Tall black tower UPS with LCD display and nine outlets on the rear

MINUTEMAN

MINUTEMAN EC3000LCD-NC Encompass 3000VA 2700W Tower UPS

SKU CH-DDX7-D5HH1 MPN EC3000LCD-NC

3000VA tower UPS delivers 2700W with zero transfer time, nine outlets including a locking L5-30R, and three minutes runtime at full load

  • International Version120V
  • Input Voltage Range0-160VAC
  • Input Frequency50/60Hz +/- 6Hz Auto-sensing
  • Input ConnectionNEMA L5-30P
  • VA Rating3000VA
  • Watts2700W

Model EC3000LCD-NC

Prikaži još 7 konfiguracija

Precrtane verzije postoje, ali nisu dostupne ovdje.

  • Zero transfer time protects voltage-sensitive equipment
  • 3000VA and 2700W capacity runs critical loads during outages
  • Eight controllable NEMA 5-15/20R plus one always-on NEMA L5-30R outlet
  • Ten minutes runtime at half load, three minutes at full load
  • cULus, FCC Class A, CE and RoHS2 certified for safety compliance

Tower UPS for voltage-sensitive equipment

The MINUTEMAN EC3000LCD-NC Encompass is a new 3000VA 2700W tower UPS designed for equipment that cannot tolerate any transfer time to battery power. It accepts 120V input through a NEMA L5-30P connection and delivers 120V output with frequency regulation of +/-0.2Hz unless synchronized to line. The unit suits servers, networking gear, and other critical loads that require continuous clean power during outages.

Three-minute full-load runtime

At full 2700W load the internal sealed lead-acid battery provides 3 minutes of runtime, while half load extends that to 10 minutes. Recharge to 90% capacity takes 8 hours from total discharge. The replaceable battery uses part number BM0078. Buyers needing longer autonomy or who cannot accommodate an 8-hour recharge window should consider external battery packs or a higher-capacity UPS instead.

Controllable outlets and management

Nine outlets are provided: eight NEMA 5-15/20R receptacles are controllable for load shedding, and one NEMA L5-30R receptacle remains always on. A serial port enables basic monitoring and shutdown signalling. The 254-joule surge rating covers minor transients only; environments with frequent heavy surges will require additional protection upstream.

Istaknuto

  • Zero transfer time protects voltage-sensitive equipment
  • 3000VA and 2700W capacity runs critical loads during outages
  • Eight controllable NEMA 5-15/20R plus one always-on NEMA L5-30R outlet
  • Ten minutes runtime at half load, three minutes at full load
  • cULus, FCC Class A, CE and RoHS2 certified for safety compliance

Specifikacije

BrandMINUTEMAN
SeriesENCOMPASS
ModelEC3000LCD-NC
International Version120V
Input Voltage Range0-160VAC
Input Frequency50/60Hz +/- 6Hz Auto-sensing
Input ConnectionNEMA L5-30P
VA Rating3000VA
Watts2700W
Output Voltage120V
Output Frequency50/60Hz +/-0.2Hz unless synchronized to line
Outlets9
Outlet Type[8] NEMA 5-15/20R (controllable) & [1] NEMA L5-30R (always on)
Battery TypeSealed Lead Acid
Battery Run TimeHalf Load: 10 min
Full Load: 3 min
Battery Recharge Time8 hours to 90% from total discharge
Battery ReplaceableBM0078
ApprovalscULus (UL1778 5th Edition & CSA 22.2 no. 107.3-14 / R: 2014), FCC Class A, CE certified, RoHS2 (EU Directive 2011/65/EU & 2015/863/EU)
Surge Energy Rating254 Joules
TemperatureOperating Temperature +32 to +104°F (0 to 40°C)
Storage Temperature +14 to +122°F (-10 to +50°C)
Humidity10% to 90% non-condensing
Dimensions26.9" x 12" x 17.6"
Weight73.0 lbs.
Težina pošiljke33.11 kg
Dimenzije pakiranja569 × 320 × 193 mm

Druge verzije ovog modela

još 5 u istoj seriji

Ista obitelj, različita memorija, hladnjak ili frekvencija — usporedite prije kupnje.

Pitanja o ovom artiklu

What does the 2700W rating mean for the equipment I connect?

It is the maximum real power the unit can deliver continuously; the connected load must not exceed 2700W or the UPS will shut down.

What does the NEMA L5-30P input plug limit in practice?

It requires a 30A 120V branch circuit and matching receptacle, so the UPS can only be installed where that supply exists.

How much space and weight should I plan for the tower?

The unit measures 26.9" x 12" x 17.6" and weighs 73.0 lbs, so allow clearance for ventilation and a sturdy floor or shelf.
