Silver 4U rack server front with thirty-six 3.5-inch drive trays

Supermicro

Supermicro SYS-6048R-E1CR36N 4U rack server 2x Xeon E5-2683 v4 64GB DDR4 36x 3.5" bays

SKU CH-PRK7-JBF6B

A 4U rack server with dual 16-core Xeon processors, 64 GB DDR4 ECC memory, a MegaRAID 9361-8i controller and 36 hot-swap 3.5-inch drive bays

  • Rack Height1U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • CPU Speed2.10 GHz
  • CPU SocketLGA 2011-3
  • Number of CPU Cores16-Core Processor
  • 36 hot-swap 3.5" drive bays support massive storage density
  • Dual Xeon E5-2683 v4 16-core CPUs at 2.1 GHz provide enterprise compute power
  • 64 GB DDR4 ECC registered memory ensures data integrity
  • LSI MegaRAID 9361-8i controller enables RAID 0/1/5/6/10/50/60
  • Quad 10GBase-T LAN ports with X540 controller deliver high-speed networking

36-Bay Storage Server

The Supermicro SYS-6048R-E1CR36N is a 4U rackmount system built for high-density storage workloads. It ships with dual Intel Xeon E5-2683 v4 processors, each running at 2.1 GHz with 16 cores, and 64 GB of DDR4 ECC memory installed across 24 DIMM slots.

Installation Notes

The chassis includes 36 hot-swap 3.5-inch drive trays pre-fitted for SATA or SAS drives, allowing tool-less insertion once the server is racked. Two redundant 1280 W power supplies slide into the rear and lock with a lever, while the LSI MegaRAID 9361-8i controller occupies a low-profile PCIe slot. Front bezel and rack rails are not supplied, so you must source compatible rails for your cabinet depth and plan cable routing for the 12 rear bays before powering on.

Sustained Load Behaviour

Under continuous I/O the dual 145 W CPUs and eight-port RAID controller draw steady power, which the 80 Plus Platinum units handle without throttle. The X540 quad 10GBase-T ports maintain line-rate throughput for extended replication or backup windows, and IPMI 2.0 provides out-of-band sensor monitoring so fan curves and temperatures can be tracked remotely during multi-day jobs.

Puntos fuertes

  • 36 hot-swap 3.5" drive bays support massive storage density
  • Dual Xeon E5-2683 v4 16-core CPUs at 2.1 GHz provide enterprise compute power
  • 64 GB DDR4 ECC registered memory ensures data integrity
  • LSI MegaRAID 9361-8i controller enables RAID 0/1/5/6/10/50/60
  • Quad 10GBase-T LAN ports with X540 controller deliver high-speed networking

Especificaciones

BrandSUPERMICRO
SeriesCSE-847BE1C-R1K28LPB-X10DRi-T4+
ModelSYS-6048R-E1CR36N
Rack Height1U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
CPU Speed2.10 GHz
CPU SocketLGA 2011-3
Number of CPU Cores16-Core Processor
# of Processors InstalledE5-2683 V4
Installed Memory Size64GB
Storage ControllerLSI MegaRAID 9361-8i Controller
HDD InterfaceSATA/SAS
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
GPU TypeMatrox G200
Video Memory8MB
Ethernet Controller4x 10GBase-T LAN with Intel X540 Ethernet Controller
Management PortRJ 45
Features36 x 3.5" SATA/SAS Hot-Plug Drive Bays

Preguntas sobre este artículo

How can I verify the server is running correctly after installation?

Confirm both Xeon E5-2683 v4 processors show 16 cores each at 2.1 GHz, 64 GB DDR4 2400 MHz ECC is detected, the MegaRAID 9361-8i controller appears with 1 GB cache, all 36 drive bays report ready status, and the four 10GBase-T ports link at expected speeds.

What ships with the unit and what must I purchase separately?

Included: chassis, dual 1280 W 80 Plus Platinum PSUs, 2× Xeon E5-2683 v4 CPUs, 4× 16 GB DDR4 RDIMMs, 9361-8i RAID card, 36 hot-swap 3.5" trays, X540 quad 10GBase-T NIC, IPMI 2.0 port, Matrox G200 video. Not included: drives, front bezel, rack rails.

Which capacity version should I choose for this 36-bay model?

This SKU is a single 36-bay configuration (24 front + 12 rear) supporting SAS3/SATA3 drives; choose it when you need maximum 3.5" density in 4U. Other Supermicro models offer fewer bays or 2.5" layouts, but this part number is fixed at 36 bays.
