White Mini-ITX motherboard with silver heatsinks and rear I/O shield

GIGABYTE

GIGABYTE X870I AORUS PRO ICE AMD motherboard

SKU CH-R41C-BSPDN MPN X870I AORUS PRO ICE

Mini-ITX AM5 board with DDR5 up to 9000, PCIe 5.0 x16, dual M.2, Wi-Fi 7 and 2.5GbE LAN

  • CPU Socket TypeAM5
  • CPU TypeRyzen 7000 Series / Ryzen 8000 Series / Ryzen 9000 Series
  • ChipsetAMD X870
  • Number of Memory Slots2x288pin (DDR5)
  • Memory StandardDDR5 5600 / DDR5 6000 / DDR5 6200 / DDR5 6400 / DDR5 6600 /
  • Maximum Memory Supported128GB

Option X870I AORUS PRO ICE

취소선으로 표시된 버전은 존재하지만, 이곳에서는 취급하지 않습니다.

  • Supports Ryzen 7000, 8000 and 9000 series CPUs on AM5 socket
  • Dual-channel DDR5 up to 128GB with EXPO and XMP 3.0 profiles
  • PCIe 5.0 x16 slot and M.2 connector driven directly by the CPU
  • Wi-Fi 7 and 2.5GbE LAN for fast wireless and wired networking
  • EZ-Latch M.2 and PCIe plus EZ-Debug zone simplify installation and troubleshooting

Mini-ITX AM5 platform for compact builds

The GIGABYTE X870I AORUS PRO ICE is a Mini-ITX motherboard for AMD Ryzen 7000, 8000 and 9000 series processors. It fits small-form-factor cases while keeping a full feature set. Builders who need high memory speeds and modern connectivity in a tight footprint will find it suitable.

Upgrade path from older AM5 Mini-ITX boards

Moving from an earlier AM5 Mini-ITX board adds PCIe 5.0 graphics and storage support with Ryzen 7000 or 9000 CPUs plus Wi-Fi 7 and 2.5 GbE LAN. The jump is worth it when you need faster GPU bandwidth, quicker NVMe drives or the latest wireless standard without changing case size.

PCIe 5.0 and DDR5 limits on this board

The single PCIe 5.0 x16 slot runs at x16 with Ryzen 7000 or 9000 CPUs but drops to x8 or x4 with Ryzen 8000 series chips. The CPU-linked M.2 slot supports PCIe 5.0 x4 NVMe SSDs only on those same 7000 and 9000 series processors. DDR5 memory tops out at the listed speeds up to DDR5 9000 with a maximum capacity of 128 GB.

주요 특징

  • Supports Ryzen 7000, 8000 and 9000 series CPUs on AM5 socket
  • Dual-channel DDR5 up to 128GB with EXPO and XMP 3.0 profiles
  • PCIe 5.0 x16 slot and M.2 connector driven directly by the CPU
  • Wi-Fi 7 and 2.5GbE LAN for fast wireless and wired networking
  • EZ-Latch M.2 and PCIe plus EZ-Debug zone simplify installation and troubleshooting

