Rectangular silver metal U.2 15mm drive with label

Solidigm

Solidigm SB5PH27X153T001 15.36TB U.2 15mm PCIe 5.0 enterprise SSD

SKU CH-FVM7-FZMAS MPN SB5PH27X153T001

15.36 TB U.2 enterprise SSD with PCIe 5.0 x4, 176-layer TLC NAND, 14,500 MB/s read, 10,000 MB/s write, 3 M IOPS random read, 1 DWPD endurance

  • Form FactorU.2 15mm
  • Capacity15.36TB
  • Memory Components176L TLC 3D NAND
  • InterfacePCI-Express 5.0
  • Max Sequential ReadUp to 14500 MBps
  • Max Sequential WriteUp to 10000 MBps

Option 15.36TB U.2

  • 1.92TB E3.S
  • 1.92TB E3.S FIPS
  • 1.92TB E3.S Opal
  • 1.92TB U.2
  • 1.92TB U.2 FIPS
  • 1.92TB U.2 Opal
  • 15.36TB E3.S
  • 15.36TB E3.S FIPS
  • 15.36TB E3.S Opal
  • 15.36TB U.2
  • 15.36TB U.2 FIPS
  • 15.36TB U.2 Opal
  • 3.84TB E1.S 15mm
  • 3.84TB E1.S 15mm Opal
  • 3.84TB E1.S 9.5mm
  • 3.84TB E1.S 9.5mm Opal
  • 3.84TB E3.S
  • 3.84TB E3.S FIPS
  • 3.84TB E3.S Opal
  • 3.84TB U.2
  • 3.84TB U.2 FIPS
  • 3.84TB U.2 Opal
  • 7.68TB E1.S 15mm
  • 7.68TB E1.S 15mm Opal
  • 7.68TB E1.S 9.5mm
  • 7.68TB E1.S 9.5mm Opal
  • 7.68TB E3.S
  • 7.68TB E3.S FIPS
  • 7.68TB E3.S Opal
  • 7.68TB U.2
  • 7.68TB U.2 FIPS
  • 7.68TB U.2 Opal

Les versions barrées existent, mais ne sont pas disponibles ici.

  • 36TB capacity stores massive datasets in a single drive
  • PCIe 5.0 interface delivers up to 14500 MBps sequential read speed
  • 176-layer TLC 3D NAND enables 3,000,000 IOPS random read performance
  • 1 DWPD endurance rating supports 14 petabytes written over drive life
  • 5 million hour MTBF ensures reliability for continuous data-centre operation

15.36TB U.2 enterprise drive for data centres

The Solidigm D7-PS1010 delivers 15.36TB of storage in a U.2 15mm form factor built for server and data-centre workloads. It uses 176-layer TLC 3D NAND connected through a PCI-Express 5.0 x4 interface. Sequential reads reach up to 14500 MBps and writes up to 10000 MBps, with random performance of 3,000,000 read IOPS and 400,000 write IOPS. Endurance is rated at 1 DWPD and 14 PBW.

Upgrade from PCIe 4.0 or lower-capacity U.2 drives

Moving from a PCIe 4.0 U.2 SSD doubles the interface bandwidth, raising sequential throughput and reducing latency for read-heavy analytics or logging. The jump is worthwhile when the workload saturates a 4.0 link or when a single 15.36TB device can replace multiple smaller drives, simplifying array management. It is not suited for systems limited to PCIe 3.0 or for budgets that cannot absorb the higher active power draw.

Fits 15mm U.2 bays with 23W cooling headroom

The drive occupies a standard 15mm U.2 bay and weighs 140g. Idle power is 5W and active power peaks at 23W, so the chassis airflow must handle that thermal load within the 0°C to 77°C operating range. No Opal encryption is present, so encryption must be handled at the controller or software layer. The 2,500,000-hour MTBF and 1,000 G shock rating support continuous operation in vibration-prone racks.

Points forts

  • 36TB capacity stores massive datasets in a single drive
  • PCIe 5.0 interface delivers up to 14500 MBps sequential read speed
  • 176-layer TLC 3D NAND enables 3,000,000 IOPS random read performance
  • 1 DWPD endurance rating supports 14 petabytes written over drive life
  • 5 million hour MTBF ensures reliability for continuous data-centre operation

Caractéristiques

BrandSolidigm
ModelD7-PS1010
Part NumberSB5PH27X153T001
Form FactorU.2 15mm
Capacity15.36TB
Memory Components176L TLC 3D NAND
InterfacePCI-Express 5.0
Max Sequential ReadUp to 14500 MBps
Max Sequential WriteUp to 10000 MBps
4KB Random ReadUp to 3,000,000 IOPS
4KB Random WriteUp to 400,000 IOPS
Read Latency60µs
Write Latency7µs
Endurance1 DWPD / 14 PBW
MTBF2,500,000 hours
Power Consumption (Idle)5W
Power Consumption (Active)23W
Operating Temperature0°C to 77°C
Max Shock Resistance1,000 G (Max) at 0.5 msec
Max Vibration ResistanceOperating: 2.17 GRMS (5 - 700 Hz) Max
Non-Operating: 3.13 GRMS (5 - 800 Hz) Max
Weight140g +/- 10g
Poids d’expédition0.16 kg
Dimensions du colis128 × 102 × 25 mm

Autres versions de ce modèle

5 de plus dans cette gamme

Même famille, mémoire, ventirad ou fréquence différents — comparez avant de vous décider.

Questions sur cet article

Does the U.2 15mm form factor need a 15mm drive bay or a 2.5-inch tray with a 15mm spacer?

The drive is a U.2 15mm unit weighing 140g +/- 10g, so it requires a 15mm-high drive bay or a 2.5-inch tray fitted with a 15mm spacer to secure it properly.

When inserting the drive into a PCIe 5.0 x4 backplane, which orientation avoids bent pins?

Align the U.2 connector keying with the backplane socket, press straight in until the latch clicks, then secure the drive with the tray screws; forcing it at an angle bends the high-speed PCIe 5.0 pins.

After how many petabytes written should I plan to replace the drive under a 1 DWPD workload?

The endurance rating is 14 PBW, so plan replacement once the SMART media-written counter approaches 14 petabytes to stay within the 1 DWPD guarantee.
