Adamant Custom 24-Core Workstation Desktop PC Intel Core Ultra 9 285K 192GB DDR5 8TB NVMe 10TB HDD Nvidia

Workstation for CAD and modelling

This desktop is built for engineers and designers who run SolidWorks, CAM or CAE workloads that demand sustained multi-core throughput. The 24-core Intel Core Ultra 9 285K and 192 GB of DDR5 give the headroom for large assemblies and simulation datasets. A 24 GB Nvidia RTX PRO 4000 Blackwell GPU adds certified driver support for professional 3D applications. Windows 11 Pro ships pre-installed and ready for domain join.

Build integration and expansion

The Gigabyte Z890 UD motherboard provides four M.2 slots and four SATA ports, leaving two M.2 sockets free after the factory 8 TB NVMe array. A single PCI Express x16 slot carries the GPU, so additional add-in cards must use the remaining chipset lanes. Front-panel I/O includes USB4 Type-C, USB 3.2 Gen 2 and USB 3.2 Gen 1 ports, while the mid-board header adds another Type-C and two Gen 1 connectors. The Antec P10 FLUX case offers three internal 3.5-inch bays and three 2.5-inch bays for further storage growth.

Thermals, noise and power

A 360 mm quiet-edition liquid cooler handles the CPU while a 140 mm PSU fan and four 120 mm case fans move air through the sound-dampened chassis. The 850 W 80 PLUS Bronze unit delivers overhead for the 24-core processor and professional GPU under sustained load. Fan speeds are adjustable via a front-panel button, allowing lower acoustic output during long render jobs. The liquid loop and case airflow keep component temperatures stable without aggressive fan curves.
