Tower server chassis with front bezel and eight 3.5 inch drive trays

DELL

DELL PowerEdge T430 5U rack server 2x Xeon E5-2620 v4 2.1GHz 256GB DDR4 H730 8x 3.5" trays

SKU CH-0Q0R-T6Q28

A 5U rack server with dual 8-core Xeon processors at 2.1 GHz, 256 GB DDR4 ECC memory, a PERC H730 RAID controller and eight 3.5-inch drive trays

  • Type0
  • Rack Height5U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • CPU Speed2.10 GHz
  • CPU SocketLGA 2011-3

Installed Memory Size 256GB

HDD None

  • Dual Xeon E5-2620 v4 processors provide 8 cores each at 2.1 GHz base and 3.0 GHz turbo
  • 256 GB DDR4 2133 MHz registered ECC memory installed across 12 slots with 384 GB maximum
  • PERC H730 1 GB controller supports RAID 0, 1, 5, 6, 10, 50, 60 plus pass-through
  • Eight 3.5-inch SAS/SATA hot-swap drive trays ready for storage expansion
  • Dual 750 W platinum power supplies and iDRAC 8 Express remote management included

5U tower server for small offices

The Dell PowerEdge T430 is a 5U tower server built for small-office and remote-office workloads such as file and print serving, mail, messaging and web hosting. It ships new with two Intel Xeon E5-2620 v4 processors, each running at 2.1 GHz with eight cores and a 3.0 GHz turbo frequency. The system includes 256 GB of DDR4 2133 MHz registered ECC memory across eight 32 GB modules.

Sustained load with dual 750 W supplies

Dual hot-swap 750 W platinum power supplies provide redundancy for continuous operation under sustained load. The PERC H730 storage controller with 1 GB cache and battery backup supports RAID 0, 1, 5, 6, 10, 50, 60 and pass-through modes across eight 3.5-inch SAS/SATA drive trays. Integrated Broadcom 5720 dual-port 1 GbE networking and iDRAC 8 Express remote management maintain availability during extended duty cycles.

Check tray count and memory ceiling

Verify that eight 3.5-inch drive trays meet your storage density needs before ordering, as no drives are installed. The platform offers twelve DDR4 slots with a 384 GB maximum, so confirm the 256 GB configuration leaves enough headroom for future expansion. Ensure your rack or floor space accommodates the 5U form factor and that plastic feet are not required for your installation.

Points forts

  • Dual Xeon E5-2620 v4 processors provide 8 cores each at 2.1 GHz base and 3.0 GHz turbo
  • 256 GB DDR4 2133 MHz registered ECC memory installed across 12 slots with 384 GB maximum
  • PERC H730 1 GB controller supports RAID 0, 1, 5, 6, 10, 50, 60 plus pass-through
  • Eight 3.5-inch SAS/SATA hot-swap drive trays ready for storage expansion
  • Dual 750 W platinum power supplies and iDRAC 8 Express remote management included

Caractéristiques

BrandDELL
SeriesPowerEdge T430
ModelT430
Type0
Rack Height5U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
CPU Speed2.10 GHz
CPU SocketLGA 2011-3
Number of CPU Cores8-Core Processor
# of Processors Installed0
MAX Processors2
ChipsetIntel C610
Installed Memory Size256GB
Memory TypeDDR4
Max Memory Capacity384GB
Number of Memory Slots12
Hard Drive (Installed)None
Storage ControllerDell Perc H730 1GB Controller
HDD InterfaceSATA/SAS
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
Media Drives0
GPU TypeMatrox G200
Video Memory8MB
Ethernet ControllerIntegrated Dell Broadcom 5720 Dual Port 1GbE LOM
LAN Ports4 x Ports
Expansion Slots1 x PCIe 3.0 x16 Slot, Single Riser Included (Riser 3)
Management PortRJ 45
Operating SystemNo
Features8 x 3.5" SATA/SAS Hot-Plug Drive Bays

Autres versions de ce modèle

5 de plus dans cette gamme

Même famille, mémoire, ventirad ou fréquence différents — comparez avant de vous décider.

Questions sur cet article

How much power and heat do the two 750 watt platinum supplies generate under continuous load?

Two 750 watt platinum supplies provide redundant hot-swap power; platinum efficiency means less waste heat than lower-rated units, though exact draw depends on the workload you run.

Which drives and cabling must I supply to populate the eight 3.5 inch trays?

The trays accept 3.5 inch SATA or SAS drives; no drives are installed, so you must provide the drives and any SAS or SATA cables the controller requires.

Will the PERC H730 controller recognise SAS drives from earlier Dell servers?

The PERC H730 supports SAS and SATA with RAID 0, 1, 5, 6, 10, 50, 60 and pass-through, so legacy SAS drives that meet those standards will be recognised.
