Compact black-grey aluminium mini PC with single-side I/O

partaker

Partaker I37 i5-1235U 8G 128G barebone mini PC

SKU CH-HQ1W-NN7CD

Industrial mini PC with Core i5-1235U, 8 GB DDR5, 128 GB SSD, four Gigabit LAN ports, dual DisplayPort, six USB 3.0, isolated RS485 and GPIO, plus 12-24 V DC input for 24/7 automation

  • ColorBlack gray
  • CPU TypeIntel Core i5 12th Gen

I37 CPU I5 1235U 8GB RAM / 128GB SSD

  • Ultraslim aluminium chassis fits tight industrial cabinets
  • 10-core i5-1235U reaches 4.4 GHz for demanding workloads
  • 2 DDR5 slots support 64 GB and 128 GB SSD installed
  • 4 Intel Gigabit LAN ports with vPro on LAN1
  • 12-24 V DC input runs from -20 °C to 60 °C

Compact industrial barebone

The Partaker I37 is a fanless-ready mini PC built around an Intel Core i5-1235U with ten cores and twelve threads reaching 4.4 GHz. It ships with 8 GB of DDR5 memory and a 128 GB SSD in an all-aluminium chassis measuring 172 by 136 by 50 mm. The unit targets integrators deploying edge gateways, AGV controllers or factory-automation nodes that require wide-temperature operation and 24/7 reliability.

Upgrade path and expansion

Two DDR5 4800 MHz SODIMM slots allow memory growth to 64 GB, while an M.2 2280 slot, an mSATA slot and three Mini PCIe sockets accept additional storage, 4G/5G or CAN modules simultaneously. The 12-24 V DC input replaces typical fixed-voltage adapters, letting the box run from industrial power rails without extra converters. Buyers needing more than 64 GB of RAM or discrete graphics acceleration should look elsewhere.

Interface and environmental limits

Four Gigabit Ethernet ports — three i210-AT and one i219-LM with vPro — provide wired connectivity, and dual DisplayPort outputs drive displays up to 7680 by 4320 at 60 Hz. Six USB 3.0 ports, two isolated RS-485 channels and eight-channel 924 V isolated GPIO cover most fieldbus needs. The system is rated for -20 °C to +60 °C ambient temperature and 5 to 95 % non-condensing humidity when fitted with an industrial-grade SSD.

Pluspunten

  • Ultraslim aluminium chassis fits tight industrial cabinets
  • 10-core i5-1235U reaches 4.4 GHz for demanding workloads
  • 2 DDR5 slots support 64 GB and 128 GB SSD installed
  • 4 Intel Gigabit LAN ports with vPro on LAN1
  • 12-24 V DC input runs from -20 °C to 60 °C

Specificaties

ColorBlack gray
CPU TypeIntel Core i5 12th Gen

Andere versies van dit model

Nog 5 in dezelfde serie

Dezelfde familie, met ander geheugen, andere koeler of kloksnelheid — vergelijk voordat u beslist.

Vragen over dit artikel

What mounting hardware is included for the 172 mm × 136 mm chassis?

The unit ships with a wall-mount bracket; DIN-rail and desktop mounting are also supported but their brackets are not included.

Which step is often missed when wiring the 4-pin Phoenix DC input?

Connecting both the 12 V and 24 V wide-range pins with correct polarity before powering on; reversing them can damage the input stage.

When should the two DDR5 4800 SODIMM modules be reseated or replaced?

Reseat if the system fails to POST after vibration or thermal cycling; replace modules if memory errors appear in logs or the 64 GB limit is reached.
