OWC
OWC 8GB DDR4 3200 CL22 260-pin SODIMM for ASUSTOR FS6706T FS6712X
8 GB DDR4 3200 SODIMM upgrade for ASUSTOR FS6706T and FS6712X NAS units
- Capacity8GB
- Type260-Pin DDR4 Non-ECC SODIMM
- SpeedDDR4 3200 (PC4 25600)
- CAS LatencyCL22
- Voltage1.2V
- ECCNo
- 8GB capacity expands multitasking headroom for NAS workloads
- DDR4 3200 speed matches ASUSTOR FS6706T and FS6712X specs
- CL22 latency and 1.2V voltage meet JEDEC standard
- Single-rank 1Rx8 260-pin SODIMM fits factory slot
- Limited lifetime warranty with free tech support included
8GB DDR4 3200 SODIMM for ASUSTOR NAS
This 8GB DDR4 3200 module is built for ASUSTOR FS6706T and FS6712X systems. It replaces the original AS-8GD4 part with a JEDEC-standard upgrade. The single 1Rx8 stick adds capacity without requiring matched pairs. It targets owners who need more memory for virtualisation or heavy file workloads.
260-pin unbuffered design at 1.2V
The module uses a standard 260-pin SODIMM edge connector and runs at 1.2V with CL22 timing. No heat spreader is fitted, so it fits tight NAS chassis without clearance issues. Installation is a straightforward DIY task that does not void the system warranty. JEDEC and ROHS compliance ensures electrical compatibility with the factory memory controller.
Replaces factory 8GB stick in FS6706T and FS6712X
This part directly substitutes the OEM AS-8GD4 module in the listed ASUSTOR models. The upgrade is worthwhile when the stock capacity limits concurrent Docker containers or large-volume transfers. It does not serve systems that require ECC or registered DIMMs. Buyers needing higher total capacity must populate additional slots with identical modules.
주요 특징
- 8GB capacity expands multitasking headroom for NAS workloads
- DDR4 3200 speed matches ASUSTOR FS6706T and FS6712X specs
- CL22 latency and 1.2V voltage meet JEDEC standard
- Single-rank 1Rx8 260-pin SODIMM fits factory slot
- Limited lifetime warranty with free tech support included
사양
| Brand | OWC |
|---|---|
| Part Number | 3S2D41R808GB |
| Capacity | 8GB |
| Type | 260-Pin DDR4 Non-ECC SODIMM |
| Speed | DDR4 3200 (PC4 25600) |
| CAS Latency | CL22 |
| Voltage | 1.2V |
| ECC | No |
| Buffered/Registered | Unbuffered |
| Rank | 1Rx8 |
| Heat Spreader | No |
| Compatible System | ASUSTOR FS6706T ASUSTOR FS6712X |
이 상품에 대한 질문
What DDR4 speed does the PC4-25600 rating on this 8GB SODIMM deliver in practice?
The module runs at DDR4 3200 with CL22 latency, so the PC4-25600 rating means 3200 MT/s data transfer on the 260-pin interface.
Will the 260-pin form factor and 1.2 V operation fit the memory slots in an ASUSTOR FS6706T or FS6712X?
Yes — it is a 260-pin DDR4 SODIMM at 1.2 V, matching the slot and voltage used by both ASUSTOR models.
What is the correct way to seat this unbuffered 1Rx8 SODIMM, and which step do DIYers most often miss?
Align the notch, insert at an angle, then press down firmly until both side clips click; the step most often missed is verifying both clips have fully engaged.
