1U silver rack server front with four 3.5-inch drive trays

Supermicro

Supermicro SYS-6018U-TR4T+ 1U rack server 2x Xeon E5-2699 v4 2.2GHz 22-core 64GB DDR4 4x 3.5" bays

SKU CH-29WE-Y52QG

Dual 22-core Xeon 1U server with 64GB DDR4, 4× 3.5" hot-swap bays, MegaRAID 9361-8i, quad 10GBase-T and IPMI 2.0

  • Rack Height1U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • CPU Speed2.20 GHz
  • CPU SocketLGA 2011-3
  • Number of CPU Cores22-Core Processor
  • Dual Xeon E5-2699 v4 provide 22 cores each at 2.2 GHz
  • 64 GB DDR4 2400 MHz ECC memory supports heavy workloads
  • MegaRAID 9361-8i handles RAID 0/1/5/6/10/50/60 with 1 GB cache
  • Quad 10GBase-T ports via Intel X540 enable fast networking
  • Dual 750 W platinum PSUs with hot-swap ensure uptime

Dual 22-core Xeon 1U server

This 1U rackmount system ships with two Intel Xeon E5-2699 v4 processors running at 2.2 GHz, each providing 22 cores. It includes 64 GB of DDR4 ECC memory across four 16 GB modules. The MegaRAID 9361-8i controller supports RAID 0, 1, 5, 6, 10, 50 and 60 across four hot-plug 3.5-inch SATA or SAS drive bays. Quad 10GBase-T Ethernet ports and IPMI 2.0 with dedicated LAN complete the connectivity.

Virtualization and HPC clusters

The dual 22-core configuration suits dense virtualization hosts, high-performance compute nodes and cloud infrastructure where core count and memory bandwidth matter. Four 3.5-inch bays limit local storage density, so buyers who need more drive slots or who need 2.5-inch bay support should look elsewhere. The Matrox G200 graphics with 8 MB video memory is only for console output, not GPU compute workloads.

Four 3.5-inch hot-plug bays with MegaRAID 9361-8i

The chassis provides exactly four 3.5-inch hot-plug drive bays backed by the LSI MegaRAID 9361-8i 8-port SAS 12 Gb/s controller with 1 GB cache and battery backup. This combination decides whether the server fits a given storage topology; expansion beyond four 3.5-inch drives requires external enclosures or a different chassis.

Puntos fuertes

  • Dual Xeon E5-2699 v4 provide 22 cores each at 2.2 GHz
  • 64 GB DDR4 2400 MHz ECC memory supports heavy workloads
  • MegaRAID 9361-8i handles RAID 0/1/5/6/10/50/60 with 1 GB cache
  • Quad 10GBase-T ports via Intel X540 enable fast networking
  • Dual 750 W platinum PSUs with hot-swap ensure uptime

Especificaciones

BrandSUPERMICRO
SeriesCSE-819U + X10DRU-i+
ModelSYS-6018U-TR4T+
Rack Height1U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
CPU Speed2.20 GHz
CPU SocketLGA 2011-3
Number of CPU Cores22-Core Processor
# of Processors InstalledE5-2699 V4
Installed Memory Size64GB
Storage ControllerLSI MegaRAID 9361-8i Controller
HDD InterfaceSATA/SAS
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
GPU TypeMatrox G200
Video Memory8MB
Ethernet ControllerSupermicro AOC-UR-i4XT - Intel X540 - 4x RJ45 10GBase-T Ports
Management PortRJ 45
Features4 x 3.5" SATA/SAS Hot-Plug Drive Bays

Preguntas sobre este artículo

Will the 2.2 GHz Xeon E5-2699 v4 processors throttle under sustained all-core workloads?

The CPUs are rated for a 3.6 GHz turbo frequency; sustained all-core speed depends on the 1U chassis airflow and the 750 W platinum power supplies maintaining thermal limits.

How loud and hot does the 1U server get when running 24/7 with both 22-core CPUs and 64 GB DDR4 loaded?

Dual 750 W platinum PSUs and high-speed 40 mm fans keep the system within spec, but expect noticeable fan noise and warm exhaust air in a 1U form factor.

Which rails and drives do I need to add before this SYS-6018U-TR4T+ can go into a standard rack?

Front bezel and rack-mount rails are not included; you must supply 3.5" SATA or SAS drives for the four hot-plug bays and compatible rails for your rack.
