Eight green 240-pin DDR3L RDIMM modules in a row

OWC

OWC 128GB (8x16GB) DDR3L 1600 CL11 ECC Registered RDIMM memory upgrade

SKU CH-F45G-YZDR6

128 GB DDR3L ECC registered kit of eight 16 GB modules for Cisco UCS servers

  • Capacity128GB (8 x 16GB)
  • Type240-Pin DDR3L ECC RDIMM
  • SpeedDDR3L 1600 (PC3L 12800)
  • CAS LatencyCL11
  • Voltage1.35V
  • ECCYes

Capacity 128GB (8 x 16GB)

  • ECC registered design prevents data errors in critical workloads
  • 128 GB kit (8 × 16 GB) scales Cisco UCS servers
  • DDR3L 1600 CL11 at 1.35 V reduces power draw
  • 2Rx4 240-pin RDIMM matches Cisco part numbers UCSMR1X162RYA, UCSMR1X162RYARF, UCSMR2X162RYE
  • Validated for Cisco UCS B200 M3, B22 M3, B420 M3, C22 M3, C220 M3

Cisco UCS memory upgrade kit

This 128GB kit contains eight 16GB DDR3L 1600 CL11 ECC registered RDIMMs built for Cisco UCS B200 M3, B22 M3, B420 M3, C22 M3 and C220 M3 servers. Each module runs at 1.35V with a 2Rx4 organisation and fits the 240-pin DDR3L slots used by those platforms. The kit replaces Cisco part numbers UCSMR1X162RYA, UCSMR1X162RYARF and UCSMR2X162RYE.

Replaces Cisco factory DIMMs

The modules drop into the same 240-pin sockets as the original Cisco memory and deliver the same DDR3L 1600 speed and CL11 timing. The upgrade is worthwhile when the server needs more capacity for virtualisation or larger datasets and the memory controller supports registered ECC DIMMs. It will not work in standard desktop boards or in systems that require unbuffered or load-reduced memory.

DDR3L platform limits

DDR3L tops out at 1600 MT/s and 1.35V, so bandwidth and density are capped by the memory controller in these Cisco UCS models. Registered ECC adds a clock cycle of buffering, which helps signal integrity at high DIMM counts but prevents mixing with unbuffered or LRDIMM modules. Buyers who need higher speeds, greater densities or newer memory generations must move to a later server platform.

特長

  • ECC registered design prevents data errors in critical workloads
  • 128 GB kit (8 × 16 GB) scales Cisco UCS servers
  • DDR3L 1600 CL11 at 1.35 V reduces power draw
  • 2Rx4 240-pin RDIMM matches Cisco part numbers UCSMR1X162RYA, UCSMR1X162RYARF, UCSMR2X162RYE
  • Validated for Cisco UCS B200 M3, B22 M3, B420 M3, C22 M3, C220 M3

仕様

BrandOWC
Part Number1R6T32R4128K
Capacity128GB (8 x 16GB)
Type240-Pin DDR3L ECC RDIMM
SpeedDDR3L 1600 (PC3L 12800)
CAS LatencyCL11
Voltage1.35V
ECCYes
Buffered/RegisteredRegistered
Rank2Rx4
Heat SpreaderNo
Compatible SystemCisco UCS B200 M3
Cisco UCS B22 M3
Cisco UCS B420 M3
Cisco UCS C22 M3
Cisco UCS C220 M3

このモデルの他のバージョン

同シリーズにさらに 5点

同じファミリーで、メモリ・クーラー・クロックが異なります — 購入前に比較してください。

この商品に関する質問

Does the 240-pin DDR3L RDIMM fit the Cisco UCS B200 M3 memory slots?

Yes, the 240-pin DDR3L ECC Registered DIMM is designed for the Cisco UCS B200 M3 and the other listed UCS M3 servers.

What is the correct way to install the eight 16 GB modules in a Cisco UCS C220 M3?

Populate all eight slots following the server's memory population guide; the common error is mixing these registered DIMMs with unbuffered or load-reduced modules.

When should the 1.35 V DDR3L 1600 CL11 kit be replaced in a Cisco UCS B420 M3?

Replace the kit only if memory errors appear or a firmware update requires a different specification; the modules have no moving parts or scheduled service interval.
