Black aluminium four-bay 3.5 inch SATA dock with cooling fan and USB 3.0 cable

Orico

Orico 4-Bay 3.5" SATA USB 3.0 Drive Enclosure Black

SKU CH-6G22-EJ87V

Holds four 3.5-inch SATA drives with 16 TB per bay, aluminium cooling and USB 3.0 speed

  • ColorBlack
  • Size2.5" & 3.5"
  • TypeDock
  • AC AdapterYes
  • MaterialAluminum
  • Internal InterfaceSATA I/II/III

HDD · # of Bay · Size · Model Without RAID · 4 Bay · 4 Bay 9548U3 · n/a

  • Auto-sleep after 10 minutes saves power and extends drive life
  • Aluminium shell plus fan provides double heat dissipation for cooler operation
  • Four bays accept 3.5″ or 2.5″ SATA drives up to 16 TB each
  • USB 3.0 interface delivers up to 5 Gbps transfer speed
  • Tool-free dock design allows quick drive swaps without RAID complexity

Four-Bay SATA Enclosure for Desktop Expansion

The Orico enclosure holds up to four 3.5-inch SATA hard drives or SSDs and connects to a PC or laptop through a single USB 3.0 cable. Each bay accepts drives up to 16 TB, giving a total raw capacity of 64 TB. The aluminium chassis includes a built-in fan and an auto-sleep timer that spins drives down after ten minutes of inactivity.

Tool-Free Drive Installation with Cooling

Drives slide into the open bays without screws or trays, so swapping disks takes seconds. The USB 3.0 link provides up to 5 Gbps bandwidth, but the enclosure does not support RAID or NAS functions, so each drive appears separately to the operating system. The fan runs continuously when the unit is powered, which adds audible noise in quiet rooms.

Check Power and Host Port Before Buying

The unit ships with an external AC adapter and a USB 3.0 cable; verify you have a free mains outlet and a USB 3.0 Type-A port on the host for full speed. Because RAID is not available, software spanning or backup must be configured in the OS. The enclosure also accepts 2.5-inch SATA drives, but 3.5-inch units require the supplied power brick.

주요 특징

  • Auto-sleep after 10 minutes saves power and extends drive life
  • Aluminium shell plus fan provides double heat dissipation for cooler operation
  • Four bays accept 3.5″ or 2.5″ SATA drives up to 16 TB each
  • USB 3.0 interface delivers up to 5 Gbps transfer speed
  • Tool-free dock design allows quick drive swaps without RAID complexity

사양

BrandORICO
ColorBlack
Size2.5" & 3.5"
TypeDock
AC AdapterYes
MaterialAluminum
Internal InterfaceSATA I/II/III
External InterfaceUSB 3.0
HDD Count SupportedWithout RAID
Number of Bay4 Bay
FanYes

이 모델의 다른 버전

같은 라인업에서 1개 더

같은 제품군에서 메모리·쿨러·클럭이 다릅니다 — 결정 전에 비교해 보세요.

이 상품에 대한 질문

How can I confirm the enclosure is operating correctly after connecting four drives?

The activity LED shows disk access status and the unit enters sleep mode automatically after 10 minutes of inactivity, indicating normal operation.

What comes in the package and what must I supply myself?

The box includes the 4-bay enclosure, a power cord, a USB 3.0 cable, a certification sheet and a user manual; you must provide up to four 3.5-inch SATA drives.

Which capacity limit should I consider when choosing drives for the four bays?

Each bay supports a single drive up to 16 TB, giving a total raw capacity of 64 TB across all four bays.
