Green micro-ATX board, silver AM5 socket, black DDR5 slots, PCIe x16 slot, two M.2 sockets, HDMI and DisplayPort, SATA ports

ASRock

ASRock A620M-HDV/M.2 AMD motherboard

SKU CH-2YB2-FDXD2

Micro-ATX AM5 board for 65 W Ryzen 7000 CPUs with DDR5 5600, PCIe 4.0 x16, Gen4 M.2, dual SATA and 7.1 audio

  • CPU Socket TypeAM5
  • CPU TypeSupports AMD Ryzen 7000 Series Processors (up to 65W)
  • ChipsetAMD A620
  • Number of Memory Slots2x288pin (DDR5)
  • Memory StandardDDR5 5600+(OC)
  • Maximum Memory Supported64GB
  • Supports Ryzen 7000 processors up to 65W for efficient performance
  • DDR5 memory up to 5600 MHz with dual-channel support up to 64GB
  • PCIe 4.0 x16 slot with 15µ gold contacts for reliable GPU connection
  • Two M.2 sockets including one PCIe Gen4x4 for fast NVMe storage
  • Realtek ALC897 7.1-channel audio with Nahimic enhancement for clear sound

AM5 micro-ATX for 65W Ryzen 7000 builds

The ASRock A620M-HDV/M.2 targets compact systems using AMD Ryzen 7000 series processors with a 65 W power ceiling. The AMD A620 chipset delivers essential platform features on a micro-ATX footprint. Two DDR5 slots accept up to 64 GB of memory running at 5600 MT/s or higher when overclocked. Integrated AMD RDNA 2 graphics output over HDMI and DisplayPort handles display duties for processors that include graphics.

4+1+1 Dr.MOS phases handle steady 65W loads

A 4+1+1 power phase design with Dr.MOS transistors feeds the CPU socket during sustained workloads rather than brief bursts. The board exposes one PCIe 4.0 x16 slot with 15 µ gold contacts for the primary graphics card and two PCIe 3.0 x1 slots for add-in cards. Storage includes a CPU-attached Hyper M.2 socket for PCIe Gen4 x4 NVMe drives, a chipset M.2 socket supporting PCIe Gen3 x2 or SATA 6 Gb/s modes, and two SATA 6 Gb/s ports. RAID 0 and 1 are available on SATA; M.2 NVMe RAID 0, 1 and 10 require extra expansion cards.

Rear I/O and front headers cover daily connectivity

The rear panel provides five USB 3.2 Gen1 ports — two Type-A, one Type-C and two more via front-panel headers — plus Realtek Gigabit LAN and Realtek ALC897 7.1-channel audio with Nahimic processing. An M.2 Key E socket accepts Wi-Fi modules for wireless networking. BIOS Flashback and ASRock Auto Driver Installer simplify firmware updates and driver setup without an operating system installed.

Highlights

  • Supports Ryzen 7000 processors up to 65W for efficient performance
  • DDR5 memory up to 5600 MHz with dual-channel support up to 64GB
  • PCIe 4.0 x16 slot with 15µ gold contacts for reliable GPU connection
  • Two M.2 sockets including one PCIe Gen4x4 for fast NVMe storage
  • Realtek ALC897 7.1-channel audio with Nahimic enhancement for clear sound

Specifications

BrandASRock
ModelA620M-HDV/M.2
CPU Socket TypeAM5
CPU TypeSupports AMD Ryzen 7000 Series Processors (up to 65W)
ChipsetAMD A620
Number of Memory Slots2x288pin (DDR5)
Memory StandardDDR5 5600+(OC)
Maximum Memory Supported64GB
Channel SupportedDual Channel
ECC SupportedNon-ECC
Buffer SupportedUn-buffered
Memory FeatureSupports Extreme Memory Profile (XMP) and EXTended Profiles for Overclocking (EXPO) memory modules
* Please refer to Memory Support List on ASRock's website for more information.
PCI Express 4.0 x161 x PCIe 4.0 x16 Slot (PCIE1), supports x16 mode*
* Supports NVMe SSD as boot disks
- 15µ Gold Contact in VGA PCIe Slot (PCIE1)
PCI Express x12 x PCIe 3.0 x1 Slots (PCIE2 and PCIE3)*
Serial ATA (SATA)2 x SATA 6Gb/s
M.2CPU:
- 1 x Hyper M.2 Socket (M2_1, Key M), supports type 2280 PCIe Gen4x4 (64 Gb/s) mode*
Chipset:
- 1 x M.2 Socket (M2_2, Key M), supports type 2260/2280 SATA3 6.0 Gb/s & PCIe Gen3x2 (16 Gb/s) modes*
* Supports NVMe SSD as boot disks
SATA RAIDSupports RAID 0 and RAID 1 for SATA storage devices
Additional RAID ControllerSupports RAID 0, RAID 1 and RAID 10 for M.2 NVMe storage devices*
* Requires additional M.2 NVMe expansion cards to support RAID 10
Audio ChipsetRealtek ALC897 Audio Codec
Nahimic Audio
Audio Channels7.1 Channels
LAN ChipsetRealtek RTL8111H
Max LAN Speed1Gbps
Back I/O Ports2 x Antenna Mounting Points
1 x HDMI Port
1 x DisplayPort 1.4
1 x USB 3.2 Gen1 Type-C Port
2 x USB 3.2 Gen1 Type-A Ports
2 x USB 2.0 Ports
1 x RJ-45 LAN Port
1 x BIOS Flashback Button
HD Audio Jacks: Line in / Front Speaker / Microphone
Onboard USB2 x USB 2.0 Headers (Support 4 USB 2.0 ports)
1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports)
Other Connectors1 x Power LED and Speaker Header
1 x CPU Fan Connector (4-pin)*
3 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control)**
1 x Front Panel Audio Connector
* CPU_FAN1 supports the fan power up to 1A (12W).
** CHA_FAN1~3/WP support the fan power up to 2A (24W).
** CHA_FAN1~3/WP can auto detect if 3-pin or 4-pin fan is in use.
Form FactorMicro ATX
Dimensions (W x L)9.6" x 8.9"
Power Pin1 x 24 pin ATX Power Connector
1 x 8 pin 12V Power Connector
Windows 11Supported
FeaturesSuperb Productivity
- Dual Channel DDR5
Rock-Solid Durability
- 4+1+1 Power Phase, 50A Dr.MOS for VCore
EZ Update
- BIOS Flashback Button
- ASRock Auto Driver Installer
EZ Troubleshooter
- ASRock Post Status Checker
Package Contents1 x User Manual
1 x I/O Shield
2 x SATA Data Cables
3 x Screws for M.2 Sockets

Questions about this item

Will a 65W Ryzen 7000 processor fit the power delivery on this board?

The 4+1+1 Dr.MOS power phase design is rated for CPUs up to 65W, matching the supported Ryzen 7000 series limit.

Can I install two DDR5 modules and run them in dual channel at 5600 MT/s?

Yes, the board has two 288-pin DDR5 slots supporting dual-channel operation and DDR5 5600+(OC) with XMP and EXPO profiles.

Which M.2 slot should I use for the fastest NVMe boot drive?

Use the CPU-connected Hyper M.2 socket (M2_1, Key M) which runs at PCIe 4.0 x4 for 64 Gb/s throughput.
