Rectangular green circuit board with gold edge connector and black controller chips

Solidigm

Solidigm SBFPFABV307TOP1 D5-P5336 30.72TB E3.S 7.5mm PCIe 4.0 enterprise SSD

SKU CH-GB3F-5V53D MPN SBFPFABV307TOP1

Enterprise E3.S 7.5mm drive stores 30.72TB on 192-layer QLC NAND with PCIe 4.0 speeds up to 7000 MB/s read and 0.56 DWPD endurance

  • Form FactorE3.S 7.5mm
  • Capacity30.72TB
  • Memory Components192 L QLC 3D NAND
  • InterfacePCI-Express 4.0
  • Max Sequential ReadUp to 7000 MBps
  • Max Sequential WriteUp to 3000 MBps

Option 30.72TB E3.S Opal

Voir les 21 autres configurations

Les versions barrées existent, mais ne sont pas disponibles ici.

  • Massive 30.72 TB capacity fits dense server racks
  • E3.S 7.5 mm form factor enables high-density deployments
  • PCIe 4.0 x4 delivers 7000 MB/s sequential reads
  • 192-layer QLC 3D NAND balances cost and endurance
  • Opal encryption secures data at rest

Enterprise QLC drive for read-heavy workloads

The Solidigm D5-P5336 packs 30.72TB into an E3.S 7.5mm module built on 192-layer QLC 3D NAND. It targets data-centre operators who need maximum capacity per slot for sequential read workloads such as content delivery, analytics or warm-tier storage. The drive is new and rated for 0.56 DWPD over 31.55 PBW.

PCIe 4.0 x4 interface with Opal security

The single spec that decides fit is the PCI-Express 4.0 x4 connection, delivering up to 7000 MBps sequential read and 3000 MBps sequential write. Random performance reaches 1005000 IOPS read and 39200 IOPS write at queue depth 256. Opal encryption is supported for data-at-rest compliance.

E3.S hot-plug bay with 23W active power

Installation requires an E3.S 7.5mm hot-plug cage and a backplane wired for PCIe 4.0 x4. Active power draw peaks at 23W, so the chassis cooling and power budget must accommodate that load. The 90g weight and 1000 G shock rating suit dense vibration-prone racks, while the 0°C to 70°C range covers standard server intake temperatures.

Points forts

  • Massive 30.72 TB capacity fits dense server racks
  • E3.S 7.5 mm form factor enables high-density deployments
  • PCIe 4.0 x4 delivers 7000 MB/s sequential reads
  • 192-layer QLC 3D NAND balances cost and endurance
  • Opal encryption secures data at rest

Caractéristiques

BrandSolidigm
ModelD5-P5336
Part NumberSBFPFABV307TOP1
Form FactorE3.S 7.5mm
Capacity30.72TB
Memory Components192 L QLC 3D NAND
InterfacePCI-Express 4.0
Max Sequential ReadUp to 7000 MBps
Max Sequential WriteUp to 3000 MBps
4KB Random Read1005000 IOPS (4K, QD256)
4KB Random Write39200 IOPS (16K, QD256)
Endurance0.56 DWPD (16K RW) / 31.55 PBW
MTBF2,000,000 hours
SecurityOpal
Power Consumption (Idle)5W
Power Consumption (Active)23W
Operating Temperature0°C ~ +70°C
Max Shock Resistance1,000 G (Max) at 0.5 msec
Max Vibration ResistanceOperating: 2.17 GRMS (5 - 700 Hz) Max
Non-Operating: 3.13 GRMS (5 - 800 Hz) Max
Weight90g +/- 10g
Poids d’expédition0.17 kg
Dimensions du colis140 × 110 × 17 mm

Autres versions de ce modèle

5 de plus dans cette gamme

Même famille, mémoire, ventirad ou fréquence différents — comparez avant de vous décider.

Questions sur cet article

What does 30.72 TB capacity mean for daily workloads?

30.72 TB provides room for large datasets, analytics tables, or object stores without spanning multiple drives.

What does PCIe 4.0 x4 mean for throughput limits?

PCIe 4.0 x4 sets the bus ceiling; the drive reaches 7000 MBps read and 3000 MBps write within that limit.

Will the E3.S 7.5 mm form factor fit my server bay?

The drive uses the E3.S 7.5 mm standard and weighs 90 g, so it fits bays and cages built to that specification.
