Green rectangular Mini-ITX board with silver CPU socket, two black memory slots, vertical M.2 slot and rear I/O shield

ASRock

ASRock B360M-ITX/ac Intel motherboard

SKU CH-BPTH-9T590

Mini-ITX board for 8th and 9th gen Intel CPUs with dual-channel DDR4, Ultra M.2, 802.11 ac Wi-Fi and 1 Gbps LAN

  • CPU Socket TypeLGA 1151 (300 Series)
  • CPU TypeSupports 8th Generation Intel Core Processors (Socket 1151)
  • Supported CPU TechnologiesTurbo Boost Technology 2.0
  • ChipsetIntel B360
  • Onboard Video ChipsetSupports Intel UHD Graphics Built-in Visuals: Intel Quick Sy
  • Number of Memory Slots2x288pin (DDR4)
  • Supports 8th generation Intel Core processors on LGA 1151 socket
  • Dual-channel DDR4 memory up to 2666 MHz with 32 GB maximum
  • Ultra M.2 slot enables PCIe 3.0 x4 NVMe storage at 32 Gb/s
  • Intel I219-V Gigabit LAN plus 802.11 ac dual-band Wi-Fi module
  • Realtek ALC887 codec delivers 7.1 channel high-definition audio

Compact LGA 1151 board for 8th and 9th Gen Intel

This Mini ITX motherboard uses the Intel B360 chipset and the LGA 1151 socket for 300 series processors. It fits small-form-factor builds that need integrated Wi-Fi and a single full-length PCIe slot. The board delivers essential connectivity without the bulk of larger ATX designs.

Who this suits and who should look elsewhere

It suits builders assembling a compact desktop with an 8th or 9th Generation Intel Core CPU and up to 32 GB of DDR4 memory. It is not suitable for older LGA 1151 CPUs, for overclocking unlocked K-series chips, or for systems that require more than two memory slots or multiple x16 slots.

The spec that decides fit

The single PCI Express 3.0 x16 slot runs in x16 mode and also supports NVMe SSDs as boot devices. If the build needs a second graphics card, additional x16 lanes or a larger M.2 complement, this board will not meet those requirements.

Highlights

  • Supports 8th generation Intel Core processors on LGA 1151 socket
  • Dual-channel DDR4 memory up to 2666 MHz with 32 GB maximum
  • Ultra M.2 slot enables PCIe 3.0 x4 NVMe storage at 32 Gb/s
  • Intel I219-V Gigabit LAN plus 802.11 ac dual-band Wi-Fi module
  • Realtek ALC887 codec delivers 7.1 channel high-definition audio

