Compact black-grey aluminum mini PC with single-side ports and active cooling

partaker

Partaker I37 i5-1235U 16G 512G barebone mini PC

SKU CH-ZYHD-ME9QH

Compact industrial mini PC with Core i5-1235U, 16 GB DDR5, 512 GB storage, four Gigabit LAN ports, dual DisplayPort, six USB 3.0, isolated RS485 and GPIO, 12-24 V DC input.

  • ColorBlack gray
  • CPU TypeIntel Core i5 12th Gen

I37 CPU I5 1235U 16GB RAM / 512GB SSD

  • Industrial-grade aluminium chassis fits tight spaces with 172 x 136 x 50 mm footprint
  • Core i5-1235U delivers 10 cores and 12 threads up to 4.4 GHz
  • DDR5 4800 MHz memory scales to 64 GB across two SODIMM slots
  • Four Gigabit LAN ports plus six USB 3.0 connectors handle heavy I/O loads
  • Wide 12-24 V DC input and -20 to +60 °C range suit harsh environments

Compact industrial barebone for embedded projects

The Partaker I37 is a fan-cooled aluminium mini PC built around an Intel Core i5-1235U processor with 10 cores and 12 threads reaching 4.4 GHz. It ships with 16 GB of DDR5 memory and a 512 GB SSD, ready for deployment in automation, AGV or AMR roles. The 12-24 V DC input and -20 °C to 60 °C operating range suit cabinet or vehicle mounting where standard desktop gear would fail.

Suits integrators needing dense I/O.

Four Gigabit LAN ports with one vPro-enabled, six USB 3.0 ports, two isolated RS485 links and an 8-channel isolated GPIO block give direct fieldbus access without extra adapters. Two DisplayPort outputs drive 7680×4320 panels for visual inspection stations. Buyers who only need a single network port and basic USB should look at simpler, lower-cost units instead.

Expansion slots and bundled bracket shape deployment

Two DDR5 SODIMM sockets accept up to 64 GB total, while an M.2 2280 slot, an mSATA slot, two full-length Mini PCIe sockets and an M.2 3052 B-key with Nano-SIM let you add storage, 4G/5G or CAN modules in any mix. A wall-mount bracket is included; DIN-rail and desktop fixtures are supported but not supplied. TPM 2.0, watchdog, Wake-on-LAN, PXE and auto power-on complete the 24/7 feature set.

Pluspunten

  • Industrial-grade aluminium chassis fits tight spaces with 172 x 136 x 50 mm footprint
  • Core i5-1235U delivers 10 cores and 12 threads up to 4.4 GHz
  • DDR5 4800 MHz memory scales to 64 GB across two SODIMM slots
  • Four Gigabit LAN ports plus six USB 3.0 connectors handle heavy I/O loads
  • Wide 12-24 V DC input and -20 to +60 °C range suit harsh environments

Specificaties

ColorBlack gray
CPU TypeIntel Core i5 12th Gen

Andere versies van dit model

Nog 5 in dezelfde serie

Dezelfde familie, met ander geheugen, andere koeler of kloksnelheid — vergelijk voordat u beslist.

Vragen over dit artikel

Do I need to supply my own 12 V to 24 V DC power source with a 4-pin Phoenix connector?

Yes, the unit requires an external 12–24 V DC supply wired to the 4-pin Phoenix power input; no internal PSU is included.

Will the three Intel i210-AT and one i219-LM ports work with my existing Cat5e patch cables?

All four Gigabit Ethernet ports use standard RJ45 connectors, so any Cat5e or higher patch cable will link at 1 Gbps.

How can I confirm the 16 GB DDR5 4800 MHz memory and 512 GB SSD are recognised after first boot?

Enter the BIOS or OS device manager; both should show two DDR5 SODIMMs totalling 16 GB at 4800 MHz and a 512 GB drive on the M.2 2280 slot.
