White 120 mm square case fan with white blades and frame

ARCTIC COOLING

ARCTIC COOLING BioniX F120 ACFAN00093A 120 mm case fan White

SKU CH-S5Z1-0F1AP MPN ACFAN00093A

120 mm white case fan runs 200 to 1800 RPM for 69 CFM airflow at 0.5 sone using a fluid dynamic bearing and PWM sharing

  • TypeCase Fan
  • CompatibilityCase
  • Bearing TypeFluid Dynamic Bearing
  • RPM200 - 1800 RPM
  • Air Flow69 CFM (@ 1,800 RPM)
  • Noise Level0.5 Sone (@ 1,800 RPM)
  • Whisper-quiet gaming sessions with 0.5 Sone noise level
  • Precise speed control from 200 to 1800 RPM via PWM PST
  • Strong airflow of 69 CFM at maximum RPM for efficient cooling
  • Long-lasting reliability from fluid dynamic bearing with German-engineered lubricant
  • Clean white 120 mm design fits standard case mounting points

White 120 mm PWM case fan

The Arctic BioniX F120 is a 120 mm case fan finished in white, built around a fluid dynamic bearing and a 3-phase motor. It connects via a standard 4-pin PWM header and supports PWM Sharing Technology so multiple fans can run from one header. The speed range spans 200 to 1800 RPM, delivering up to 69 CFM of airflow at the top speed. At that speed the manufacturer rates the noise at 0.5 Sone.

Builders who want quiet, white-themed cooling

This fan suits system builders who want a clean white aesthetic and low noise during long gaming sessions. The wide speed range and PST support make it easy to balance airflow and acoustics across several fans. Buyers who need higher static pressure for dense radiators or who require a different frame colour should look at other models. The 27 mm thickness fits most standard case mounts, but always verify clearance in compact builds.

69 CFM at 1800 RPM decides fit

The single figure that determines whether this fan meets a cooling target is the 69 CFM airflow rating measured at 1800 RPM. If a build demands more air movement than that, this model will fall short regardless of its quiet operation or colour. Conversely, if the required airflow is at or below this level, the wide 200 to 1800 RPM range lets the fan run slower and quieter while still satisfying the thermal load.

Highlights

  • Whisper-quiet gaming sessions with 0.5 Sone noise level
  • Precise speed control from 200 to 1800 RPM via PWM PST
  • Strong airflow of 69 CFM at maximum RPM for efficient cooling
  • Long-lasting reliability from fluid dynamic bearing with German-engineered lubricant
  • Clean white 120 mm design fits standard case mounting points

Specifications

BrandARCTIC COOLING
SeriesBioniX F120
ModelACFAN00093A
TypeCase Fan
CompatibilityCase
Bearing TypeFluid Dynamic Bearing
RPM200 - 1800 RPM
Air Flow69 CFM (@ 1,800 RPM)
Noise Level0.5 Sone (@ 1,800 RPM)
Power Connector4 Pin
ColorWhite
FeaturesSilent 3-Phase Motor: Extremely silent operation through 3-phase motor guarantees long gaming sessions without annoying noise.
200 to 1800 RPM: With a wide range of regulation and the PWM Sharing Technology (PST), the BioniX F120 fan speed can be controlled synchronously with all your other fans together and thus keep the noise at a minimum while guaranteeing maximum cooling performance when needed.
Optimised Fan Design: We further optimised the fan blade design to get a higher airflow at lower noise generation. This guarantees high pressure and highly efficient ventilation for your
Dimensions120.00 x 120.00 x 27.00 mm
Shipping weight0.17 kg
Package size130 × 130 × 36 mm

Other versions of this model

1 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Does this fan need a 4-pin PWM header on the motherboard?

Yes, the BioniX F120 uses a 4-pin power connector and requires a PWM header for speed control between 200 and 1800 RPM.

Can I chain this fan with older 3-pin fans using the PST function?

PWM Sharing Technology synchronises speed signals between fans on the same header; 3-pin fans will run at full voltage and will not follow the PWM curve.

How do I confirm the fan is running at its rated 69 CFM airflow?

At maximum speed the fan spins at 1800 RPM and produces 0.5 Sone; verify the RPM reading in BIOS or fan-control software under load to ensure it reaches the top of its range.
