Square metallic processor with gold contact pads on the underside and a silver integrated heat spreader engraved with the model name

AMD

AMD Ryzen Threadripper PRO 9995WX 96-Core 2.5 GHz sTR5 desktop processor 100-100001361WOF

SKU CH-Z6AT-Y4NXX MPN 100-100001361WOF

96-core, 192-thread desktop processor with 2.5 GHz base clock, 5.4 GHz max turbo, 384 MB L3 cache and DDR5-6400 eight-channel support for workstation workloads

  • Processors TypeDesktop
  • NameRyzen Threadripper PRO 9995WX
  • CPU Socket TypeSocket sTR5
  • Core NameShimada Peak
  • # of Cores96-Core
  • # of Threads192-Threads
  • 96 cores and 192 threads accelerate heavy multi-threaded workloads
  • Max turbo up to 5.4 GHz lifts single-threaded responsiveness
  • 384 MB L3 cache keeps large datasets close to the cores
  • Eight-channel DDR5 6400 memory support feeds bandwidth-hungry applications
  • TSMC 4 nm FinFET process at 350 W TDP delivers high compute density

Ryzen Threadripper PRO 9995WX 96-core workstation

The AMD Ryzen Threadripper PRO 9995WX is a desktop processor built for professional workstations. It targets artists, architects and engineers who need maximum multi-threaded throughput. The chip delivers 96 cores and 192 threads on the sTR5 platform. Base frequency sits at 2.5 GHz with a maximum turbo of 5.4 GHz.

sTR5 platform limits and DDR5 6400 memory ceiling

The processor fits the sTR5 socket and draws up to 350 W under load. Memory support tops out at DDR5 6400 across eight channels, so total bandwidth is capped by that specification. No integrated graphics are present, meaning a discrete GPU is mandatory for display output. The 384 MB L3 cache and 96 MB L2 cache help feed the 96 cores within those interface constraints.

Verify motherboard power delivery and cooling

Before ordering, confirm your sTR5 motherboard is rated for 350 W sustained power delivery and that its VRM cooling can handle the thermal load. Ensure the chassis and cooler provide sufficient clearance for a high-wattage sTR5 heatsink or liquid block. Check that the power supply has enough 8-pin EPS connectors for the board. Validate that your operating system and applications can utilise 192 threads effectively.

Highlights

  • 96 cores and 192 threads accelerate heavy multi-threaded workloads
  • Max turbo up to 5.4 GHz lifts single-threaded responsiveness
  • 384 MB L3 cache keeps large datasets close to the cores
  • Eight-channel DDR5 6400 memory support feeds bandwidth-hungry applications
  • TSMC 4 nm FinFET process at 350 W TDP delivers high compute density

Specifications

BrandAMD
Processors TypeDesktop
SeriesRyzen Threadripper PRO 9000 WX-Series
NameRyzen Threadripper PRO 9995WX
Model100-100001361WOF
CPU Socket TypeSocket sTR5
Core NameShimada Peak
# of Cores96-Core
# of Threads192-Threads
Operating Frequency2.5 GHz
Max Turbo FrequencyUp to 5.4 GHz
L1 Cache7680KB
L2 Cache96MB
L3 Cache384MB
Manufacturing TechTSMC 4nm FinFET
Instruction Set64-Bit
Memory TypesDDR5 6400
Memory Channel8
Virtualization Technology SupportYes
Integrated GraphicsNone Integrated Graphics
PCI Express Revision5.0
Max Number of PCI Express Lanes148, 144, 128 (Total/Usable/PCIe 5.0)
Thermal Design Power350W
Cooling DeviceCooling device not included - Processor Only
Compatible Desktop ChipsetsAMD Pro 695 / AMD TRX50 / AMD WRX90
Operating System SupportedWindows 11 (64-Bit Edition), RHEL (x86 64-Bit), Ubuntu (x86 64-Bit), Windows 10 (64-Bit Edition)
Advanced TechnologiesAMD EXPO Technology , AMD PRO technologies , AMD Ryzen Technologies
Security & ReliabilityAMD Memory Guard: Yes
AMD Secure Processor: Yes
Windows Secure Boot: Yes
UEFI Secure Boot: Yes
Windows Device Guard: Yes
Guest Mode Execution (GMET) Trap: Yes
Virtualization-Based Security (VBS): Yes
Windows Secured-Core PC: Yes
Firmware TPM: Yes
AMD-V (SVM): Yes
AMD-V Nested Paging (RVI): Yes
AMD AVIC (Interrupt Virtualization): Yes
AMD-Vi (I/O MMU Virtualization): Yes
Second Level Address Translation (SLAT): Yes
Advanced Encryption Standard New Instructions (AES-NI): Yes
AMD Enhanced Virus Protection (NX bit): Yes
FIPS Certification: In Review
Shipping weight0.39 kg
Package size127 × 127 × 71 mm

Questions about this item

What is the difference between the 96-core 2.5 GHz model and any other Threadripper PRO 9000 WX-Series options?

The 9995WX is the top-tier SKU with 96 cores, 192 threads, a 2.5 GHz base clock, 5.4 GHz max boost, and 384 MB L3 cache. Other WX-Series models have fewer cores, lower cache, or different frequency targets.

How does the 5.4 GHz max turbo frequency behave inside a workstation running sustained loads?

Max boost reaches 5.4 GHz on one or two cores when thermal and power headroom allows. Under continuous all-core workloads the 350 W TDP typically keeps clocks closer to the 2.5 GHz base.

What does the DDR5 6400 eight-channel memory controller actually deliver in bandwidth?

Eight channels of DDR5-6400 provide up to 64 GB/s theoretical peak bandwidth per socket, scaling with populated DIMM slots and memory rank configuration.
