AMD Ryzen Threadripper PRO 9975WX 32-Core 4.0 GHz sTR5 desktop processor 100-100000723WOF

32-Core Workstation Processor

The AMD Ryzen Threadripper PRO 9975WX is a 32-core, 64-thread desktop CPU built for artists, architects and engineers who need maximum multi-threaded throughput. It operates at a 4.0 GHz base clock with a max turbo frequency up to 5.4 GHz and uses the sTR5 socket on the 9000 WX-Series platform. The TSMC 4nm FinFET Shimada Peak design includes 128MB L3 cache and 32MB L2 cache to accelerate demanding professional workloads.

350W Thermal Envelope

With a 350W TDP, this processor requires a robust cooling solution capable of dissipating sustained high heat loads during render, simulation or compute tasks. The 4nm manufacturing process helps manage power efficiency across 32 cores, but sustained all-core workloads will push thermal output to the rated limit. No integrated graphics are present, so a discrete GPU is mandatory for display output and GPU-accelerated pipelines.

Eight-Channel DDR5 Platform

The CPU supports eight-channel DDR5 6400 memory with ECC, providing massive bandwidth for large datasets and in-memory workloads. Builders must pair it with an sTR5 motherboard offering sufficient VRM phases and memory slots to populate all channels. The platform frees up PCIe lanes for multiple high-speed storage devices and professional GPUs, enabling a highly expandable workstation configuration.
