Silver rackmount power strip with ten NEMA 5-15R outlets and 8 ft cord

APC

APC AP7750A Automatic Transfer Switch PDU 1440 VA 10x NEMA 5-15R 15A 8 ft

SKU CH-HQR8-1TK0N MPN AP7750A

Rack-mount automatic transfer switch supplies 1.44 kVA through ten NEMA 5-15R outlets from a 120 V, 15 A input with an eight-foot cord

  • TypeAutomatic Transfer Switch
  • StyleRackmount
  • ROHSYes
  • Input Voltage100V, 120V
  • Input Frequency50/60 Hz
  • Maximum Input Current15A
  • Automatic transfer switching protects connected equipment during power source failure
  • Ten NEMA 5-15R outlets distribute 1440 VA to multiple devices from one unit
  • 8-foot input cord with NEMA 5-15P plug reaches rack power sources without extension leads
  • Regulatory derated input current of 12 A supports continuous operation within electrical code limits
  • ROHS-compliant construction meets environmental substance restrictions for global deployment

Automatic Transfer Switch PDU

The APC AP7750A is a rackmount automatic transfer switch that delivers 1440 VA at 100 V or 120 V. It accepts a single NEMA 5-15P input and provides ten NEMA 5-15R outlets for connected equipment.

Suitable for single-cord devices needing redundant

This unit suits IT racks where servers or network gear have only one power supply but the site runs two independent feeds. Builds that require more than 12 A derated current or outlets other than NEMA 5-15R should look at other power distribution options.

1440 VA at 100 V or 120 V

The 1.44 kVA rating and 12 A regulatory derated input current decide whether the switch can support the intended load. Verify the total connected draw against this limit before deployment.

Highlights

  • Automatic transfer switching protects connected equipment during power source failure
  • Ten NEMA 5-15R outlets distribute 1440 VA to multiple devices from one unit
  • 8-foot input cord with NEMA 5-15P plug reaches rack power sources without extension leads
  • Regulatory derated input current of 12 A supports continuous operation within electrical code limits
  • ROHS-compliant construction meets environmental substance restrictions for global deployment

Specifications

BrandAPC
ModelAP7750A
TypeAutomatic Transfer Switch
StyleRackmount
ROHSYes
Input Voltage100V, 120V
Input Frequency50/60 Hz
Maximum Input Current15A
Regulatory Derated Input Current12A
Input Connector(s)NEMA 5-15P
Cord Length8 ft
Output Voltage100V, 120V
Output Watts (VA)1440 VA
Output Connector(s)(10) NEMA 5-15R
Operating Environment-5 - 45 ºC
Operating Relative Humidity0 - 95%
Operating Elevation0 - 3000 m
Storage Temperature-25 - 65 ºC
Storage Relative Humidity0 - 95%
Storage Elevation0 - 15000 m
FeaturesAPC Automatic Transfer Switch (AP7750A) - NEMA 5-15R - 1.44 kVA - 100 V AC, 120 V AC
Dimensions1.73" x 17.01" x 9.29" (H x W x D)
Weight10.36 lbs.
Shipping weight6.37 kg
Package size594 × 356 × 112 mm

Questions about this item

How much rack space does the 1.73 inch high AP7750A occupy?

The unit is 1.73 inches tall, 17.01 inches wide and 9.29 inches deep, fitting a standard 1U rack opening.

Which input plug must be connected to each source for the automatic transfer to work?

Two NEMA 5-15P cords are required; each plugs into a separate 120 V, 15 A circuit so the switch can transfer between them.

When should the internal batteries of the automatic transfer switch be replaced?

The AP7750A has no internal batteries; it relies on the two live AC sources, so no battery replacement is needed.
