence différents — comparez avant de vous décider.

Questions sur cet article

How do I install the E3.S 7.5mm drive and which step is often missed?

Slide the drive into an E3.S 7.5mm bay until the PCIe 4.0 x4 connector seats fully, then secure the retention screw; the step most often missed is torquing that screw to the chassis specification so the drive cannot unseat under vibration.

What maintenance or replacement will the 15.36TB QLC drive need later?

The drive has no user-serviceable parts; plan replacement once the 14.11 PBW endurance budget or the 0.51 DWPD rating is reached, which the SMART attributes will report as the media approaches end of life.

What limit appears first during sustained writes on this PCIe 4.0 SSD?

Sustained sequential writes are capped at 3000 MBps and the SLC cache will exhaust, after which write throughput drops toward the native QLC rate while the controller manages the 0.51 DWPD endurance budget.
