Black tall mini PC barebone with front USB ports

ASUS

ASUS RNUC13ANHI50000UI i5-1340P barebone mini PC

SKU CH-JJGH-9AP89 MPN RNUC13ANHI50000UI

Barebone mini PC with a 13th Gen Intel Core i5-1340P, dual DDR4 SO-DIMM slots up to 64 GB, one M.2 PCIe Gen4x4 slot, one 2.5-inch SATA bay, dual HDMI 2.1, dual Thunderbolt 4.

  • ColorBlack
  • Form FactorTall
  • CPU TypeIntel Core i5-1340P
  • Memory installedNo Memory
  • Memory slot2 x 260Pin SO-DIMM
  • Memory Type SupportedDDR4 3200

CPU Type Intel Core i5-1340P

Group Tall Kit

  • 13th Gen Intel Core i5-1340P with Iris Xe graphics for responsive performance
  • Tall 4×4 form factor includes VESA mount for wall or monitor-back placement
  • 5GbE Intel i226V LAN plus Wi-Fi 6E for fast wired and wireless links
  • Dual HDMI 2.1 and dual Thunderbolt 4 with DP1.4 drive up to four 4K60 displays
  • Two DDR4 3200 SO-DIMM slots support up to 64GB and M.2 2280 PCIe Gen4x4 plus 2.5" SATA bay for storage expansion

Tall barebone with 13th Gen Core i5

The ASUS NUC 13 Pro RNUC13ANHI50000UI is a tall-form-factor mini PC barebone built around an Intel Core i5-1340P processor and integrated Intel Iris Xe graphics. It targets system builders and IT deployments that need a compact, VESA-mountable unit for digital signage, kiosk or office workloads. No memory or storage is included so the buyer chooses capacity.

Expansion bay and dual Thunderbolt 4 ports

A single M.2 2280 PCIe Gen4x4 slot accepts NVMe SSDs from 128GB to 8TB, while a 2.5-inch SATA header supports drives up to 2TB. Two Thunderbolt 4 Type-C ports provide 40Gbps bandwidth, DisplayPort 1.4 video and 5V/3A power delivery for docks or extra I/O modules. Front panel adds two USB 3.2 Gen2 Type-A ports at 10Gbps.

Tool-less access but memory

The chassis opens without tools to reveal two 260-pin SO-DIMM slots for DDR4 3200 modules up to 64GB total. Installers must supply RAM and at least one drive before first boot. The tall SKU includes a Kensington lock slot and cable-locking arm for physical security in public spaces.

Points forts

  • 13th Gen Intel Core i5-1340P with Iris Xe graphics for responsive performance
  • Tall 4×4 form factor includes VESA mount for wall or monitor-back placement
  • 5GbE Intel i226V LAN plus Wi-Fi 6E for fast wired and wireless links
  • Dual HDMI 2.1 and dual Thunderbolt 4 with DP1.4 drive up to four 4K60 displays
  • Two DDR4 3200 SO-DIMM slots support up to 64GB and M.2 2280 PCIe Gen4x4 plus 2.5" SATA bay for storage expansion

Caractéristiques

BrandASUS
SeriesNUC 13 PRO
ModelRNUC13ANHI50000UI
Part Number90AR00C1-M00090
ColorBlack
Form FactorTall
CPU TypeIntel Core i5-1340P
Memory installedNo Memory
Memory slot2 x 260Pin SO-DIMM
Memory Type SupportedDDR4 3200
Max Memory Supported64GB (2 x 32GB)
Other1 x Kensington Lock Slot
Storage InstalledNo Hard Drive
Serial ATA1 x SATA 6.0Gb/s
M.2 Slot1 x M.2 2280 PCIe Gen4x4, supports 128GB~8TB NVMe SSD
Integrated GraphicsIntel Iris Xe Graphics
LANIntel i226V
Max LAN Speed2.5Gbps
2.5" Internal Bays1 x SATA Power/DATA header for 2.5in SSD/HDD, supports 128GB~2TB SATA drive (Tall SKU only)
Front USB2 x USB 3.2 Gen2 Type-A (5V/0.9A, 10Gbps)
Front Audio Ports1 x Audio Jack (Line out/Mic in/Headphone out)
HDMI2 x HDMI 2.1 (up to 4K@60Hz)
Rear USB2 x Thunderbolt 4 (with DP1.4 / 5V/3A, 40Gbps)
1 x USB 3.2 Gen2 Type-A (5V/0.9A, 10Gbps)
1 x USB 2.0 Type-A (5V/0.5A, 480Mbps)
RJ451 x 2.5GbE (RJ45)
Other Rear Ports1 x Cable Locking Arm
1 x DC-in
Power Supply120W
Dimensions2.13" x 4.61" x 4.41"
PackagingVESA Mount & Screws / AC Power Adapter / Power Cord (US Only)
Poids d’expédition1.66 kg
Dimensions du colis191 × 171 × 127 mm

Autres versions de ce modèle

3 de plus dans cette gamme

Même famille, mémoire, ventirad ou fréquence différents — comparez avant de vous décider.

Questions sur cet article

Will the DDR4 3200 SO-DIMM slots or the M.2 2280 PCIe Gen4x4 slot need replacement later?

The two 260-pin SO-DIMM slots and the single M.2 2280 PCIe Gen4x4 slot are fixed on the board; only the memory modules or NVMe SSD you install may be upgraded up to 64 GB DDR4 3200 or 8 TB NVMe.

What limit appears first when the i5-1340P runs sustained workloads?

The processor's 28 W base power and the compact Tall chassis thermal capacity set the sustained performance ceiling; the single M.2 2280 PCIe Gen4x4 and one SATA 6.0 Gb/s bay do not throttle storage bandwidth.

How loud and hot does the unit get when it runs all day?

Qualified for 24/7 operation; the cooling solution is designed for continuous use with the i5-1340P at its base power, and the front USB 3.2 Gen2 ports supply 5 V / 0.9 A without extra heat.
