Full-height single-slot graphics card with fan cooler, two DisplayPort and one DVI output

AMD

AMD MXRT-5500 2GB PCIe 3.0 x16 Graphics Card

SKU CH-D12W-A91KM

Drives three monitors from a single PCIe 3.0 x16 slot with 2 GB memory, two DisplayPort and one DVI output, up to 5.8 MP grayscale resolution, and medical imaging tools such as Conference Clone

  • InterfacePCI Express 3.0 x16
  • Chipset ManufacturerAMD
  • GPUMXRT-5500
  • DirectXDirectX 11.1
  • OpenGLOpenGL 4.2
  • Multi-Monitor SupportYes
  • Drives three monitors from one PCIe 3.0 x16 slot
  • 8MP grayscale max resolution suits diagnostic displays
  • DirectX 11.1 and OpenGL 4.2 for medical imaging software
  • DisplayPort and DVI outputs connect two diagnostic screens plus a third
  • Single-slot form factor fits dense PACS workstations

Medical-grade display controller

The AMD MXRT-5500 is a single-slot PCIe 3.0 x16 graphics card built for diagnostic imaging workstations. It drives up to three monitors from one slot, supporting two high-resolution medical displays and a third auxiliary screen. The GPU delivers DirectX 11.1 and OpenGL 4.2 compatibility for PACS applications.

Bundled Barco productivity suite

Conference Clone View mirrors diagnostic images to a large-screen projector with scaling, zoom and pan controls. Dim View automatically lowers brightness on auxiliary displays such as worklists to reduce ambient light. Spot View highlights a circular region of interest by dimming surroundings and boosting contrast. Find Cursor locates the pointer instantly across multiple screens. Single View treats the entire display area as one seamless surface for centred hanging protocols.

Straightforward PCIe installation

The full-height card fits a single PCIe 3.0 x16 slot and uses an onboard fan for cooling. Driver support covers Windows 7 and Windows 8.1 in both 32-bit and 64-bit editions. Common issues arise when the system BIOS does not initialise the x16 link at 3.0 speeds or when DisplayPort cables exceed certified lengths, causing signal drop-out on 5.8MP grayscale outputs.

Highlights

  • Drives three monitors from one PCIe 3.0 x16 slot
  • 8MP grayscale max resolution suits diagnostic displays
  • DirectX 11.1 and OpenGL 4.2 for medical imaging software
  • DisplayPort and DVI outputs connect two diagnostic screens plus a third
  • Single-slot form factor fits dense PACS workstations

Specifications

BrandAMD
SeriesBarco MXRT-5500
ModelBarco MXRT-5500
InterfacePCI Express 3.0 x16
Chipset ManufacturerAMD
GPUMXRT-5500
DirectXDirectX 11.1
OpenGLOpenGL 4.2
Multi-Monitor SupportYes
DisplayPort2 x DisplayPort
DVI1 x DVI
Max ResolutionUp to 5.8MP grayscale
CoolerWith Fan
Operating Systems SupportedWindows 7 ­ 32/64­bit Windows 8.1 ­ 32/64­bit
Form FactorPlug-in CardFull-height
Slot WidthSingle Slot

Questions about this item

Will the single-slot fan cooler need periodic cleaning or replacement to keep the MXRT-5500 running reliably?

The card uses a single-slot fan cooler; dust buildup on the heatsink and fan blades is the main maintenance item, so schedule a brief compressed-air clean every few months depending on your environment.

What limit appears first when the MXRT-5500 drives three diagnostic displays continuously?

The 2 GB frame buffer and PCIe 3.0 x16 bandwidth set the practical ceiling; sustained high-resolution workloads across three heads will hit memory capacity before thermal limits.

How much noise and heat does the MXRT-5500 produce during all-day PACS use?

The single-slot fan spins up under load but stays within typical workstation acoustics; the card draws modest power through the PCIe slot, so case airflow handles the heat without extra cables.
