Silver 2U rack server front with eight 2.5 inch drive bays and bezel

DELL

DELL PowerEdge R730 2U Rack Server 2x Xeon E5-2699 v3 2.3GHz 18C 64GB DDR4 8x 1.2TB SAS H730

SKU CH-6VTK-6QHB7

2U rack server with dual 18-core Xeon processors at 2.3 GHz, 64 GB DDR4, eight 1.2 TB SAS drives and a PERC H730 controller

  • TypeRack
  • Rack Height2U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • CPU Speed2.30 GHz
  • CPU SocketLGA 2011-3

Installed Memory Size 64GB

HDD 8 x 1.2TB 10K SAS

  • Dual 18-core Xeon processors at 2.3 GHz with 3.6 GHz turbo for heavy compute
  • 64 GB DDR4 registered ECC memory in four 16 GB modules for reliable capacity
  • PERC H730 controller with 1 GB cache enables RAID 0, 1, 5, 6, 10, 50, 60
  • Eight 1.2 TB 10K SAS drives deliver fast storage in 2.5-inch bays
  • Quad-port network card adds two 1 GbE and two 10 Gb SFP+ connections

Dual 18-core Xeon server for virtualised workloads

The Dell PowerEdge R730 is a 2U rack server equipped with two Intel Xeon E5-2699 v3 processors running at 2.3 GHz, each providing 18 cores. Sixty-four gigabytes of DDR4 registered ECC memory are installed across four 16 GB modules, leaving twenty free slots for expansion up to 1.5 TB. The PERC H730 controller with 1 GB cache manages eight 1.2 TB 10K SAS drives in a hot-swap 2.5-inch backplane.

Suited for database nodes and VDI hosts.

This configuration targets midsize and large enterprises running data warehouses, e-commerce platforms, virtual desktop infrastructure or high-performance computing data nodes. Quad-port networking with two 1 GbE and two 10 Gb SFP+ links plus iDRAC 8 Enterprise remote management simplify deployment in dense racks. Buyers who need GPU acceleration, more than two processor sockets or a different drive protocol should evaluate other platforms.

Eight 1.2 TB SAS drives on a H730 RAID controller

The storage subsystem centres on the Dell PERC H730 12 Gb/s controller supporting RAID 0, 1, 5, 6, 10, 50 and 60 plus pass-through mode. Eight enterprise-class 1.2 TB 10K SAS drives deliver the capacity and IOPS profile for the workloads listed above. Confirm that your application stack is compatible with SAS 12 Gb/s and the available RAID levels before purchase.

Points forts

  • Dual 18-core Xeon processors at 2.3 GHz with 3.6 GHz turbo for heavy compute
  • 64 GB DDR4 registered ECC memory in four 16 GB modules for reliable capacity
  • PERC H730 controller with 1 GB cache enables RAID 0, 1, 5, 6, 10, 50, 60
  • Eight 1.2 TB 10K SAS drives deliver fast storage in 2.5-inch bays
  • Quad-port network card adds two 1 GbE and two 10 Gb SFP+ connections

Caractéristiques

BrandDELL
SeriesPowerEdge R730
ModelR730
TypeRack
Rack Height2U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
CPU Speed2.30 GHz
CPU SocketLGA 2011-3
Number of CPU Cores18-Core Processor
# of Processors Installed2
MAX Processors2
ChipsetIntel C610
Installed Memory Size64GB
Memory TypeDDR4
Max Memory Capacity1.5TB
Number of Memory Slots24
Storage ControllerDell Perc H730 1GB Controller
HDD InterfaceSAS
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
GPU TypeMatrox G200
Video Memory8MB
Ethernet ControllerDell Intel X520/I350 Quad Port 2x 1GbE 2x 10Gb SFP+ Network Daughter Card
LAN Ports4 x Ports
Expansion Slots1 x PCIe 3.0 x16 Slot, Single Riser Included (Riser 3)
Management PortRJ 45
Operating SystemNo
Features8 x 2.5" SATA/SAS Hot-Plug Drive Bays

Autres versions de ce modèle

5 de plus dans cette gamme

Même famille, mémoire, ventirad ou fréquence différents — comparez avant de vous décider.

Questions sur cet article

Will the two Xeon E5-2699 v3 CPUs and 64GB DDR4 memory work with my existing LGA 2011-3 motherboard?

The server uses two Xeon E5-2699 v3 processors on an Intel C610 chipset with 64GB DDR4 registered ECC memory across 24 slots; your motherboard must support the same socket, chipset and registered ECC DDR4 to be compatible.

How can I verify the PERC H730 controller and eight 1.2TB SAS drives are healthy after installation?

Use the iDRAC8 Enterprise interface or boot into the PERC H730 BIOS utility to confirm all eight 1.2TB 10K SAS drives are detected, the 1GB cache battery shows charged, and the virtual disks report optimal RAID status.

Which items ship in the box and what must I source separately?

The chassis includes two Xeon E5-2699 v3 CPUs, 64GB DDR4 memory, PERC H730 controller, eight 1.2TB SAS drives, X520/I350 quad-port network card, iDRAC8 Enterprise, two 750W PSUs, ready rails and front bezel; SFP+ transceivers for 10GbE and any additional DDR4 modules are not included.
