Dell PowerEdge T430 5U rack server silver chassis eight 3.5 inch drive bays front bezel two power supplies

DELL

DELL PowerEdge T430 8-bay 3.5" rack server 2x Xeon E5-2620 v4 2.1GHz 128GB DDR4 H730

SKU CH-VM6A-AYVAH

A 5U tower server with dual Xeon E5-2620 v4 processors, 128GB DDR4 ECC memory, a PERC H730 RAID controller, eight 3.5-inch drive bays, dual 1GbE ports.

  • Type0
  • Rack Height5U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • CPU Speed2.10 GHz
  • CPU SocketLGA 2011-3

Installed Memory Size 128GB

HDD None

  • Dual Xeon E5-2620 v4 CPUs deliver 16 cores at 2.1GHz with 3.0GHz turbo
  • 128GB DDR4 2133MHz registered ECC memory supports up to 384GB across 12 slots
  • PERC H730 1GB controller enables RAID 0/1/5/6/10/50/60 for 8x 3.5" SAS/SATA bays
  • iDRAC8 Express provides remote management while dual 750W platinum PSUs ensure power redundancy
  • Integrated dual-port 1GbE LOM and front bezel complete the 5U tower-ready chassis

5U Server with Dual 8-Core Xeons

This 5U tower chassis houses two Intel Xeon E5-2620 v4 processors, each running at 2.1 GHz with eight cores. The system ships with 128 GB of registered DDR4 ECC memory across eight 16 GB modules. A PERC H730 storage controller with 1 GB cache supports RAID levels 0, 1, 5, 6, 10, 50 and 60. Eight 3.5-inch drive trays accept SATA or SAS drives. Dual 750 W hot-swap power supplies and iDRAC8 Express remote management are included.

Suited for Small Offices and Branch Sites

The configuration targets small office and remote office environments needing single-server performance for collaboration, mail, file, print and web workloads. Buyers who require pre-installed storage drives should look elsewhere, as no hard drives are included. Those needing more than 384 GB of memory or support for newer processor generations will not find that capacity here. Plastic feet for tower placement are also not supplied.

Dual 8-Core Xeon E5-2620 v4 Processors

The pair of 2.1 GHz 8-core Xeon E5-2620 v4 CPUs provides 16 total cores and a 3.0 GHz turbo frequency. This processor choice determines the LGA 2011-3 socket platform and the C610 chipset, which together set the memory ceiling at 384 GB across 12 DDR4 slots. If your workload demands a different socket, core count or maximum memory limit, this server will not match those requirements.

Points forts

  • Dual Xeon E5-2620 v4 CPUs deliver 16 cores at 2.1GHz with 3.0GHz turbo
  • 128GB DDR4 2133MHz registered ECC memory supports up to 384GB across 12 slots
  • PERC H730 1GB controller enables RAID 0/1/5/6/10/50/60 for 8x 3.5" SAS/SATA bays
  • iDRAC8 Express provides remote management while dual 750W platinum PSUs ensure power redundancy
  • Integrated dual-port 1GbE LOM and front bezel complete the 5U tower-ready chassis

Caractéristiques

BrandDELL
SeriesPowerEdge T430
ModelT430
Type0
Rack Height5U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
CPU Speed2.10 GHz
CPU SocketLGA 2011-3
Number of CPU Cores8-Core Processor
# of Processors Installed0
MAX Processors2
ChipsetIntel C610
Installed Memory Size128GB
Memory TypeDDR4
Max Memory Capacity384GB
Number of Memory Slots12
Hard Drive (Installed)None
Storage ControllerDell Perc H730 1GB Controller
HDD InterfaceSATA/SAS
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
Media Drives0
GPU TypeMatrox G200
Video Memory8MB
Ethernet ControllerIntegrated Dell Broadcom 5720 Dual Port 1GbE LOM
LAN Ports4 x Ports
Expansion Slots1 x PCIe 3.0 x16 Slot, Single Riser Included (Riser 3)
Management PortRJ 45
Operating SystemNo
Features8 x 3.5" SATA/SAS Hot-Plug Drive Bays

Autres versions de ce modèle

5 de plus dans cette gamme

Même famille, mémoire, ventirad ou fréquence différents — comparez avant de vous décider.

Questions sur cet article

How much heat and power draw should I expect from the two 750 watt platinum power supplies running continuously?

The server includes two 750 watt platinum efficiency power supplies with redundant hot-swap capability, designed for continuous operation in office and remote office environments.

Which drives and cables must I supply to populate the eight 3.5 inch trays?

The system ships with eight 3.5 inch SAS/SATA drive trays but no drives installed; you must provide SAS or SATA hard drives or SSDs compatible with the PERC H730 controller.

Can the integrated Broadcom 5720 dual port 1GbE LOM and iDRAC 8 Express work with my existing network switches?

Yes, the onboard dual port 1GbE LOM uses standard Ethernet and iDRAC 8 Express provides remote management over the same network infrastructure.