사양

BrandGIGABYTE
ModelX870I AORUS PRO ICE
CPU Socket TypeAM5
CPU TypeRyzen 7000 Series / Ryzen 8000 Series / Ryzen 9000 Series
ChipsetAMD X870
Number of Memory Slots2x288pin (DDR5)
Memory StandardDDR5 5600 / DDR5 6000 / DDR5 6200 / DDR5 6400 / DDR5 6600 / DDR5 6666 / DDR5 6800 / DDR5 7000 / DDR5 7200 / DDR5 7600 / DDR5 7800 / DDR5 8000 / DDR5 8200 / DDR5 8800 / DDR5 9000
Maximum Memory Supported128GB
Channel SupportedDual Channel
Memory Performance ProfileIntel XMP 3.0 / AMD EXPO
ECC SupportedNon-ECC
Buffer SupportedUn-buffered
PCI Express 5.0 x161 x PCI Express x16 slot, integrated in the CPU:
AMD Ryzen 9000/7000 Series Processors support PCIe 5.0 x16 mode
AMD Ryzen 8000 Series-Phoenix 1 Processors support PCIe 4.0 x8 mode
AMD Ryzen 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4 mode
* The PCIEX16 slot can only support a graphics card or an NVMe SSD.
Serial ATA (SATA)2 x SATA 6Gb/s
M.21 x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3, M key, type 2280 SSDs:
AMD Ryzen 9000/7000 Series Processors support PCIe 5.0 x4/x2 SSDs
AMD Ryzen 8000 Series-Phoenix 1 Processors support PCIe 4.0 x4/x2 SSDs
AMD Ryzen 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4/x2 SSDs
1 x M.2 connector on the back of the motherboard (M2C_SB), integrated in the Chipset, supporting Socket 3, M key, type 2280 PCIe 4.0 x4/x2 SSDs
SATA RAIDRAID 0, RAID 1, RAID 5, and RAID 10 support for NVMe SSD storage devices
* RAID 5 is only available on AMD Ryzen 9000 Series Processors.
RAID 0 and RAID 1 support for SATA storage devices
Audio ChipsetRealtek ALC4080
Audio Channels2 Channels
Max LAN Speed2.5Gbps
Wireless LANRealtek Wi-Fi 7 RTL8922AE
Back I/O Ports1 x Q-Flash Plus button
1 x HDMI port (Note)
2 x antenna connectors (2T2R)
1 x USB4 USB Type-C port (DisplayPort (Note))
1 x USB Type-C port, with USB 3.2 Gen 2 support
2 x USB 3.2 Gen 2 Type-A ports (red)
2 x USB 3.2 Gen 1 ports
2 x USB 2.0/1.1 ports
1 x RJ-45 port
2 x audio jacks
(Note) Actual support may vary by CPU.
Onboard USB1 x USB Type-C header, with USB 3.2 Gen 2 support
1 x USB 3.2 Gen 1 header
1 x USB 2.0/1.1 header
Other Connectors1 x CPU fan header
1 x CPU fan/water cooling pump header
1 x system fan header
2 x addressable RGB Gen2 LED strip headers
1 x RGB LED strip header
2 x M.2 Socket 3 connectors
2 x SATA 6Gb/s connectors
1 x front panel header
1 x speaker header
1 x front panel audio header (routed from the adapter card on the rear panel)
1 x reset jumper
1 x Clear CMOS jumper
1 x chassis intrusion header
Form FactorMini ITX
Dimensions (W x L)6.7" x 6.7"
Power Pin1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
BIOS Feature1 x 256 Mbit flash
Use of licensed AMI UEFI BIOS
PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Windows 11Support for Windows 11 64-bit
FeaturesSupport for GIGABYTE Control Center (GCC)
Support for Q-Flash
Support for Q-Flash Plus
Support for Smart Backup
배송 무게1.29 kg
포장 크기241 × 229 × 102 mm

이 모델의 다른 버전

같은 라인업에서 5개 더

같은 제품군에서 메모리·쿨러·클럭이 다릅니다 — 결정 전에 비교해 보세요.

이 상품에 대한 질문

What case clearance does the Mini-ITX board need for the VRM thermal guard and M.2 heatsink?

The board follows the Mini-ITX form factor; allow extra height above the socket area for the VRM thermal guard and above the M.2 slot for the integrated heatsink.

Which screws do I remove first when fitting an M.2 SSD using the EZ-Latch mechanism?

The EZ-Latch design uses a single captive screw; press the latch to release the SSD, then lift it out without fully removing the screw.

How often should the VRM thermal pads be inspected or replaced on this 110A power-stage design?

Thermal pads on the VRM heatsink do not have a fixed interval; inspect them if temperatures rise unexpectedly or during a major rebuild.
