Green rectangular M.2 2280 circuit board with black controller and gold edge connector

Team Group

Team Group MP33 PRO 1TB M.2 2280 PCIe 3.0 x4 NVMe 1.3 internal SSD TM8FPD001T0C101

SKU CH-X5ZE-J04EG MPN TM8FPD001T0C101

M.2 2280 drive with 1TB of 3D NAND storage delivers up to 2100 MBps read and 1700 MBps write over PCIe 3.0 x4 NVMe 1.3 for fast loads and 240TB endurance

  • Device TypeInternal Solid State Drive (SSD)
  • Used ForConsumer
  • Form FactorM.2 2280
  • Capacity1TB
  • Memory Components3D NAND
  • InterfacePCIe 3.0 x4 with NVMe 1.3

Options 1TB MP33 PRO

  • PCIe 3.0 x4 interface delivers up to 2100 MBps sequential read
  • NVMe 1.3 protocol provides up to 1700 MBps sequential write
  • 220,000 IOPS random read accelerates game and app loading
  • 200,000 IOPS random write speeds up content creation tasks
  • 240 TBW and 2,000,000-hour MTBF ensure long-term drive reliability

Team Group MP33 PRO 1TB NVMe SSD

The Team Group MP33 PRO is a 1TB internal solid state drive built for consumer workloads. It uses a PCIe 3.0 x4 interface with NVMe 1.3 protocol and 3D NAND flash. Sequential reads reach up to 2100 MBps and writes up to 1700 MBps, with random 4K performance of 220,000 read and 200,000 write IOPS. The drive is rated for 240 TBW and a 2,000,000 hour MTBF.

Easy M.2 2280 installation for most builds

The drive follows the standard M.2 2280 form factor and slots directly into a compatible motherboard M key socket. No cables or drive bays are required. Common issues include inserting the module at the wrong angle, failing to secure the retention screw, or using a slot that only supports SATA signalling. Ensure the BIOS is set to NVMe mode and that the latest firmware is applied for full compatibility.

Check motherboard M key slot and PCIe 3.0 support

Before ordering, verify that your motherboard has an M.2 slot wired for PCIe 3.0 x4 NVMe operation. Some older boards share bandwidth with SATA ports or limit the link to PCIe 2.0 speeds. Confirm the slot accepts 2280 length modules and that your system can boot from NVMe if this will be the primary drive. Operating temperature range is 0°C to 70°C, so ensure adequate airflow in compact chassis.

Points forts

  • PCIe 3.0 x4 interface delivers up to 2100 MBps sequential read
  • NVMe 1.3 protocol provides up to 1700 MBps sequential write
  • 220,000 IOPS random read accelerates game and app loading
  • 200,000 IOPS random write speeds up content creation tasks
  • 240 TBW and 2,000,000-hour MTBF ensure long-term drive reliability

Caractéristiques

BrandTeam Group
SeriesMP33 PRO
ModelTM8FPD001T0C101
Part NumberTM8FPD001T0C101
Device TypeInternal Solid State Drive (SSD)
Used ForConsumer
Form FactorM.2 2280
Capacity1TB
Memory Components3D NAND
InterfacePCIe 3.0 x4 with NVMe 1.3
ProtocolNVMe 1.3
Cache0MB
Max Sequential ReadUp to 2100 MBps
Max Sequential WriteUp to 1700 MBps
4KB Random ReadUp to 220,000 IOPS
4KB Random WriteUp to 200,000 IOPS
Terabytes Written (TBW)240TB
MTBF2,000,000 hours
FeaturesOnce you've used the high-speed PCIe, you will never go back
High-speed reading and writing for more efficiency
Stable and durable - Not only fast, but reliable
Up to 2TB of storage capacity
Operating Temperature0°C ~ +70°C
Storage Temperature-40°C ~ +85°C
Operating HumidityRH 90% under 40 celsius degree
Max Shock Resistance1,500G / 0.5 ms
Max Vibration Resistance80-2,000 Hz / 20G
Height3.80mm
Width22.00mm
Depth80.00mm
Weight6.00g
Poids d’expédition0.06 kg
Dimensions du colis123 × 90 × 7 mm

Autres versions de ce modèle

5 de plus dans cette gamme

Même famille, mémoire, ventirad ou fréquence différents — comparez avant de vous décider.

Questions sur cet article

How can I verify the MP33 PRO 1TB is running at its rated PCIe 3.0 x4 NVMe 1.3 speeds after installation?

Use CrystalDiskMark or a similar benchmark tool to confirm sequential read near 2100 MBps and sequential write near 1700 MBps, with 4K random read around 220,000 IOPS and random write around 200,000 IOPS.

What comes in the box with the TM8FPD001T0C101 and what must I supply myself?

The package contains the M.2 2280 SSD only; you must provide a compatible M.2 slot with PCIe 3.0 x4 support, an M.2 mounting screw, and a heatsink if your motherboard lacks one.

Which MP33 PRO capacity should I choose for a balance of endurance and space?

The 1TB model delivers 240 TBW and up to 2100 MBps read and 1700 MBps write, matching the series' rated endurance and performance for typical consumer workloads.
