Black rectangular network video recorder with front panel indicators and rear ports, 330 by 48 by 310 millimetres

Reolink

Reolink RLN36 36CH Network Video Recorder

SKU CH-9Q50-22T7K

Records up to 36 Reolink PoE cameras at 12MP each with H.265 compression, dual HDMI and VGA outputs, three SATA bays for 48TB total storage, and two-way audio

  • Channel36 Channel
  • Supported ProtocolsHTTP, TCP/IP, UDP, DHCP, P2P, UPNP, RTMP, SMTP, SSL/TLS, DNS
  • Video InputSupports up to 36 channels of IPC access; each channel up to
  • Video Output• HDMI: 3840x2160, 1920x1080, 1280x1024, 1280x720, 1024x768
  • Audio InputBuilt-in audio in & out ports
  • Compression FormatH.265, H.264

Channels 36 Channel

Options No HDD

  • Manages 36 camera channels simultaneously for large installations
  • Stores up to 48TB across three SATA bays for weeks of footage
  • Outputs 4K via HDMI for detailed live view and playback
  • Operates from -10°C to 55°C for reliable year-round use
  • Supports 12MP input per channel for high-resolution recording

36-Channel PoE NVR for Reolink cameras

The Reolink RLN36 is a 36-channel network video recorder built exclusively for Reolink PoE IP cameras up to 12MP resolution. It accepts 36 simultaneous camera streams and compresses them using H.265 or H.264. The unit ships without any hard drives installed and operates on a supplied DC 12V 5.4A power adapter.

Three internal SATA bays and four PoE switch uplinks

Three SATA ports each accept a single drive up to 16TB, giving a total raw capacity of 48TB. No external drive bays are present. For larger deployments the NVR can aggregate up to four PoE switches through its LAN ports, allowing 36 cameras to be distributed across switches while remaining centrally managed. HDMI and VGA outputs provide local monitoring at resolutions up to 3840x2160 and 1920x1080 respectively.

Continuous 24/7 recording at 6 Mbps per channel

With every channel recording constantly at 6 Mbps the three installed drives can retain roughly 20 days of footage before overwriting. The chassis is rated for ambient temperatures from -10°C to +45°C and humidity between 10% and 90%. Power draw stays below 10W when no drives or PoE devices are attached. Synchronous playback is limited to four channels at once.

特長

  • Manages 36 camera channels simultaneously for large installations
  • Stores up to 48TB across three SATA bays for weeks of footage
  • Outputs 4K via HDMI for detailed live view and playback
  • Operates from -10°C to 55°C for reliable year-round use
  • Supports 12MP input per channel for high-resolution recording

仕様

BrandReolink
SeriesReolink 36Ch 6K PoE NVR
ModelRLN36
Channel36 Channel
Supported ProtocolsHTTP, TCP/IP, UDP, DHCP, P2P, UPNP, RTMP, SMTP, SSL/TLS, DNS, DDNS, NTP
Video InputSupports up to 36 channels of IPC access; each channel up to 12MP input
Video Output• HDMI: 3840x2160, 1920x1080, 1280x1024, 1280x720, 1024x768
• VGA: 1920x1080, 1280x1024, 1280x720, 1024x768
Audio InputBuilt-in audio in & out ports
Compression FormatH.265, H.264
Recording TypeVideo Recorder
RemoteEdge, Firefox, Chrome, Safari
Storage InstalledNone
Max Capacity48TB
Operating SystemPC: Windows, Mac OS; Smartphone: iOS, Android
Power SupplyDC 12V/5.4A
Temperature-10°C ~+45°C (14°F~113°F);
Humidity10%~90%
Dimensions330 x 48 x 310mm
Weight2.26kg

このモデルの他のバージョン

同シリーズにさらに 2点

同じファミリーで、メモリ・クーラー・クロックが異なります — 購入前に比較してください。

この商品に関する質問

How many cameras can the RLN36 record simultaneously before hitting its channel limit?

The recorder accepts up to 36 IP camera channels, each supporting a maximum of 12MP resolution.

What is the NVR's power draw when running continuously without hard drives or PoE cameras attached?

It consumes less than 10W under those conditions, with an operating temperature range of -10°C to 55°C.

Which storage drives must be purchased separately to make the RLN36 operational?

Three SATA hard drives are required — each bay supports up to 16TB for a total of 48TB capacity.
