Silver 2U rack server with front bezel, eight 2.5-inch drive bays and dual hot-swap power supplies

DELL

DELL PowerEdge R730 2U rack server 2x Xeon E5-2660 v4 2.0GHz 14-core 64GB DDR4 8x 1.2TB SAS H730

SKU CH-T0VT-BQ6DJ

Dual 14-core Xeon 2.0 GHz server with 64 GB DDR4 ECC, eight 1.2 TB 10 K SAS drives and H730 RAID controller

  • TypeRack
  • Rack Height2U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • CPU Speed2.00 GHz
  • CPU SocketLGA 2011-3

Installed Memory Size 64GB

HDD 8 x 1.2TB 10K SAS

  • 28 processing cores handle parallel workloads with 2x Xeon E5-2660 v4 2.0 GHz 14-core CPUs
  • 64 GB DDR4 2400 MHz registered ECC memory supports large datasets with room to grow to 1.5 TB
  • PERC H730 1 GB controller enables RAID 0/1/5/6/10/50/60 for data protection
  • 8x 1.2 TB 10K SAS drives deliver high IOPS for transaction-heavy applications
  • iDRAC8 Enterprise plus quad-port 1GbE/10GbE SFP+ gives remote management and flexible networking

Dual Xeon 14-core 2U server

The Dell PowerEdge R730 is a 2U rack server equipped with two Intel Xeon E5-2660 v4 processors running at 2.0 GHz with 14 cores each. It includes 64 GB of DDR4 registered ECC memory across four 16 GB modules. The system uses a PERC H730 1 GB storage controller and eight 1.2 TB 10K SAS hard drives in 2.5-inch bays. Dual 750 W platinum power supplies and iDRAC8 Enterprise remote management are installed.

Virtualisation hosts and database nodes

This configuration suits workloads that benefit from high core counts and redundant SAS storage such as virtualisation clusters, database servers and high-performance computing data nodes. The quad-port network daughter card provides two 1 GbE and two 10 Gb SFP+ links for flexible connectivity. Buyers who need solid-state storage or more than eight drive bays should consider a different chassis. The fixed two-processor maximum also limits future CPU expansion beyond the installed pair.

Eight-bay 2.5-inch SAS chassis

The eight-bay 2.5-inch chassis defines the storage ceiling for this server. Only SAS or SATA drives fit the backplane and the PERC H730 controller supports RAID levels 0, 1, 5, 6, 10, 50 and 60. With eight 1.2 TB drives installed, raw capacity is fixed by the bay count and drive size. Any capacity increase requires larger drives or a different server model.

Points forts

  • 28 processing cores handle parallel workloads with 2x Xeon E5-2660 v4 2.0 GHz 14-core CPUs
  • 64 GB DDR4 2400 MHz registered ECC memory supports large datasets with room to grow to 1.5 TB
  • PERC H730 1 GB controller enables RAID 0/1/5/6/10/50/60 for data protection
  • 8x 1.2 TB 10K SAS drives deliver high IOPS for transaction-heavy applications
  • iDRAC8 Enterprise plus quad-port 1GbE/10GbE SFP+ gives remote management and flexible networking

Caractéristiques

BrandDELL
SeriesPowerEdge R730
ModelR730
TypeRack
Rack Height2U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
CPU Speed2.00 GHz
CPU SocketLGA 2011-3
Number of CPU Cores14-Core Processor
# of Processors Installed2
MAX Processors2
ChipsetIntel C610
Installed Memory Size64GB
Memory TypeDDR4
Max Memory Capacity1.5TB
Number of Memory Slots24
Storage ControllerDell Perc H730 1GB Controller
HDD InterfaceSAS
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
GPU TypeMatrox G200
Video Memory8MB
Ethernet ControllerDell Intel X520/I350 Quad Port 2x 1GbE 2x 10Gb SFP+ Network Daughter Card
LAN Ports4 x Ports
Expansion Slots1 x PCIe 3.0 x16 Slot, Single Riser Included (Riser 3)
Management PortRJ 45
Operating SystemNo
Features8 x 2.5" SATA/SAS Hot-Plug Drive Bays

Autres versions de ce modèle

5 de plus dans cette gamme

Même famille, mémoire, ventirad ou fréquence différents — comparez avant de vous décider.

Questions sur cet article

What is the SAS controller speed on the PERC H730 and what throughput does it cap?

The PERC H730 is a 12Gb/s SAS controller that supports RAID 0, 1, 5, 6, 10, 50 and 60 with a 1GB cache and battery backup.

What physical space and mounting hardware does the 2U server require?

The chassis occupies 2U of rack height and ships with ready rails and a front bezel for cabinet installation.

How are the eight 1.2TB drives installed and what step is often missed?

The 2.5-inch SAS drives slide into the front hot-swap bays; the common mistake is not configuring the virtual disks in the H730 BIOS before installing the operating system.
