Square green ceramic processor with gold contacts and silver heat spreader, AM5 socket form factor

AMD

AMD Ryzen 7 9800X3D 100-100001084WOF desktop processor

SKU CH-4317-Q6Q3Z MPN 100-100001084WOF

Eight-core desktop processor with 3D V-Cache, 5.2 GHz boost and DDR5 support up to 8800 MT/s for Socket AM5

  • Processors TypeDesktop
  • NameRyzen 7 9800X3D
  • CPU Socket TypeSocket AM5
  • Core NameGranite Ridge Zen 5
  • # of Cores8-Core
  • # of Threads16-Threads
  • 8 cores and 16 threads handle heavy multitasking workloads
  • 2 GHz max turbo frequency accelerates single-thread performance
  • 96 MB L3 cache cuts latency for gaming
  • Integrated Radeon graphics at 2200 MHz covers display output without a discrete card
  • DDR5 support up to 8800 MT/s and 192 GB capacity feeds data-hungry apps

AMD Ryzen 7 9800X3D desktop processor

The AMD Ryzen 7 9800X3D is an 8-core, 16-thread desktop processor built on the Zen 5 architecture. It operates at a 4.7 GHz base frequency and reaches a 5.2 GHz max boost frequency. The chip includes 96MB of L3 cache using second-generation 3D V-Cache technology and features integrated AMD Radeon graphics. It fits the Socket AM5 platform with a 120W TDP.

Best for gaming builds needing high cache

This processor suits enthusiasts building a high-performance gaming system on the AM5 platform who can supply their own cooling solution. The large L3 cache targets low-latency gaming performance at 1080p and 1440p resolutions. Builders who need a bundled cooler, prefer lower power draw, or require more than eight cores for heavy multi-threaded workloads should consider other models.

96MB L3 cache with 3D V-Cache technology

The defining specification is the 96MB L3 cache implemented with second-generation AMD 3D V-Cache technology. This cache structure reduces memory latency for gaming workloads. The processor supports DDR5 memory up to 8800 MT/s across two channels with a maximum capacity of 192GB. It provides 28 total PCIe 5.0 lanes with 24 usable lanes for graphics and storage.

Highlights

  • 8 cores and 16 threads handle heavy multitasking workloads
  • 2 GHz max turbo frequency accelerates single-thread performance
  • 96 MB L3 cache cuts latency for gaming
  • Integrated Radeon graphics at 2200 MHz covers display output without a discrete card
  • DDR5 support up to 8800 MT/s and 192 GB capacity feeds data-hungry apps

Specifications

BrandAMD
Processors TypeDesktop
SeriesRyzen 7 9000 Series
NameRyzen 7 9800X3D
Model100-100001084WOF
CPU Socket TypeSocket AM5
Core NameGranite Ridge Zen 5
# of Cores8-Core
# of Threads16-Threads
Operating Frequency4.7 GHz
Max Turbo Frequency5.2 GHz
L1 Cache640KB
L2 Cache8MB
L3 Cache96MB
Manufacturing TechTSMC 4nm FinFET
Instruction Set64-Bit
Memory TypesDDR5 5600 / DDR5 6000 / DDR5 6400 / DDR5 7600 / DDR5 8200 / DDR5 8400 / DDR5 8600 / DDR5 8800
Memory Channel2
Max Memory Size192 GB
Integrated GraphicsAMD Radeon Graphics
Graphics Base Frequency2200 MHz
PCI Express Revision5.0
Max Number of PCI Express Lanes28, 24 (Total/Usable)
Thermal Design Power120W
Cooling DeviceCooling device not included - Processor Only
Compatible Desktop ChipsetsAMD X870E, X870, B840, B850 and existing X670/E, B650/E and A620-based motherboards, with BIOS updates
Operating System SupportedWindows 11 - 64-Bit Edition , Windows 10 - 64-Bit Edition , RHEL x86 64-Bit , Ubuntu x86 64-Bit
Advanced TechnologiesAMD EXPO Technology , AMD Ryzen Technologies
Shipping weight0.09 kg
Package size127 × 127 × 36 mm

Questions about this item

Does the processor include a cooling solution in the box?

No, the processor is sold without a cooler; a compatible AM5 cooler must be purchased separately.

Which memory speeds are officially supported by the CPU?

The memory controller supports DDR5 at 5600, 6000, 6400, 7600, 8200, 8400, 8600 and 8800 MT/s across two channels up to 192 GB total.

What motherboard chipsets are compatible with this Socket AM5 processor?

Compatible chipsets include X870E, X870, B850, B840, X670E, X670, B650E, B650 and A620, with a BIOS update where required.
