Compact DIP high-voltage power supply module in a metal enclosure

Analog Technologies

Analog Technologies Compact DIP High Voltage Power Supply 0 to 2kV .5mA 12V Input

SKU CH-405F-WPPKZ

Converts a 12 V input into a continuously adjustable 0 to 2 kV output at 0.5 mA with short-circuit protection in a compact DIP package

  • TypeHigh Voltage Power Supply
  • Adjustable 0–2 kV output for precise control
  • 5 mA current suits low-power applications
  • 12 V DC input enables simple integration
  • Overload and short-circuit protection safeguards equipment
  • Metal enclosure provides shielding and durability

Compact High-Voltage DIP Module

This Analog Technologies unit is a DC-DC converter that steps a 12 V input up to a continuously adjustable 0 to 2 kV output at up to .5 mA. It targets engineers and technicians building photomultiplier, optical, nuclear or medical instrumentation where a stable, low-ripple high-voltage rail is required.

DIP Pin-Out and Protection Features

The module uses a standard DIP footprint for direct PCB mounting and offers continuous linear voltage adjustment through a control pin. Built-in overload and short-circuit protection guards the load and the converter, while the metal enclosure provides shielding with zero EMI emissions.

Suited for Precision Low-Current HV Applications

This supply suits designs needing a compact, moisture-proof and shockproof high-voltage source with minimal drift. It is not intended for systems that require higher output current, a different input voltage range or an alternative package style.

Highlights

  • Adjustable 0–2 kV output for precise control
  • 5 mA current suits low-power applications
  • 12 V DC input enables simple integration
  • Overload and short-circuit protection safeguards equipment
  • Metal enclosure provides shielding and durability

Specifications

TypeHigh Voltage Power Supply

Questions about this item

How do I verify the output is stable after connecting the 12V input?

Measure the high-voltage output with a suitable meter; it should adjust linearly from zero to 2kV at up to .5mA with low ripple and minimal drift.

What comes in the package and what must I source separately?

The unit itself is supplied; you must provide a 12V DC source, load wiring, and any safety interlocks or enclosures required by your application.

Which version suits a photomultiplier tube needing up to 2kV at low current?

This model delivers 0 to 2kV at .5mA from a 12V input, matching typical PMT bias requirements.
