Silver 2U rack server with twelve front 3.5-inch drive bays

Supermicro

Supermicro SYS-6029U-E1CR4T 2x Xeon Gold 6130 2.1GHz 16C 512GB DDR4 12x 3.5" rack server

SKU CH-EXSS-MW8BH

A 2U rack server with dual Xeon Gold 6130 processors, 512GB DDR4, 12 hot-swap 3.5" bays, MegaRAID 9361-8i and four 10GBase-T ports

  • Rack Height1U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • CPU Speed2.10 GHz
  • CPU SocketLGA 3647
  • Number of CPU Cores16-Core Processor
  • Dual 16-core Xeon Gold 6130 CPUs deliver 32 threads for heavy compute
  • 512GB DDR4-2666 ECC memory supports large virtualisation workloads
  • MegaRAID 9361-8i controller enables RAID 0/1/5/6/10/50/60 with 1GB cache
  • 12 hot-swap 3.5" bays provide high-density SAS/SATA storage capacity
  • Four 10GBase-T ports plus dedicated IPMI 2.0 LAN ensure fast remote management

Dual Xeon 16-core server for virtualization

The Supermicro SYS-6029U-E1CR4T is a 2U rackmount system with two Intel Xeon Gold 6130 processors running at 2.1 GHz with 16 cores each. It ships with 512 GB of DDR4-2666 ECC registered memory across 16 modules. The platform targets virtualization, hyper-converged storage and cloud workloads that demand high core counts and large memory capacity.

PCIe 3.0 lanes and 12 Gb/s SAS define storage limits

The installed MegaRAID 9361-8i controller provides eight ports of SAS 12 Gb/s connectivity with 1 GB cache and battery backup. Twelve front 3.5-inch bays accept SATA or SAS drives; four of those bays can support NVMe SSDs when a compatible add-on card is fitted. Expansion includes two PCIe 3.0 x16 slots, four PCIe 3.0 x8 slots full-height and one low-profile PCIe 3.0 x8 slot.

Redundant titanium power

Dual 1000-watt titanium-efficiency power supplies are hot-swappable for continuous uptime. All twelve drive bays support hot-plug replacement without tools. A dedicated RJ45 port enables IPMI 2.0 remote management with virtual media and KVM-over-LAN. Front bezel and rack rails are not included in the shipment.

Points forts

  • Dual 16-core Xeon Gold 6130 CPUs deliver 32 threads for heavy compute
  • 512GB DDR4-2666 ECC memory supports large virtualisation workloads
  • MegaRAID 9361-8i controller enables RAID 0/1/5/6/10/50/60 with 1GB cache
  • 12 hot-swap 3.5" bays provide high-density SAS/SATA storage capacity
  • Four 10GBase-T ports plus dedicated IPMI 2.0 LAN ensure fast remote management

Caractéristiques

BrandSUPERMICRO
SeriesCSE-829U2E1C4-R1K02-T-X11DPU
ModelSYS-6029U-E1CR4T
Rack Height1U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
CPU Speed2.10 GHz
CPU SocketLGA 3647
Number of CPU Cores16-Core Processor
# of Processors InstalledGold 6130
Installed Memory Size512GB
Storage ControllerLSI MegaRAID 9361-8i Controller
HDD InterfaceSATA/SAS
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
GPU TypeMatrox G200
Video Memory8MB
Ethernet Controller4x 10GBase-T ports via Intel X710 (AOC-2UR66-i4XTF)
Management PortRJ 45
Features12 x 3.5" SATA/SAS Hot-Plug Drive Bays

Questions sur cet article

Should I pick the 2-processor configuration or add a second CPU later?

The server arrives with two Xeon Gold 6130 processors already installed, each running at 2.1 GHz with 16 cores.

What does the 512 GB DDR4-2666 memory mean for my workloads?

You get 16 registered ECC modules of 32 GB at 2666 MHz, filling 16 of the 24 DIMM slots and leaving room to grow to the platform maximum.

How fast are the four 10GBase-T ports in practice?

The Intel X710 controller provides four RJ-45 ports at 10 Gb/s each, connected through a PCIe 3.0 x8 add-in card for full line-rate throughput.
