Green ceramic square with gold contacts and silver heatspreader reading Ryzen 7 5800XT

AMD

AMD Ryzen 7 5800XT desktop processor 100-100001582BOX

SKU CH-14ZP-8ZP0R MPN 100-100001582BOX

Eight-core desktop processor with 16 threads, 3.8 GHz base and 4.8 GHz boost, 32 MB L3 cache, DDR4-3200 support and 105 W TDP

  • Processors TypeDesktop
  • NameRyzen 7 5800XT
  • CPU Socket TypeSocket AM4
  • Core NameVermeer (Zen 3)
  • # of Cores8-Core
  • # of Threads16-Threads
  • Eight cores and sixteen threads handle heavy multitasking
  • 8 GHz base clock with 4.8 GHz max turbo speeds single-thread work
  • 32 MB L3 cache reduces latency for gaming and content creation
  • 7 nm Zen 3 architecture delivers high performance at 105 W TDP
  • DDR4 3200 dual-channel support up to 128 GB memory capacity

8-Core AM4 Desktop Processor

The AMD Ryzen 7 5800XT is an 8-core, 16-thread desktop CPU built on the 7nm Vermeer architecture. It fits the Socket AM4 platform and operates at a 3.8 GHz base frequency with a maximum turbo of 4.8 GHz. This processor targets users upgrading an existing AM4 system who need strong multi-threaded performance without integrated graphics.

105W TDP and Cooling Requirement

The processor carries a 105W thermal design power and ships without a cooler in the retail box. A compatible AM4 cooling solution rated for at least 105W is mandatory for sustained operation at the 4.8 GHz boost frequency. Buyers must budget for a separate air or liquid cooler that matches this thermal envelope.

128GB DDR4-3200 Memory Support

The dual-channel memory controller officially supports up to 128GB of DDR4-3200, providing ample headroom for content creation, virtualization and heavy multitasking. Four 32GB modules fill the maximum capacity, while two 16GB or 32GB kits leave room for future expansion. Memory speeds above 3200 are not guaranteed by the specification.

Highlights

  • Eight cores and sixteen threads handle heavy multitasking
  • 8 GHz base clock with 4.8 GHz max turbo speeds single-thread work
  • 32 MB L3 cache reduces latency for gaming and content creation
  • 7 nm Zen 3 architecture delivers high performance at 105 W TDP
  • DDR4 3200 dual-channel support up to 128 GB memory capacity

Specifications

BrandAMD
Processors TypeDesktop
SeriesRyzen 7 5000 Series
NameRyzen 7 5800XT
Model100-100001582BOX
CPU Socket TypeSocket AM4
Core NameVermeer (Zen 3)
# of Cores8-Core
# of Threads16-Threads
Operating Frequency3.8 GHz
Max Turbo FrequencyUp to 4.8 GHz
L1 Cache512KB
L2 Cache4MB
L3 Cache32MB
Manufacturing Tech7nm
Instruction Set64-Bit
Memory TypesDDR4 3200
Memory Channel2
Max Memory Size128 GB
Integrated GraphicsNone Integrated Graphics
PCI Express Revision5.0
Max Number of PCI Express Lanes20/24 (Usable/Total)
Thermal Design Power105W
Cooling DeviceAMD Wraith Prism
Compatible Desktop ChipsetsAMD X570 / AMD X470
Operating System SupportedWindows 11 / Windows 10 / Ubuntu / RHEL
Advanced TechnologiesAMD Zen 3 Core Architecture, AMD StoreMI Technology, AMD Ryzen Master Utility, AMD Ryzen VR-Ready Premium
Shipping weight0.79 kg
Package size133 × 133 × 133 mm

Questions about this item

How does the 3.8 GHz base clock behave when all 8 cores are under load?

The 3.8 GHz base frequency is the guaranteed minimum across all eight cores at the 105 W TDP. With adequate cooling the CPU will sustain this speed indefinitely during multi-threaded workloads.

What memory speeds does the DDR4 controller officially support?

The integrated memory controller is rated for DDR4-3200 in dual-channel mode. Faster modules will run at this speed unless the motherboard firmware enables a higher data rate.

What cooler mounting hardware is required for the AM4 socket?

The processor fits the standard AM4 mounting pattern used by most aftermarket air and liquid coolers. Any cooler labelled AM4-ready will attach without extra brackets.
