Athena Power
Athena Power RM-2UC238 Black 2U Rackmount Server Chassis
A compact 2U rackmount chassis for MicroATX and Mini-ITX boards with two 5.25-inch bays, four low-profile PCI slots, dual front 80mm fans and a removable air filter
- Chassis TypeRackmount
- Form Factor2U
- ColorBlack
- Case Material1.0mm SECC
- Motherboard CompatibilityMicroATX (9.6 in. x 9.6 in.) Mini-ITX (6.7 in. x 6.7 in.)
- Power SupplyPS3 Single
- Fits standard 19-inch racks with compact 3.50 x 17.13 x 14.00-inch 2U design
- Supports MicroATX and Mini-ITX boards for flexible server builds
- Four low-profile PCI slots enable vertical expansion card installation
- Two front 80mm fans deliver direct airflow to internal components
- Removable washable air filter simplifies maintenance in dusty environments
Space-saving 2U Rackmount Server Chassis
The Athena Power RM-2UC238 is a black 2U rackmount server chassis built from 1.0mm SECC steel. It accepts MicroATX boards up to 9.6 in. x 9.6 in. and Mini-ITX boards at 6.7 in. x 6.7 in., making it suitable for small-business servers or edge-computing nodes that must fit a standard 19 in. rack.
Upgrade from tower or 1U systems
This chassis replaces a tower server when rack density becomes a priority, or a 1U unit when additional expansion is required. The jump is worth it when you need two external 5.25 in. drive bays and four low-profile vertical PCI slots while staying within a 14 in. depth that fits shallow cabinets.
Straightforward rack installation
The unit mounts in a standard 19 in. rack using its 3.50 in. height and 17.13 in. width, weighing 10.00 lbs. Two front 80mm fans provide intake airflow, and a removable washable air filter simplifies maintenance. Builders must source a compatible PS3 single power supply separately, and full-height cards will not fit the low-profile slots.
Puntos fuertes
- Fits standard 19-inch racks with compact 3.50 x 17.13 x 14.00-inch 2U design
- Supports MicroATX and Mini-ITX boards for flexible server builds
- Four low-profile PCI slots enable vertical expansion card installation
- Two front 80mm fans deliver direct airflow to internal components
- Removable washable air filter simplifies maintenance in dusty environments
Especificaciones
| Brand | Athena Power |
|---|---|
| Model | RM-2UC238 |
| Chassis Type | Rackmount |
| Form Factor | 2U |
| Color | Black |
| Case Material | 1.0mm SECC |
| Motherboard Compatibility | MicroATX (9.6 in. x 9.6 in.) Mini-ITX (6.7 in. x 6.7 in.) |
| Power Supply | PS3 Single |
| External 5.25" Drive Bays | 2 |
| Expansion Slots | 4 x Low Profile Vertical PCI Slots |
| Front Ports | 1 x Front 2-port USB 2.0 |
| 80mm Fans | 2 x Front 80mm |
| Features | Indicators: (LED) HDD, Power Air Filter: Removable & Washable Switch: Power On / Off, Reset |
| Dimensions | 3.50" x 17.13" x 14.00" |
| Weight | 10.00 lbs. |
| Peso de envío | 6.60 kg |
| Dimensiones del paquete | 566 × 505 × 241 mm |
Preguntas sobre este artículo
What rack depth and width does the 2U RM-2UC238 require for mounting?
The chassis measures 14.00 inches deep and 17.13 inches wide, fitting a standard 19-inch rack with 2U (3.50-inch) height clearance.
How are the two front 80mm fans installed, and what common step is missed?
The fans mount behind the removable front bezel; the step often missed is reconnecting the fan power headers to the motherboard or fan controller before closing the bezel.
When should the removable air filter be cleaned or replaced?
Inspect the washable air filter monthly and clean it whenever dust buildup is visible to maintain airflow through the front 80mm fans.
