Square green CPU with silver lid and small black fan cooler attached

AMD

AMD Ryzen 5 1600 desktop processor with Wraith Stealth Cooler

SKU CH-H3BP-CVP3M

Six-core desktop processor with twelve threads, 3.2 GHz base clock, 3.6 GHz max turbo and a 65 W thermal design, bundled with a Wraith Stealth cooler

  • Processors TypeDesktop
  • NameRyzen 5 1600
  • CPU Socket TypeSocket AM4
  • # of Cores6-Core
  • # of Threads12-Threads
  • Operating Frequency3.2 GHz
  • 6 cores and 12 threads handle heavy multitasking smoothly
  • 65 W TDP keeps system power draw and heat low
  • 16 MB L3 cache speeds up repeated data access
  • 6 GHz max turbo frequency lifts single-thread performance
  • Included Wraith Stealth cooler provides adequate cooling out of the box

Ryzen 5 1600 six-core desktop processor

The AMD Ryzen 5 1600 is a 65 W desktop CPU built on 12 nm process technology. It provides six cores and twelve threads for gaming and multi-threaded workloads. The processor fits the AM4 socket and includes a Wraith Stealth cooler in the box.

Sustained load behaviour with 65 W TDP

With a 65 W thermal design power the chip maintains its 3.2 GHz base frequency under continuous load. The 16 MB L3 cache and 3 MB L2 cache reduce memory latency during extended sessions. Maximum turbo reaches 3.6 GHz when thermal headroom allows.

AM4 installation and common issues

The processor drops into any AM4 motherboard without a separate bracket. Apply a pea-sized amount of thermal paste if the pre-applied pad is damaged. Bent pins on the PGA package are the most frequent cause of a no-post condition.

Highlights

  • 6 cores and 12 threads handle heavy multitasking smoothly
  • 65 W TDP keeps system power draw and heat low
  • 16 MB L3 cache speeds up repeated data access
  • 6 GHz max turbo frequency lifts single-thread performance
  • Included Wraith Stealth cooler provides adequate cooling out of the box

Specifications

BrandAMD
Processors TypeDesktop
SeriesRyzen 5
NameRyzen 5 1600
ModelYD1600BBAFBOX
CPU Socket TypeSocket AM4
# of Cores6-Core
# of Threads12-Threads
Operating Frequency3.2 GHz
Max Turbo FrequencyUp to 3.6 GHz
L1 Cache576KB
L2 Cache3MB
L3 Cache16MB
Manufacturing Tech12nm
Instruction Set64-Bit
Memory Channel2
Virtualization Technology SupportYes
PCI Express Revision3.0
Max Number of PCI Express Lanes16
Thermal Design Power65W
Cooling DeviceCooling device not included - Processor Only

Questions about this item

How much heat does the 65W TDP generate during long sessions?

The processor has a 65W thermal design power, and the included Wraith Stealth cooler is built to handle that load continuously.

What motherboard socket is required for the AM4 package?

You need a motherboard with a Socket AM4 to install this CPU.

Will the PCIe 3.0 lanes limit an older graphics card?

The chip provides 16 lanes of PCI Express 3.0, so older GPUs that use PCIe 3.0 or earlier will run at their native speed.