Specifications

BrandASRock
ModelB360M-ITX/ac
CPU Socket TypeLGA 1151 (300 Series)
CPU TypeSupports 8th Generation Intel Core Processors (Socket 1151)
* Not backward compatible with older generation of LGA 1151 CPUs
Supported CPU TechnologiesTurbo Boost Technology 2.0
ChipsetIntel B360
Onboard Video ChipsetSupports Intel UHD Graphics Built-in Visuals: Intel Quick Sync Video with AVC, MVC (S3D) and MPEG-2 Full HW Encode1, Intel InTru 3D, Intel Clear Video HD Technology, Intel Insider, Intel UHD Graphics
DirectX 12
HWA Encode/Decode: AVC/H.264, HEVC/H.265 8-bit, HEVC/H.265 10-bit, VP8, VP9 8-bit, VP9 10-bit (Decode only), MPEG2, MJPEG, VC-1 (Decode only)
Three graphics output options: DVI-I, HDMI and DisplayPort 1.2
Supports Triple Monitor
Supports HDMI with max. resolution up to 4K x 2K (4096x2160) @ 30Hz
Supports DisplayPort 1.2 with max. resolution up to 4K x 2K (4096x2304) @ 60Hz
Sup
Number of Memory Slots2x288pin (DDR4)
Memory StandardDDR4 2666/ 2400/ 2133
Maximum Memory Supported32GB
* Due to the operating system limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows 32-bit OS. For Windows 64-bit OS with 64-bit CPU, there is no such limitation.
Channel SupportedDual Channel
PCI Express 3.0 x161 x PCI Express 3.0 x16 Slot (PCIE1: x16 mode)
* Supports NVMe SSD as boot disks
Other Slots1 x Vertical M.2 Socket (Key E) with the bundled Wi-Fi 802.11 ac module (on the rear I/O)
Serial ATA (SATA)4 x SATA3 6.0Gb/s Connectors, support NCQ, AHCI and Hot Plug*
* If M2_1 is occupied by a SATA-type M.2 device, SATA3_0 will be disabled.
M.21 x Ultra M.2 Socket, supports M Key type 2280 M.2 SATA3 6.0Gb/s module and M.2 PCI Express module up to Gen3 x4 (32Gb/s)**
** Supports Intel Optane Technology
** Supports NVMe SSD as boot disks
** Supports ASRock U.2 Kit
Audio ChipsetRealtek ALC887
Audio Channels7.1 Channels
* To configure 7.1 CH HD Audio, it is required to use an HD front panel audio module and enable the multi-channel audio feature through the audio driver.
Supports Surge Protection
LAN ChipsetIntel I219-V
Max LAN Speed1Gbps
Wireless LANIntel 802.11 ac Wi-Fi Module
Supports IEEE 802.11 a/b/g/n/ac
Supports Dual-Band (2.4/5 GHz)
Supports high speed wireless connections up to 433 Mbps
BluetoothSupports Bluetooth 4.2 / 3.0 + High speed class II
PS/21 x PS/2 keyboard/mouse port
Video Ports1 x DVI-I Port
HDMI1 x HDMI
RJ451 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED)
DisplayPort1 x DisplayPort 1.2
USB 3.12 x USB 3.1 Gen2 Type-A Ports (10Gb/s)
2 x USB 3.1 Gen1 Ports (Supports ESD Protection)
Audio PortsHD Audio Jacks: Line in / Front Speaker / Microphone
Antenna Connectors2 x Antenna Ports
Onboard USB1 x USB 2.0 Header (Supports 2 USB 2.0 ports) (Supports ESD Protection)
1 x USB 3.1 Gen1 Header (Supports 2 USB 3.1 Gen1 ports) (Supports ESD Protection)
Other Connectors1 x Chassis Intrusion Header
1 x CPU Fan Connector (4-pin)*
1 x Chassis Fan Connector (4-pin)**
1 x Chassis/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)***
1 x Front Panel Audio Connector
* The CPU Fan Connector supports the CPU fan of maximum 1A (12W) fan power.
** The Chassis Fan Connector supports the chassis fan of maximum 1A (12W) fan power.
*** The Chassis/Water Pump Fan supports the water cooler fan of maximum 2A (24W) fan power.
*** CHA_FAN1/WP can auto detect if 3-pin or 4-pin fan is in use.
Form FactorMini ITX
Dimensions (W x L)6.7" x 6.7"
Power Pin1 x 24-pin ATX Power Connector
1 x 8-pin 12V Power Connector
FeaturesUnique Feature:
ASRock USB 3.1 Gen2
- ASRock USB 3.1 Gen2 Type-A Ports (10Gb/s)
ASRock Super Alloy
- Premium 60A Power Choke
- Dual-Stack MOSFET (DSM)
- Sapphire Black PCB
- High Density Glass Fabric PCB
Intel 802.11 ac Wi-Fi
ASRock Ultra M.2 (PCIe Gen3 x4 & SATA3)
ASRock Full Spike Protection (for USB, Audio, LAN Ports)
ASRock Live Update & APP Shop
BIOS:
- 128MB AMI UEFI Legal BIOS with multilingual GUI support
- ACPI 6.0 Compliant wake up events
- SMBIOS 2.7 Support
- CPU, DRAM, PCH 1.0V, VCCST Voltage Multi-adjustment
Software and UEFI:
Software
- ASRock A-Tuning
- ASRock XFast L
Package ContentsAccessories:
- Quick Installation Guide, Support CD, I/O Shield
- 2 x SATA Data Cables
- 2 x ASRock Wi-Fi 2.4/5 GHz Antennas
- 1 x Screw for M.2 Socket

Questions about this item

How much heat does the B360M-ITX/ac produce when running an 8th generation Core processor all day?

The board uses a 6-phase power design for the CPU socket, and the B360 chipset has a 6 W TDP, so sustained loads stay cool with a standard Mini-ITX case airflow.

Which DDR4 memory kit do I need to populate both 288-pin slots for dual-channel operation?

Install two DDR4 modules rated at 2666, 2400 or 2133 MT/s; the board supports up to 32 GB total in dual-channel mode.

Will my existing SATA 6.0 Gb/s SSD still work if I add an M.2 NVMe drive in the Ultra M.2 slot?

Yes, the Ultra M.2 socket runs over PCIe 3.0 x4 and does not share bandwidth with the four SATA3 ports, so both drives operate simultaneously.
