White rectangular Wi-Fi 6 range extender with four adjustable external antennas

Wavlink

Wavlink WL-WN583AX3 AX3000 Wi-Fi 6 wireless range extender

SKU CH-X171-F4JCG

Dual-band Wi-Fi 6 range extender with four 5dBi antennas, 160 MHz bandwidth, OFDMA and BSS Coloring, covering up to 2000 sq ft for 256 devices

  • StandardsIEEE 802.11a/b/g/n/ac/ax
  • Frequency Band2.4 GHz / 5.0 GHz
  • Wireless Data Rates2.4GHz(573Mbps) / 5GHz(2402Mbps)
  • SecurityAdvanced Security with WPA3
  • WPA/WPA2WPA3/WPA2-PSK MIX, WPA2-PSK, WPA2/WPA1-PSK MIX
  • Antenna4 x 5dBi Omni Directional Antennas(Length: 15.4cm/6.1in)

Class AX3000

Wireless Speed ax3000

  • Dual-band Wi-Fi 6 delivers up to 2975 Mbps combined throughput
  • Four 5 dBi antennas extend coverage to 2000 sq ft
  • WPA3 encryption protects every connected device
  • Repeater, AP and router modes suit any network layout
  • Gigabit Ethernet port enables wired links for PCs or consoles

What this Wavlink extender does

The WL-WN583AX3 is a dual-band Wi-Fi 6 wireless range extender that also works as an access point or router. It covers indoor areas up to 100m and outdoor areas up to 300m, supporting up to 256 connected devices for homes or small offices.

160MHz bandwidth on 5GHz

The single specification that decides fit is the 160MHz channel width on the 5.0GHz band, which enables the 2402Mbps link rate. Without a main router that also supports 160MHz, the extender will fall back to narrower channels and lower throughput.

Sustained load behaviour

Under continuous traffic the four 5dBi antennas and four FEM chips maintain signal strength across the 2000sq.ft. coverage area. BSS Coloring reduces interference from neighbouring networks, while OFDMA and MU-MIMO keep multiple streams stable during prolonged streaming, gaming or large file transfers.

주요 특징

  • Dual-band Wi-Fi 6 delivers up to 2975 Mbps combined throughput
  • Four 5 dBi antennas extend coverage to 2000 sq ft
  • WPA3 encryption protects every connected device
  • Repeater, AP and router modes suit any network layout
  • Gigabit Ethernet port enables wired links for PCs or consoles

사양

BrandWavlink
ModelWL-WN583AX3
Part Number1 x WAN/LAN(10/100/1000Mbps)
StandardsIEEE 802.11a/b/g/n/ac/ax
Frequency Band2.4 GHz / 5.0 GHz
Wireless Data Rates2.4GHz(573Mbps) / 5GHz(2402Mbps)
SecurityAdvanced Security with WPA3
WPA/WPA2WPA3/WPA2-PSK MIX, WPA2-PSK, WPA2/WPA1-PSK MIX
Antenna4 x 5dBi Omni Directional Antennas(Length: 15.4cm/6.1in)
Operating RangeIndoor: Up to 100m, Outdoor: Up to 300m
Operating ModeRepeater/AP/Router
InterfaceEthernet Port
LED1 x WPS(Purple/Red/Blue); 1 x WAN/LAN(Blue)
Button1 x Power On/Off; 1 x Reset; 1 x WPS
Weight298g/10.5oz
Features- Dual band 2.4G 573Mbps +5G 2402Mbps with the aggregated speeds up to 2975Mbps.
- The BSS coloring technology enables a better spatial reuse.
- The WiFi 6 MU-MIMO and OFDMA techniques have greatly improved the device efficiency and performance.
- One Gigabit Ethernet port provides your devices with high-speed network experience.
- With various modes, you can either use it as a regular Repeater/AP/Router or pair it with a Mesh device.
- High grade WLAN security with WPA3/WPA2-PSK MIX, WPA2-PSK, WPA2/WPA1-PSK MIX.
- Compact wall plug design for easy placement.
- Antenna: 4 x 5dBi high
Package ContentsIn the Box
- 1 x Wi-Fi 6 Repeater/AP/Router
- 1 x RJ-45 Ethernet Cable
- 1 x Quick Start Guide

이 모델의 다른 버전

같은 라인업에서 1개 더

같은 제품군에서 메모리·쿨러·클럭이 다릅니다 — 결정 전에 비교해 보세요.

이 상품에 대한 질문

What does the AX3000 rating mean for actual throughput on my devices?

The AX3000 label combines the 5 GHz radio at 2402 Mbps and the 2.4 GHz radio at 573 Mbps for an aggregate 2975 Mbps. Real-world speed per device will be lower and depends on the client's capabilities and channel width.

How does the 160 MHz channel width affect the 5 GHz link?

The 160 MHz bandwidth on the 5 GHz band doubles the channel width versus the common 80 MHz setting, enabling the 2402 Mbps PHY rate. Both the extender and the client must support 160 MHz to reach that figure.

What physical space and mounting options does the unit need?

The extender weighs 298 g and ships with four 5 dBi omni-directional antennas that are 15.4 cm long. It is designed for desktop or shelf placement; no wall-mount hardware is included in the box.
