Compact black-grey aluminium mini PC, book-style, single-side ports

partaker

partaker I37 i5-1235U 16G 256G barebone mini PC

SKU CH-4QJ4-YKF6F

Industrial barebone mini PC with a 10-core Intel Core i5-1235U, 16 GB DDR5, 256 GB SSD, four Gigabit LAN ports, dual DisplayPort, six USB 3.0, isolated RS485 and GPIO, 12–24 V DC input.

  • ColorBlack gray
  • CPU TypeIntel Core i5 12th Gen

I37 CPU I5 1235U 16GB RAM / 256GB SSD

  • Ultraslim aluminium chassis fits tight spaces with single-side I/O
  • 10-core i5-1235U reaches 4.4 GHz for demanding workloads
  • 16 GB DDR5-4800 and 256 GB SSD ready to run
  • Four Gigabit LAN plus six USB 3.0 with two reverse-flow protected ports
  • Operates -20 °C to +60 °C on 12-24 V DC input

Compact Industrial Barebone

The Partaker I37 is a fan-cooled mini PC built around an Intel Core i5-1235U processor with 10 cores and 12 threads reaching 4.4 GHz. It ships with 16 GB of DDR5 4800 MHz memory and a 256 GB SSD installed. The all-aluminium chassis measures 172 by 136 by 50 mm and weighs 1.45 kg. This unit targets integrators deploying edge gateways, AGV controllers or factory automation nodes that need dense I/O in a book-style form factor.

Thermals Noise Power

Active cooling dissipates heat across the aluminium shell while the system draws 12 to 24 V DC through a four-pin Phoenix connector. Rated operation spans -20 °C to +60 °C with an industrial SSD and 5 to 95 % non-condensing humidity. The single-sided port layout keeps cables on one face for tidy cabinet installs. No acoustic or power-consumption figures are provided by the supplier.

Expansion And Mounting

Two DDR5 SODIMM slots accept up to 64 GB total, while one M.2 2280 M-key, one mSATA, two full-length Mini PCIe and one M.2 3052 B-key with internal Nano-SIM enable simultaneous SSD, 4G/5G, Wi-Fi or optional CAN modules. The bundle includes a wall-mount bracket; DIN-rail and desktop mounting are also supported. Integrated TPM 2.0, watchdog timer, Wake-on-LAN, PXE boot and auto power-on maintain 24/7 reliability without extra software.

Pluspunten

  • Ultraslim aluminium chassis fits tight spaces with single-side I/O
  • 10-core i5-1235U reaches 4.4 GHz for demanding workloads
  • 16 GB DDR5-4800 and 256 GB SSD ready to run
  • Four Gigabit LAN plus six USB 3.0 with two reverse-flow protected ports
  • Operates -20 °C to +60 °C on 12-24 V DC input

Specificaties

ColorBlack gray
CPU TypeIntel Core i5 12th Gen

Andere versies van dit model

Nog 5 in dezelfde serie

Dezelfde familie, met ander geheugen, andere koeler of kloksnelheid — vergelijk voordat u beslist.

Vragen over dit artikel

How do I mount the I37 barebone on a wall using the included bracket, and what clearance mistake do installers make?

Use the supplied wall-mount brackets on the 172 mm × 136 mm chassis; the common error is leaving less than 50 mm above the unit so the active fan cannot draw air.

Which memory and storage parts will need replacement first in a 24/7 industrial deployment?

The two DDR5 4800 MHz SODIMM modules and the M.2 2280 SSD are the only field-replaceable components; the soldered CPU and chipset are not serviceable.

At what ambient temperature does the i5-1235U begin to throttle during continuous full-load operation?

The spec lists a maximum operating temperature of +60 °C; sustained loads at or above that limit will trigger thermal throttling on the 10-core processor.
