Three square black 120 mm case fans with metallic hubs, anti-vibration corners and PWM cables

COUGAR

COUGAR MHP120 KIT 120 mm case fan 3-pack

SKU CH-CSCW-02JTB

Three 120 mm hydraulic-bearing PWM fans deliver up to 82.48 CFM airflow and 4.24 mm H₂O static pressure for radiator or case cooling

  • Fan Counts3 Fans
  • Fan ControllerNo Controller
  • TypeCase Fan
  • Fan Size120mm
  • Fan Thickness25mm
  • Bearing TypeHydraulic Bearing

Option 3 Packs

  • High static pressure of 4.24 mm H₂O for dense radiators
  • Hydraulic bearing and PWM control give quiet 600–2000 RPM range
  • Metallic-reinforced hub and shell increase structural rigidity
  • Anti-vibration dampers and low-noise adaptors reduce transmitted noise
  • Three-fan kit includes extension cables and screw kit for quick install

Three-fan kit for high-static-pressure cooling

The COUGAR MHP120 KIT supplies three 120 mm case fans built around a hydraulic bearing and a metallic-reinforced motor hub. Each unit runs at 12 VDC and draws 0.23 A through a standard 4-pin PWM connector. The pack includes 300 mm extension cables, 100 mm low-noise adaptors and a screw kit for straightforward installation.

Static pressure of 4.24 mm H₂O for dense fin stacks

The single figure that determines fit for purpose is the rated air pressure of 4.24 mm H₂O ±10 %. This level targets radiators and restrictive mesh where airflow alone is insufficient. Buyers who need high volume through open grilles rather than pressure through fins should look elsewhere.

Sustained 2000 RPM with hydraulic bearing durability

At full PWM duty the fans hold 2000 RPM ±200 RPM, delivering 82.48 CFM ±10 % at a maximum of 41.2 dB(A). The hydraulic bearing and reinforced shell are engineered to maintain that speed continuously without the wear spike seen in sleeve designs. Power draw stays at 2.76 W per fan under load.

Puntos fuertes

  • High static pressure of 4.24 mm H₂O for dense radiators
  • Hydraulic bearing and PWM control give quiet 600–2000 RPM range
  • Metallic-reinforced hub and shell increase structural rigidity
  • Anti-vibration dampers and low-noise adaptors reduce transmitted noise
  • Three-fan kit includes extension cables and screw kit for quick install

Especificaciones

BrandCougar
ModelMHP120 KIT
Fan Counts3 Fans
Fan ControllerNo Controller
TypeCase Fan
Fan Size120mm
Fan Thickness25mm
Bearing TypeHydraulic Bearing
RPM600-2000 RPM +/- 200RPM
Air Flow82.48 CFM +/- 10%
Noise Level41.2 dB(A) (Max.)
Power Connector4 Pin PWM
FeaturesMetallic-reinforced Motor Hub & Shell
Extreme Cooling Fan With 2000 RPM (max)
HDB Bearing & PWM Control
Anti-vibration Damper
3 Fan Pack
Air Pressure: 4.24 mm H2O±10%
Rated Voltage: 12 VDC
Rated Current: 0.23 A
Power Consumption: 2.76 W +/- 10%
Cable Length: 200 mm (With 100mm Y-cable)
Weight: 186g
Dimensions120 x 120 x 25 mm
Package Contents3 x MHP120
3 x 300mm Extension Cable
3 x 100mm Low-Noise Adaptor
Fan Screw Kit
User Manual

Otras versiones de este modelo

1 más en esta gama

Misma familia, con memoria, disipador o frecuencia diferentes — compare antes de decidirse.

Preguntas sobre este artículo

What does the 2000 RPM top speed actually deliver inside a case?

At maximum speed the fans move 82.48 CFM with 4.24 mm H2O static pressure, suited for radiators or restrictive meshes.

How does the 4-pin PWM connector limit or enable speed control?

The 4-pin PWM header lets the motherboard vary voltage from 600 to 2000 RPM automatically based on temperature curves.

What clearance and mounting hardware do the 120 mm frames need?

Each fan is 120 x 120 x 25 mm and the box includes a screw kit plus 300 mm extension cables for flexible routing.
