Silver 6U rackmount server chassis with sixty 3.5-inch hot-swap drive bays visible on the front

Shenzhen Junxiangcheng Technology Co.,

Shenzhen Junxiangcheng Technology Co., 6U Rackmount Server Chassis 60×3.5" Hot-Swap 6Gb/s Backplane

SKU CH-VS80-ZAVD8

Holds sixty 3.5″ hot-swap drives plus two 2.5″ bays in a 6U rackmount chassis with a 6 Gb/s expander backplane and seven half-height expansion slots

  • Chassis TypeRackmount
  • Form Factor6U
  • 60 hot-swap 3.5" drive bays for massive storage density
  • 6 Gb/s expander backplane with temperature control ensures reliable throughput
  • 0 mm SGCC steel construction resists fingerprints and EMI
  • Seven half-height PCI/PCIe slots plus dual 2.5" bays add flexible expansion
  • Redundant 2U power supply support with hot-swap fans maintains uptime

Shenzhen Junxiangcheng 6U Rackmount Chassis

This 6U rackmount server chassis supports E-ATX motherboards up to 13.68 by 13 inches and fits standard 19-inch racks. It is built from 1.0mm SGCC zinc-coated steel and provides three-section ball slides for installation. The unit includes system controls for power, reset, UID and status LEDs. It is designed for cloud storage, big data and security monitoring deployments.

Suited for high-density storage.

The chassis targets builders who need sixty 3.5-inch hot-swap drive bays with a 6Gb/s expander backplane using Mini-SAS SFF-8087 connectors. Two internal 2.5-inch bays and seven half-height PCIe slots support additional peripherals. Buyers requiring fewer drive bays or a smaller rack footprint should consider a different form factor. The optional 12Gb/s backplane uses SFF-8643 connectors for faster SAS/SATA connectivity.

60-bay 6Gb/s expander backplane decides fit

The defining specification is the sixty 3.5-inch hot-swap bays driven by a 6Gb/s expander backplane with temperature control and SGPIO support. This backplane uses Mini-SAS SFF-8087 interfaces and includes staggered spin-up. An optional 12Gb/s expander backplane with SFF-8643 interfaces is available. Cooling is handled by six hot-swap 12038 fans plus four 8038 fans, and power uses standard CRPS redundant supplies.

特長

  • 60 hot-swap 3.5" drive bays for massive storage density
  • 6 Gb/s expander backplane with temperature control ensures reliable throughput
  • 0 mm SGCC steel construction resists fingerprints and EMI
  • Seven half-height PCI/PCIe slots plus dual 2.5" bays add flexible expansion
  • Redundant 2U power supply support with hot-swap fans maintains uptime

仕様

Chassis TypeRackmount
Form Factor6U

この商品に関する質問

Which backplane option should I choose for this 60-bay chassis?

The standard backplane is a 6Gb/s expander with Mini-SAS SFF8087 connectors; an optional 12Gb/s expander with Mini-SAS HD SFF8643 is also available.

What does the 6Gb/s backplane rating mean once drives are installed?

It caps each SATA or SAS drive link at 6Gb/s, so even faster drives will run at that speed through the expander.

How does the Mini-SAS SFF8087 interface limit the storage connection?

Each SFF8087 cable carries four 6Gb/s lanes, so the backplane connects to the host controller over that aggregate bandwidth.
