Silver 2U rack server with front bezel, eight 2.5-inch drive bays and redundant power supplies

DELL

DELL PowerEdge R730 2U rack server 2x Xeon E5-2680 v4 2.4GHz 14-core 64GB DDR4 8x 1.2TB SAS H730

SKU CH-0QX9-MZ5RB

2U rack server with dual 14-core Xeon processors at 2.4 GHz, 64 GB DDR4 ECC memory, eight 1.2 TB 10K SAS drives on a PERC H730 RAID controller, dual 10 GbE SFP+ ports.

  • TypeRack
  • Rack Height2U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • CPU Speed2.40 GHz
  • CPU SocketLGA 2011-3

Installed Memory Size 64GB

HDD 8 x 1.2TB 10K SAS

  • Dual Xeon 14-core CPUs deliver 28 total cores for heavy workloads
  • 64 GB DDR4 registered ECC memory supports virtualization and databases
  • PERC H730 controller enables RAID 0/1/5/6/10/50/60 with battery-backed cache
  • Eight 1.2 TB 10K SAS drives provide fast redundant storage
  • Quad-port 1/10 GbE networking plus iDRAC8 Enterprise for remote management

Dual 14-core Xeon server for virtualization

The PowerEdge R730 fits 2U of rack space and ships with two Intel Xeon E5-2680 v4 processors at 2.4 GHz, each offering 14 cores and a 3.3 GHz turbo. Sixty-four gigabytes of DDR4 registered ECC memory populate four of the twenty-four slots, leaving room for expansion up to 1.5 TB. The platform targets midsize and large enterprises running data warehouses, e-commerce, VDI or high-performance computing nodes.

Redundant 750 W platinum supplies and hot-swap bays

Dual 750-watt platinum-efficiency power supplies provide full redundancy with hot-swap replacement. Eight 2.5-inch drive bays hold 1.2 TB 10 K SAS disks connected to a PERC H730 controller with 1 GB cache and battery-backed write cache. The controller supports RAID 0, 1, 5, 6, 10, 50 and 60 plus pass-through mode. Front-to-rear airflow across the 2U chassis keeps thermals steady under sustained load.

Quad-port networking and remote management built in

An Intel X520/I350 daughter card delivers two 1 GbE and two 10 Gb SFP+ ports without consuming a PCIe slot. iDRAC 8 Enterprise enables out-of-band remote management, virtual console and power control over a dedicated network interface. ReadyRails sliding rails and a front bezel are included for quick rack mounting and a clean front appearance.

Points forts

  • Dual Xeon 14-core CPUs deliver 28 total cores for heavy workloads
  • 64 GB DDR4 registered ECC memory supports virtualization and databases
  • PERC H730 controller enables RAID 0/1/5/6/10/50/60 with battery-backed cache
  • Eight 1.2 TB 10K SAS drives provide fast redundant storage
  • Quad-port 1/10 GbE networking plus iDRAC8 Enterprise for remote management

Caractéristiques

BrandDELL
SeriesPowerEdge R730
ModelR730
TypeRack
Rack Height2U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
CPU Speed2.40 GHz
CPU SocketLGA 2011-3
Number of CPU Cores14-Core Processor
# of Processors Installed2
MAX Processors2
ChipsetIntel C610
Installed Memory Size64GB
Memory TypeDDR4
Max Memory Capacity1.5TB
Number of Memory Slots24
Storage ControllerDell Perc H730 1GB Controller
HDD InterfaceSAS
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
GPU TypeMatrox G200
Video Memory8MB
Ethernet ControllerDell Intel X520/I350 Quad Port 2x 1GbE 2x 10Gb SFP+ Network Daughter Card
LAN Ports4 x Ports
Expansion Slots1 x PCIe 3.0 x16 Slot, Single Riser Included (Riser 3)
Management PortRJ 45
Operating SystemNo
Features8 x 2.5" SATA/SAS Hot-Plug Drive Bays

Autres versions de ce modèle

5 de plus dans cette gamme

Même famille, mémoire, ventirad ou fréquence différents — comparez avant de vous décider.

Questions sur cet article

How do I install the PERC H730 controller in the R730 and what step is often missed?

The PERC H730 1GB mini controller fits in the dedicated internal slot; the step often missed is connecting the battery backup cable to the controller before closing the chassis.

What maintenance or replacement will the 1.2TB 10K SAS drives need later?

The eight 1.2TB 10K SAS drives are mechanical; plan to replace any that develop read errors or exceed their rated workload limit, and keep a spare 2.5" SAS drive on hand.

What limit appears first when the dual Xeon E5-2680 v4 14-core CPUs run at full load continuously?

The 750 watt platinum power supplies cap total system power, so sustained 3.3 GHz turbo on all 28 cores will hit the power envelope before thermal limits.
