Silver 4U rack server with thirty-six front drive trays and dual redundant power supplies

Supermicro

Supermicro SYS-6048R-E1CR36N 36-bay 4U rack server 2x Xeon E5-2680 v4 14-core 768GB DDR4 9361-8i

SKU CH-1WSN-KQMCE

Holds 36 hot-swap 3.5" drives, dual Xeon 14-core CPUs at 2.4 GHz, 768 GB DDR4 ECC and a 9361-8i RAID controller with quad 10G LAN and IPMI 2.0 in a 4U chassis

  • Rack Height1U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • CPU Speed2.40 GHz
  • CPU SocketLGA 2011-3
  • Number of CPU Cores14-Core Processor
  • Dual 14-core Xeon processors at 2.4 GHz base with 3.3 GHz turbo for demanding workloads
  • 768 GB DDR4 registered ECC memory across 24 DIMM slots for data integrity
  • 36 hot-swap 3.5-inch SAS/SATA drive bays provide massive storage density
  • LSI MegaRAID 9361-8i controller supports RAID 0/1/5/6/10/50/60 with 1 GB cache
  • Quad 10GBase-T LAN ports via Intel X540 plus dedicated IPMI 2.0 management

High-Density 36-Bay 4U Server

The Supermicro SYS-6048R-E1CR36N is a 4U rackmount server system built for high-density storage environments. It integrates dual Intel Xeon E5-2680 v4 14-core processors running at 2.40 GHz with 768GB of DDR4 registered ECC memory. A MegaRAID 9361-8i controller manages up to 36 hot-swap 3.5-inch SATA/SAS drive bays, while quad 10GBase-T ports and IPMI 2.0 provide connectivity and remote management.

Suited For Enterprise Storage Workloads

This server suits organisations deploying massive direct-attached storage, backup repositories or archival platforms that require 36 drive bays in a single chassis. The dual 14-core CPUs and large memory pool handle heavy file-serving and software-defined storage tasks. Buyers who need GPU-accelerated compute or more than eight internal RAID ports should evaluate alternative platforms.

Eight-Port 12Gb/s RAID Controller

The installed LSI MegaRAID 9361-8i delivers eight internal SAS 12Gb/s ports with 1GB cache and battery backup, supporting RAID 0, 1, 5, 6, 10, 50 and 60. This port count and feature set determine how many drives can be grouped into protected arrays and whether the controller meets the performance and redundancy requirements of the target workload.

Puntos fuertes

  • Dual 14-core Xeon processors at 2.4 GHz base with 3.3 GHz turbo for demanding workloads
  • 768 GB DDR4 registered ECC memory across 24 DIMM slots for data integrity
  • 36 hot-swap 3.5-inch SAS/SATA drive bays provide massive storage density
  • LSI MegaRAID 9361-8i controller supports RAID 0/1/5/6/10/50/60 with 1 GB cache
  • Quad 10GBase-T LAN ports via Intel X540 plus dedicated IPMI 2.0 management

Especificaciones

BrandSUPERMICRO
SeriesCSE-847BE1C-R1K28LPB-X10DRi-T4+
ModelSYS-6048R-E1CR36N
Rack Height1U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
CPU Speed2.40 GHz
CPU SocketLGA 2011-3
Number of CPU Cores14-Core Processor
# of Processors InstalledE5-2680 V4
Installed Memory Size768GB
Storage ControllerLSI MegaRAID 9361-8i Controller
HDD InterfaceSATA/SAS
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
GPU TypeMatrox G200
Video Memory8MB
Ethernet Controller4x 10GBase-T LAN with Intel X540 Ethernet Controller
Management PortRJ 45
Features36 x 3.5" SATA/SAS Hot-Plug Drive Bays

Preguntas sobre este artículo

What RAID levels does the 9361-8i controller support?

The MegaRAID 9361-8i supports RAID 0, 1, 5, 6, 10, 50 and 60 across its eight SAS 12Gb/s ports.

How many 3.5-inch drive trays are included and where do they mount?

Thirty-six trays are supplied; twenty-four install in the front bays and twelve in the rear bays of the 4U chassis.

How do I access IPMI 2.0 on this server?

Connect the dedicated RJ45 management port to your network, then browse to the IPMI interface for KVM-over-LAN and virtual media.
