ASUS TUF Gaming X870-PRO WIFI7 W NEO ATX motherboard in dark finish with CPU cooler installed

ASUS

ASUS TUF GAMING X870-PRO WIF17 W NEO AMD motherboard & Ryzen 9 9950X3D CPU combo

SKU CH-2ZPW-Z5GYA

ATX motherboard and 16-core Ryzen 9 9950X3D combo with DDR5 support up to 256 GB, four M.2 slots, PCIe 5.0 graphics slot, WiFi7 and 5 Gb Ethernet

  • ChipsetAMD X870
  • South BridgeAMD X870
  • Number of Memory Slots4x288pin (DDR5)
  • Maximum Memory Supported256GB
  • Channel SupportedDual Channel
  • Memory Performance ProfileAMD EXPO / Intel XMP / ASUS AEMP

model TUF GAMING X870-PRO WIFI7 W NEO

+CPU + Ryzen 9 9950X3D

  • Robust power delivery with 16+2+1 80A SPS stages
  • Massive 128MB L3 cache accelerates gaming and AI workloads
  • Four M.2 slots support PCIe 5.0 and 4.0 x4 speeds
  • WiFi7 and 5Gb Ethernet provide high-speed wired and wireless connectivity
  • 256GB DDR5 capacity across four slots with AEMP for easy tuning

ASUS TUF X870-PRO WIFI7 Combo

This bundle pairs the ASUS TUF GAMING X870-PRO WIFI7 W NEO motherboard with the AMD Ryzen 9 9950X3D processor. The board uses the AMD X870 chipset and AM5 socket, supporting Ryzen 9000, 8000 and 7000 series CPUs. It targets enthusiasts building high-performance AI-ready desktops.

DDR5 256GB Capacity and PCIe 5.0 Layout

Four 288-pin DDR5 slots accept up to 256 GB in dual-channel mode with EXPO, XMP and AEMP profiles. The board provides one PCIe 5.0 x16 slot, two PCIe 4.0 x16 slots and four M.2 sockets supporting PCIe 5.0 and 4.0 x4. Two SATA 6Gb/s ports and RAID 0/1/5/10 handle additional storage.

16+2+1 80A Power Stages and 128MB L3 Cache

The 16+2+1 80A power stage design on an 8-layer PCB delivers stable current for the 170 W Zen 5 CPU. The processor brings 128 MB L3 cache and 16 MB L2 cache with integrated Radeon graphics. 5Gb Ethernet, WiFi7, USB4 40 Gbps and 20 Gbps USB-C with 30 W Power Delivery complete the connectivity.

Points forts

  • Robust power delivery with 16+2+1 80A SPS stages
  • Massive 128MB L3 cache accelerates gaming and AI workloads
  • Four M.2 slots support PCIe 5.0 and 4.0 x4 speeds
  • WiFi7 and 5Gb Ethernet provide high-speed wired and wireless connectivity
  • 256GB DDR5 capacity across four slots with AEMP for easy tuning

Caractéristiques

BrandASUS
ModelTUF GAMING X870-PRO WIFI7 W NEO+R9 9950X3D
ChipsetAMD X870
South BridgeAMD X870
Number of Memory Slots4x288pin (DDR5)
Maximum Memory Supported256GB
Channel SupportedDual Channel
Memory Performance ProfileAMD EXPO / Intel XMP / ASUS AEMP
ECC SupportedYes
Buffer SupportedUn-buffered
PCI Express 5.0 x161 x PCI Express 5.0 x16
PCI Express 4.0 x162 x PCI Express 4.0 x16
PCI Express x162 x PCI Express x16
PCI Express x41 x PCI Express x4
Serial ATA (SATA)2 x SATA 6Gb/s
M.24 x M.2 (Support PCIe 5.0 x4 & PCIe 4.0 x4)
SATA RAID0/1/5/10
Onboard Video ChipsetDepends on AMD Ryzen Series Processor with Integrated Graphics
Audio ChipsetRealtek ALC1220P
Audio Channels7.1 Channels
LAN ChipsetRealtek 5Gb
Max LAN Speed5Gbps
Wireless LANWi-Fi 802.11 be
BluetoothYes
Back I/O Ports2 x USB4 (40Gbps) Type-C, 3 x USB 10Gbps Type-A, 4 x USB 5Gbps Type-A, 1 x USB 2.0 Type-A, 1 x HDMI, 1 x Wi-Fi module, 1 x Realtek 5Gb Ethernet port, 3 x Audio jacks, 1 x BIOS FlashBack button, 1 x Clear CMOS button
COM1
Video PortsHDMI + 2 x USB Type-C
HDMI1 x HDMI port
RJ451 x RJ45
USB 3.13 x USB 3.1
USB 3.06 x USB 3.0
USB 1.1/2.01 x USB 2.0
USB Type-C2 x USB Type-C port, with USB4 (40Gbps) support
S/PDIF OutYes
Audio Ports3 Ports
Onboard USB1 x USB Type-C header, with USB 3.2 Gen 2x2 + 1 x USB 3.2 Gen 1 header + 3 x USB 2.0 headers
Form FactorATX
LED LightingRGB
Dimensions (W x L)12 inch x 9.6 inch
Power Pin24 Pin
Windows 11Supported

Autres versions de ce modèle

5 de plus dans cette gamme

Même famille, mémoire, ventirad ou fréquence différents — comparez avant de vous décider.

Questions sur cet article

Will the 170W TDP of the Ryzen 9 9950X3D hit thermal throttling under sustained all-core workloads?

The CPU is rated at 170W and the motherboard uses a 16+2+1 phase design with 80A power stages, an 8-layer PCB and dual 8-pin ProCool connectors to deliver stable current for heavy loads.

How loud and hot does the VRM area get when the system runs all day at full load?

The 16+2+1 80A power stages on an 8-layer PCB are designed for efficient delivery, while AI Cooling II adjusts fan curves automatically to balance noise and thermals during extended sessions.

Which DDR5 modules do I need to have on hand before this combo will post?

The board has four 288-pin DDR5 slots supporting up to 256GB in dual-channel; AMD EXPO, Intel XMP and ASUS AEMP profiles are all supported for automatic configuration.
