1U silver rack server, four front 3.5 drive bays, redundant PSUs

Supermicro

Supermicro SYS-6019U-TN4R4T rack server 2x Xeon Platinum 8160 512GB DDR4 4x 3.5" bays

SKU CH-M881-TEFAF

Dual 24-core Xeon Platinum 8160 CPUs, 512GB DDR4 ECC memory, four 3.5-inch hot-swap bays and four 10GBase-T ports in a 1U chassis

  • Rack Height1U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • CPU Speed2.10 GHz
  • CPU SocketLGA 3647
  • Number of CPU Cores24-Core Processor
  • Dual 24-core Xeon Platinum 8160 CPUs deliver high parallel throughput
  • 512 GB DDR4-2666 ECC registered memory supports large virtualised workloads
  • MegaRAID 9361-8i with 1 GB cache enables RAID 0/1/5/6/10/50/60
  • Four 10GBase-T ports via Intel X540 provide fast network connectivity
  • Two 750 W platinum-efficiency hot-swap PSUs maintain uptime during power events

Dual Xeon Platinum 8160 1U server

The Supermicro SYS-6019U-TN4R4T packs two 24-core Intel Xeon Platinum 8160 CPUs at 2.1 GHz with 3.7 GHz Turbo into a 1U rack chassis. It ships with 512 GB of DDR4-2666 ECC registered memory across 16 DIMMs. Four hot-swap 3.5-inch bays accept SATA or SAS drives for dense storage. The LSI MegaRAID 9361-8i controller handles RAID 0, 1, 5, 6, 10, 50 and 60 with 1 GB cache and battery backup. Four 10GBase-T ports via an Intel X540 add-in card provide high-speed networking.

Redundant 750 W platinum PSUs

Two hot-swap 750-watt platinum-efficiency power supplies deliver redundant power for continuous operation. The 1U form factor concentrates heat in a small volume, so the system relies on high-airflow fans that will be audible under load. IPMI 2.0 with a dedicated RJ45 management port enables remote monitoring of temperatures, fan speeds and power draw without loading the host OS. The Matrox G200 GPU with 8 MB video memory handles basic console output only.

9361-8i RAID controller and IPMI 2.0

The bundled MegaRAID 9361-8i adds hardware RAID acceleration and cache protection that software RAID cannot match, reducing CPU overhead during parity calculations. IPMI 2.0 with virtual media and KVM-over-LAN lets administrators mount ISOs, reboot and troubleshoot remotely even when the OS is unresponsive. No front bezel or rack rails are included, so buyers must source mounting hardware separately. This configuration targets virtualization, HPC and software-defined storage clusters needing maximum cores and memory in 1U.

Puntos fuertes

  • Dual 24-core Xeon Platinum 8160 CPUs deliver high parallel throughput
  • 512 GB DDR4-2666 ECC registered memory supports large virtualised workloads
  • MegaRAID 9361-8i with 1 GB cache enables RAID 0/1/5/6/10/50/60
  • Four 10GBase-T ports via Intel X540 provide fast network connectivity
  • Two 750 W platinum-efficiency hot-swap PSUs maintain uptime during power events

Especificaciones

BrandSUPERMICRO
SeriesCSE-819UTS-R751P-T-X11DPU
ModelSYS-6019U-TN4R4T
Rack Height1U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
CPU Speed2.10 GHz
CPU SocketLGA 3647
Number of CPU Cores24-Core Processor
# of Processors InstalledPlatinum 8160
Installed Memory Size512GB
Storage ControllerLSI MegaRAID 9361-8i Controller
HDD InterfaceSATA/SAS
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
GPU TypeMatrox G200
Video Memory8MB
Ethernet Controller4x 10GBase-T ports via AOC-UR-i4XT (Intel X540 10GBase-T)
Management PortRJ 45
Features4 x 3.5" SATA/SAS Hot-Plug Drive Bays

Preguntas sobre este artículo

How do I install the 512GB DDR4 memory kit into the 16 DIMM slots?

Populate all 16 slots with the 32GB DDR4-2666 ECC registered modules; the key mistake is mixing ranks or speeds, so install the matched 16-piece kit together.

When will the MegaRAID 9361-8i controller battery need replacement?

The 1GB cache battery on the 9361-8i typically lasts 3–5 years; plan a swap when the controller logs a battery-learn failure or degraded write-back mode.

What thermal limit appears first when both Platinum 8160 CPUs run at 3.7GHz turbo in a 1U chassis?

The 750W redundant PSUs and 1U airflow hit their cooling ceiling before the CPUs reach sustained 3.7GHz, causing automatic frequency scaling.
