Ubiquiti Networks
Ubiquiti Networks UDR7-US wireless router
A desktop cloud gateway with integrated WiFi 7, a PoE switch, and 64 GB microSD storage for NVR
- WiFi GenerationWi-Fi 7
- Wireless Standard802.11be (WiFi 7), 802.11ax (WiFi 6/6E), 802.11ac (WiFi 5),
- SecurityStateful Firewall Application-Aware Layer 7 Firewall DPI & T
- WPAWPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3/PPSK)
- WAN Ports(1) 10G SFP+ (1) 2.5 GbE RJ45
- LAN Ports3 x 2.5G
- WiFi 7 tri-band coverage across 160 m² for fast whole-home wireless
- 10 Gbps SFP+ and 2.5 GbE WAN ports deliver high-speed internet connectivity
- Built-in 64 GB microSD stores UniFi Protect footage without extra hardware
- Quad-core ARM processor at 1.5 GHz handles routing, firewall and VPN tasks
- One PoE-enabled 2.5 GbE LAN port powers an access point or camera directly
Desktop 10G Cloud Gateway with WiFi 7
The Ubiquiti Dream Router 7 is a desktop gateway that combines a 10G SFP+ WAN port, a 2.5 GbE RJ45 WAN port and four 2.5 GbE LAN ports with integrated WiFi 7. It targets small businesses and advanced home users who want UniFi application management, license-free SD-WAN and a pre-installed 64 GB microSD card for NVR storage in one device.
Setup and common issues
The unit ships with a power adapter and the microSD card already installed, so initial power-up and adoption through the UniFi controller are straightforward. One PoE-enabled LAN port can power a compatible access point or camera without an extra injector. Builders who need more than four LAN ports or a second 10G WAN connection will need an external switch or a different gateway.
Capacity and headroom
The router handles up to 300 simultaneous clients and manages 30-plus UniFi devices with IDS/IPS throughput of 2.3 Gbps. Wireless throughput reaches 5.7 Gbps on 6 GHz, 4.3 Gbps on 5 GHz and 688 Mbps on 2.4 GHz across a 160 m² coverage area. Environments that require higher multi-gig aggregate switching or larger NVR retention will outgrow the built-in ports and the 64 GB storage.
Points forts
- WiFi 7 tri-band coverage across 160 m² for fast whole-home wireless
- 10 Gbps SFP+ and 2.5 GbE WAN ports deliver high-speed internet connectivity
- Built-in 64 GB microSD stores UniFi Protect footage without extra hardware
- Quad-core ARM processor at 1.5 GHz handles routing, firewall and VPN tasks
- One PoE-enabled 2.5 GbE LAN port powers an access point or camera directly
Caractéristiques
| Brand | Ubiquiti Networks |
|---|---|
| Model | Dream Router 7 |
| Part Number | UDR7-US |
| WiFi Generation | Wi-Fi 7 |
| Wireless Standard | 802.11be (WiFi 7), 802.11ax (WiFi 6/6E), 802.11ac (WiFi 5), 802.11n, 802.11g, 802.11b, 802.11a |
| Security | Stateful Firewall Application-Aware Layer 7 Firewall DPI & Traffic Identification Zone-Based Firewall Advanced Filtering (Regions, Domains, Apps) Content Filtering Intrusion Prevention (IPS/IDS) Ad Blocking IDS/IPS Signatures: 20,000+ with CyberSecure VLAN/Subnet-based Traffic Segmentation |
| WPA | WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3/PPSK) |
| WAN Ports | (1) 10G SFP+ (1) 2.5 GbE RJ45 |
| LAN Ports | 3 x 2.5G |
| LEDs | System |
| Buttons | (1) Factory reset |
| Wireless Data Rates | Supported Data Rates 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps 802.11b: 1, 2, 5.5, 11 Mbps 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps 802.11n: 6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40) 802.11ac (WiFi 5): 6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80/160) 802.11ax (WiFi 6/6E): 7.3 Mbps to 2.4 Gbps (MCS0 - MCS11 NSS1/2, HE 20/40/80/160) 802.11be (WiFi 7): 7.3 Mbps to 5.7 Gbps (MCS0 - MCS13 NSS1/2, EHT 20/40/80/160/240/320) |
| Operating Range | Coverage Area 160 m2 (1,750 ft2) |
| Frequency Band | 2.4 GHz / 5 GHz / 6 GHz |
| Antenna | MIMO 6 GHz: 2 x 2 (DL/UL MU-MIMO) 5 GHz: 2 x 2 (DL/UL MU-MIMO) 2.4 GHz: 2 x 2 (DL/UL MU-MIMO) Antenna Gain 6 GHz: 6 dBi 5 GHz: 7 dBi 2.4 GHz: 5 dBi |
| Transmitted Power | Max. TX Power 6 GHz: 24 dBm 5 GHz: 26 dBm 2.4 GHz: 23 dBm |
| Storage Capacity | Pre-installed 64GB microSD for NVR |
| Interface | WAN: (1) 10G SFP+ (1) 2.5 GbE RJ45 LAN: (4) 2.5 GbE RJ45 |
| VPN support | License-Free SD-WAN Site-to-Site VPN: Site Magic IPsec OpenVPN VPN Server: Identity Endpoint One-Click VPN Teleport Zero-Configuration VPN WireGuard OpenVPN L2TP VPN Client: OpenVPN WireGuard |
| Power Supply | Universal AC input, 100-240V AC, 1.5A Max, 50/60 Hz |
| Wireless Adapter included | No |
| Memory | 3 GB |
| Dimensions | 110 Diameter x 184.1 mm (4.3" x 7.3") |
| Weight | 1.1 kg (2.4 lbs.) |
| Temperature | -10 to 40° C (14 to 104° F) |
| Humidity | 5 to 95% noncondensing |
| Special Features | VPN |
| Features | Multi-WAN Load Balancing Dynamic Routing: OSPF Advanced QoS Multicast DNS (mDNS) Advanced NAT (SNAT / DNAT / Masquerade / NAT Pooling / 1-to-1 NAT) Integrated RADIUS Server RADIUS over TLS (RadSec) Additional Internet Failover with UniFi LTE Backup Internet Quality and Outage Reporting MAC Address Table Size: 2,000 Policy-based WAN and VPN Routing Customizable DHCP Server IPv6 ISP Support IGMP Proxy Virtual Network Override |
| Package Contents | 1x Dream Router 7, 1x Power Adapter & Cable, 1x 64GB microSD Card |
| Poids d’expédition | 1.70 kg |
| Dimensions du colis | 284 × 157 × 152 mm |
Questions sur cet article
How can I confirm the Dream Router 7 is operating correctly after installation?
The front System LED shows the gateway status; open the UniFi Network application to verify the 10G SFP+ WAN link, both 2.5 GbE WAN/LAN ports, and the three 2.5 GbE LAN ports are all green and passing traffic.
What ships with the Dream Router 7 and what must I source separately?
The box contains the gateway, a universal 100-240V AC power adapter with cable, and a pre-installed 64 GB microSD card for NVR storage; any 10G SFP+ transceiver module and Ethernet patch cords are not included.
Which Dream Router 7 variant should I choose for my deployment?
Only the UDR7-US model is listed — a desktop 10G cloud gateway with integrated WiFi 7, a 15 W PoE switch port, and 64 GB microSD storage — so select this single SKU.
