Silver 1U rack server chassis with four front 3.5-inch drive trays

Supermicro

Supermicro SYS-6019U-TN4R4T 1U rack server 2x Xeon Platinum 8160 24-core 16GB DDR4 4x 3.5" bays

SKU CH-93K7-WNTD0

A 1U rack server with dual 24-core Xeon Platinum 8160 processors, 16GB DDR4, four 3.5" hot-swap bays, MegaRAID 9361-8i controller and four 10GBase-T ports

  • Rack Height1U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • CPU Speed2.10 GHz
  • CPU SocketLGA 3647
  • Number of CPU Cores24-Core Processor
  • Dual Xeon Platinum 8160 CPUs provide 24 cores each for heavy workloads
  • 16 GB DDR4 ECC memory at 2666 MT/s protects data integrity
  • MegaRAID 9361-8i controller supports RAID 0/1/5/6/10/50/60 with 1 GB cache
  • Four 10GBase-T ports via Intel X540 give high-speed network throughput
  • Dual 750 W Platinum PSUs with IPMI 2.0 enable redundant power and remote management

Dual Xeon 1U server for dense compute

The Supermicro SYS-6019U-TN4R4T is a 1U rackmount system equipped with two Intel Xeon Platinum 8160 processors, each running at 2.10 GHz with 24 cores. Sixteen gigabytes of DDR4-2666 ECC registered memory are installed across two modules. The platform targets workloads that need high core counts in a single rack unit, such as virtualization hosts, HPC nodes or software-defined storage clusters.

Four hot-swap bays and quad 10GBase-T

Four front-access 3.5-inch trays accept SATA or SAS drives and connect to an LSI MegaRAID 9361-8i controller supporting RAID 0, 1, 5, 6, 10, 50 and 60 with 1 GB battery-backed cache. Networking is provided by an AOC-UR-i4XT add-on card delivering four 10GBase-T ports via Intel X540 controllers. A dedicated RJ45 port gives IPMI 2.0 access for remote KVM and virtual media, leaving the data ports free for production traffic.

Redundant 750 W platinum power supplies

Two hot-swap 750 watt platinum-efficiency power supplies share the load and maintain uptime if one unit fails. The 1U chassis relies on internal high-speed fans to cool both CPUs, the RAID controller and the drive bays under sustained throughput. Buyers who need more than 16 GB of memory or additional PCIe expansion slots will find the single riser layout restrictive. Front bezel and rack rails are not included.

Puntos fuertes

  • Dual Xeon Platinum 8160 CPUs provide 24 cores each for heavy workloads
  • 16 GB DDR4 ECC memory at 2666 MT/s protects data integrity
  • MegaRAID 9361-8i controller supports RAID 0/1/5/6/10/50/60 with 1 GB cache
  • Four 10GBase-T ports via Intel X540 give high-speed network throughput
  • Dual 750 W Platinum PSUs with IPMI 2.0 enable redundant power and remote management

Especificaciones

BrandSUPERMICRO
SeriesCSE-819UTS-R751P-T-X11DPU
ModelSYS-6019U-TN4R4T
Rack Height1U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
CPU Speed2.10 GHz
CPU SocketLGA 3647
Number of CPU Cores24-Core Processor
# of Processors InstalledPlatinum 8160
Installed Memory Size16GB
Storage ControllerLSI MegaRAID 9361-8i Controller
HDD InterfaceSATA/SAS
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
GPU TypeMatrox G200
Video Memory8MB
Ethernet Controller4x 10GBase-T ports via AOC-UR-i4XT (Intel X540 10GBase-T)
Management PortRJ 45
Features4 x 3.5" SATA/SAS Hot-Plug Drive Bays

Preguntas sobre este artículo

What is the maximum turbo frequency the dual Xeon Platinum 8160 CPUs can reach under sustained load?

Each Xeon Platinum 8160 processor can boost up to 3.7 GHz when thermal and power headroom allow.

How much heat and power should I plan for with the redundant 750 W platinum supplies running continuously?

Two 750 W platinum-efficiency power supplies provide redundant hot-swap power for 24/7 operation.

Which storage drives must I supply myself to populate the four hot-swap bays?

The server includes four 3.5-inch SATA/SAS trays but ships without any hard disk drives installed.
